Sida 1/3
1
12/19/22
FSW-0503 5-Port Fast Ethernet PoE
Switch, 802.3af PoE, 4 PoE Outputs,
61.6W
Product Images
Short Description
Provides flexibility of 4 x 10/100BASE-TX PoE ports
IEEE 802.3af PoE compliant to simplify deployment and installation
Auto-detection and protection of non-standard PoE devices
10/100Mbps, full/half-duplex, auto-negotiation, auto-MDI/MDIX
IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
2
12/19/22
Description
Advanced PoE Solution FSW-0503(Z) is a 4 Fast Ethernet PoE +1 Fast Ethernet Switch. Per PoE port is
powered up to 15.4W. The total PoE power budget is 61.6W. It is an ideal solution for extensive WLAN, IP
surveillance system deployments especially when the legacy and PoE compliance devices co-exist in your
network environment. The switch automatically detects IEEE 802.3af compliant device connected and
provides power and data over a single cable to these devices. FSW-0503(Z) is compact in size, making it ideal
for desktop users with limited space. You also have option of installing several FSW-0503(Z) in a 19” chassis
(POC-6000) for a largescale rack-mount PoE Solution. Stable and Reliable Network
Environment FSW-0503(Z) enables users to deploy a stable and reliable high-speed LAN environment, with
store-and-forward switching architecture, packet error filtering and non-blocking packet forwarding. The
802.3x and backpressure flow control mechanisms work respectively for full and half duplex modes. This
device supports N-way auto-negotiation protocol that automatically detects networking speed and duplex
modes. Easy to UseFor instant error detection, the switch is equipped with a full range of LEDs to help
monitor and troubleshoot problems on the network.
Additional Information
Approval and compliance FCC, CE, RoHS
Operating humidity 0% RH ~ 90% RH
Operating temperature 0°C ~ 45°C
Storage humidity 0% RH ~ 90% RH
Storage temperature -20°C ~ 70°C
Backplane (Gbps) 10/100Mbps
MAC address table 1K
Flash memory size 48KB
Mount Desk mount
Standards
IEEE 802.3 10-BASE-T, Ethernet IEEE 802.3u 100-BASE-TX,
Fast Ethernet IEEE 802.3x Full-duplex Flow Control IEEE
802.3af Power over Ethernet (PoE)IEEE 802.3 10-BASE-T,
Ethernet IEEE 802.3u 100-BASE-TX, Fast Ethernet IEEE
802.3x Full-duplex Flow Control IEEE 802.3af Power over
Ethernet (PoE)IEEE 802.3 10-BASE-T, Ethernet IEEE 802.3u
100-BASE-TX, Fast Ethernet IEEE 802.3x Full-duplex Flow
Control IEEE 802.3af Power over Ethernet (PoE)IEEE 802.3
10-BASE-T, Ethernet IEEE 802.3u 100-BASE-TX, Fast
Ethernet IEEE 802.3x Full-duplex Flow Control IEEE
802.3af Power over Ethernet (PoE)IEEE 802.3 10-BASE-T,
Ethernet IEEE 802.3u 100-BASE-TX, Fast Ethernet IEEE
802.3x Full-duplex Flow Control IEEE 802.3af Power over
Ethernet (PoE)IEEE 802.3 10-BASE-T, Ethernet IEEE 802.3u
100-BASE-TX, Fast Ethernet IEEE 802.3x Full-duplex Flow
Control IEEE 802.3af Power over Ethernet (PoE)
Product weight (kg) 0,8
Color Grey
EAN 4015867156803
Model number FSW-0503
Package contents FSW-0503, User Manual
3
12/19/22
Fast Ethernet multi-mode ST 5
802.3af PoE 4
Grade Commercial
Data Rate Fast Ethernet
PoE Supported Yes
Manageable No
Fanless Yes
Concurrent ports Total5.00
PoE Power Budget Total61.60
