Sida 1/28
Web Management Guide
( GEP- 2841 )
Chapter Product IntroductionⅠ
Product introduction
The LevelOne GEP-2841 Web Smart Gigabit PoE Switch, provides 24 PoE ports
10/100/1000Base-T plus 2 port Gigabit Uplink SFP and 2 port Gigabit Uplink RJ45 to
enable high speed network. With the plus the clearly visible status LEDs provide simple
monitoring of port link activity. Moreover, the SFP slots support pluggable modules that
enabling you to choose from a variety of transceivers. It offers powerful enhanced PoE
functionality and a total PoE budget of 375W. and it is fully complied with
IEEE802.3af/at/bt PoE standard at maximum 90W(1-2 port) power budget. supports up
to 30W output power per PoE port, giving you power distribution flexibility for a wide
range of PoE PD devices. It helps to save infrastructure wiring costs dramatically by
eliminating electric wiring and less UPS needed.
F ront interface
Figure 1-3
Definition of operating mode switch!
Mark
Work mode
Description
Unmanaged
Unmanaged
mode
All ports communicate freely, and the parameters
configured in Web mode do not take effect
Web Smart
WEB managed
mode
The web network management function is
effective, and the switch can be managed and
configured
Indicator!
Figure 0-4
S/N
Indicator
Status
Description
①
P ower
Light on
Power on
Light off
No power
②
PoE
Light on
PoE power in
Light off
PoE without power
③
1000M
Light on
The current operating rate is 1000Mbps
Light off
The current operating rate is 10 /
100Mbps or the link is not connected
④
Link/Act
Light on
The link is connected
Light flash
The port has data transceiver
Light off
the link is not connected
List of accessories
l Master unit
l Power cord
l Quick Installation Guide
l L- shaped bracket and other
l Rubber Feet
Installation guide
For the safe installation and operation of the switch, it is recommended that you!
1. Check that the power cord is securely wrapped around the AC power connector"
2. Ensure proper heat dissipation and ventilation around the switch"
3. Do not stack heavy objects on the switch"
Mounting to rack
1. Check the grounding and stability of the frame"
2. L-Install the two shaped brackets in the accessories on both sides of the switch panel
and fix them with the screws provided in the accessories, as shown in Figure 2-1 "
3. Place the switch in the appropriate position in the rack and supported by the bracket"
Fix the L-shaped bracket on the guide grooves fixed at both ends of the rack with screws
to ensure that the switch is stably and horizontally installed on the machine, as shown in
