Sida 1/20

150m Cat.6 4x4 HDMI 4K60 HDBaseT

Matrix Extender

User Manual English

No. 8345 3

lindy.com

User Manual English

Safety Instructions

! WARNING !

Please read the following safety information carefully and always keep this document with

the product.

Failure to follow these precautions can result in serious injuries or death from electric

shock, fire or damage to the product.

This device has a switching type power supply and can work with supply voltages in the

range 100…240 VAC.

Touching the internal components or a damaged cable may cause electric shock, which may result in

death.

To reduce risk of fire, electric shocks or damage:

 Do not open the product nor its power supply. There are no user serviceable parts inside.

 Only qualified servicing personnel may carry out any repairs or maintenance.

 Never use damaged cables.

 Do not expose the product to water or places of moisture.

 Do not use this product outdoors it is intended for indoor use only.

 Do not place the product near direct heat sources. Always place it in a well ventilated place.-

 Do not place heavy items on the product or the cables.

 Please ensure any adapters are firmly secured and locked in place before inserting into a wall socket

Introduction

Thank you for purchasing the 150m Cat.6 4x4 HDMI 4K60 HDBaseT Matrix Extender. This product has

been designed to provide trouble free, reliable operation. It benefits from both a LINDY year warranty 2

and free lifetime technical support. To ensure correct use, please read this manual carefully and retain it

for future reference.

This high end- HDBaseT Matrix Extender connection for 4 HDMI sources and 4 allows the HDMI displays,

each output is mirrored to provide HDBaseT extensions up to 150m (4 HDBaseT receivers are included).

It supports resolutions up to 4K60, each HDMI output can also be downscaled to FullHD independently

while Audio can be de embedded thanks to the analog and coaxial outputs. -

IR matrix function is supported on the main unit, then IR signal follows the HDMI video channel at the

respective HDBaseT receiver end.

User can easily manage the matrix via front panel buttons with OLED screen, IR remote -control, RS 232

or TCP/IP commands and web GUI.

Package Contents

 HDMI 4K60 HDBaseT Matrix Extender

 4 x HDBaseT Receiver

 IR remote control

 RS- 232 Male to Female cable, 1.5m

 4 - x 3 Pin Terminal Block

 4 x 5- Pin Terminal Block

 5 x IR Emitter cable, 1.5m

 5 x IR Receiver cable, 1.5m

 10 x Mounting Ears with screws

 4 x mains cables IEC (EU, UK, US & AUS), 1.5m

 Lindy Manual

User Manual English

Features

 Supports resolutions up to 3840x2160@60Hz 4:4:4 8bit

 4x4 Matrix function

 4 HDMI inputs

 4 HDMI & HDBaseT mirrored outputs

 Support 4K to 1080p downscaler function on each output

 EDID management and CEC control

 Support IR matrix function

 Audio Pass-through of all HDMI audio formats including Dolby TrueHD, Dolby Digital, Dolby Digital

Plus (DD+), DTS-HD,

DTS HD- -X, HRA, DTS Master Audio, LPCM up to 7.1

 Audio de- embedded via analog and coax ports

 24V PoC (Power over Cable) function on HDBaseT ports

 Manageable via front panel buttons -with OLED display, IR remote control, RS 232 or TCP/IP

commands and Web GUI

Specification

 HDMI 2.0b, 18Gbps c ompliant

 HDCP 2.2/ - 1.4 pass through

 The following distance and resolution combinations are possible when using high quality Cat.6

U/UTP or F/UTP solid core cable:

- 150m: 1920x1080@60Hz 4:4:4 8bit

- 120m: 3840x2160@60Hz 4:4:4 8bit / 4:2:2 12bit

 Coax Audio Formats: PCM 2.0, Dolby Digital / Plus, DTS 2.0/5.1

 Analog Balanced Audio Formats: PCM 2.0CH

 SNR: >90dB

 THD+N Ratio: <0.1% ( ( ) V_max 0.001%~0.01%) V_best

 Crosstalk: > 80dB

 Frequency Response: 20Hz~20kHz ±0.5dB

 ESD Protection: ± 8kV (air- gap discharge)

 Human Body Model: ± 4kV (contact discharge)

 Operating Temperature: 0°C - - 40°C (32°F 104°F)

 Storage Temperature: - - - - 20°C 60°C ( 4°F 140°F)

 Relative Humidity: 2 - 9 - 0 0% RH (Non condensing)

 Metal Housing

 Colour: Black

 Power Requirements: AC100-240V 50/60Hz

 Power Consumption: 60W

Produktspecifikationer

Varumärke:	Lindy
Kategori:	AV förlängare
Modell:	38345
Vikt:	5310 g
Bredd:	440 mm
Djup:	200 mm
Höjd:	45 mm
Förpackningens bredd:	510 mm
Strömförsörjning:	60 W
Ljudformat som stöds:	LPCM
Videolägen som stöds:	1080p
Maximal upplösning:	3840 x 2160 pixlar
Certifiering:	California Proposition 65
HDCP:	Ja
HDR-stöd:	Ja
Material:	Metall
HDMI-version:	2.0
Modell:	Sändare och mottagare för AV-utrustning
Bandbredd:	18 Gbit/s
RJ-45 utgångsportar:	4
HDCP-version:	2.2
Antal HDMI-utgångar:	5
HDBaseT-port:	Ja
Kabeltyper som stöds:	Cat6
3,5 mm in:	Ja
Garantiperiod:	2 År
Infrarött (IR) frekvensområde:	20 - 60 kHz
Produktens färg:	Svart
bruksanvisning:	Ja
Förpackningstyp:	Låda
Låddjup:	401 mm
Vikt inkl. förpackning:	6330 g
EDID-hantering:	Ja
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Intervall för relativ operativ luftfuktighet:	20 - 90 %
Hållbarhetscertifiering:	CE, Federal Communications Commission (FCC), REACH, RoHS, UKCA
AC-inspänning:	100 - 240 V
Anslutningsteknologi:	Kabel
Strömkälla av typen:	AC
Antal ljudutgångar vänster/höger:	4
Växelström Frekvens:	50/60 hz
På / av-knapp:	Ja
Maximal överföringshastighet avstånd:	150 m
Uppfyller hållbarhetskrav:	Ja
Mottagare (B x D x H):	140 x 65 x 18 mm
Signal/brusförhållande (SNR):	90 dB
Digital koaxialutgång för ljud:	4
HDMI-in:	4
3,5 mm-utgång:	Ja
RS-232-ingångar:	2
RCA-ljudutgångar:	4
Orörd överföring av HDCP:	Ja
