Sida 1/2
Features
Comply with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3az, af/at standards
Support IEEE802.3x full-duplex flow control; support Auto MDI/MDIX
16 Ports support 48V-56VDC power to PoE powered devices
Provide 15.4W or 30W power to powered devices
2 Combo Uplink port: 10/100/1000Mbps RJ-45 or 1000Base-x optical fiber port SFP
265 watts PoE budget
PoE data & power transmission distance up to 100meters
Excellent anti-thunder, anti-static and anti-interference ability
Support 10K lenght Jumbo frame transmission
Restart function helps master IC reset whoolly
Built-in 265W power supply
Easy and convenient to use, plug & play, no need to configure
Galvanized housing for stable and durable working life
Overview
The SW-UF16P2G2SV-061 provides 16 ports 10/100Mbps IEEE 802.3af/at Power over
Ethernet with a total of 265 watts of PoE budget, which is an ideal solution to fulfill the
demand of sufficient PoE power for network applications.
The SW-UF16P2G2SV-061 is an ideal solution for securing IP surveillance infrastructure.
It provides both 802.3af/at PoE functions along with 16x10/100Base-TX ports featuring
15.4 watt 802.3af/30 watt 802.3at PoE in RJ-45 interface and extra 2-Combo uplink port:
10/100/1000Mbps RJ-45 or 1000Base-TX optical fiber port SFP port to keep a cascade
connection with another switch or NVR. For instance, one SW-UF16P2G2SV-061 ca be
combined with one 16 Channel NVR and 16 PoE IP camerras as a kit for the administra
-
tor to centrally and efficiently manage the surveillance system in the local LAN and the
remote site via internet.
With data and power over Ethernet from one unit, the SW-UF16P2G2SV-061 reduce
cabling requirements and eliminates the need for dedicated electrical outlets on the wall,
ceiling or any unreachable place. A wire that carries both data and power can lower the
installation costs, simplify the installation effortand eliminate the need for electricians or
extension cords. Providing 16 interface, the SW-UF16P2G2SV-061 is ideal for small
business and workgroups requiring deploying the PoE for the wireless access point,
IP-based surveillance IP phone in any places easily, efficiently and cost-effectively.
Front panel
1. Rack-mounting ears: Cabinets for product installation or Wall installation
2. Power Indicator: Red Light on: with power; Light off: no power
3. PoE Indicator: Yellow Light on: when device is powered
Light off: when device is not detected or not powered
4. Link/ Act Indicator: Green LED on: link up off: link down blinks: data transfer
5. Reset Button: Whole machine will restart while press button
6. Uplink SFP port: Speed 1000Base-X, transfer data from PoE ports to other devices
(NVR/Switch /ADSL)
7. Uplink Gigabit RJ45 port: Transfer data from PoE ports to other devices (NVR/Switch
/ADSL)
7. Downlink port: Transfer data from other IP devices to the switch
Rear panel
1. Input: AC 96 264V~
2. Power Switch: Turn on with power, Turn off no power
3. Waiting Content
5. Ground Connection
6. Fuse: Max 10A
visit our website
www.machpower.it
USER MANUAL SW-UF16P2G2SV-061
