Sida 1/2
Features
Comply with IEEE802.3, IEEE802.3ab, IEEE802.3u,IEEE802.3az, IEEE802.3af/at standards
Support IEEE802.3x full-duplex flow control; support Auto MDI/MDIX
8 Port support 48V-56VDC power to PoE powered devices
Provide 15.4W or 30W power to powered devices
Extra 2-Port 10/100/1000Mbps UPLINK RJ-45
120 watts PoE budget
PoE data & power transmission distance up to 100meters
Port based VLAN for Enhanced Security
Excellent anti-thunder, anti-static and anti-interference ability
Surge Protection: 6KV
Restart function helps master IC reset wholly
Easy and convenient to use, plug & play, no need to configure
Galvanized housing for stable and durable working life
Overview
The SW-UG8P2LV-059 provides 8 port 10/100/1000Mbps IEEE 802.3af/at Power over
Ethernet with a total of 120 watts of PoE budget, which is an ideal solution to fulfill the
demand of sufficient PoE power for network applications.
The SW-UG8P2LV-059 is an ideal solution for securing IP surveillance infrastructure. It
provides both 802.3af/at PoE functions along with 8 x 10/100/1000Base-TX ports
featuring 15.4 watts 802.3af/30 watts 802.3at PoE in RJ-45 interfaces and extra 2 x
10/100/1000Mbps UPLINK RJ- 45 port to keep a cascade connection with another switch
or NVR. For instance, one SW-UG8P2LV-059 can be combined with one 8 Channel NVR
and 8 PoE IP cameras as a kit for the administrators to centrally and efficiently manage
the surveillance system in the local LAN and the remote site via Internet.
With data and power over Ethernet from one unit, the SW-UG8P2LV-059 reduces cabling
requirements and eliminates the need for dedicated electrical outlets on the wall, ceiling
or any unreachable place. A wire that carries both data and power can lower the installa
-
tion costs, simplify the installation effort and eliminate the need for electricians or
extension cords. Providing 8 PoE interfaces, the SW-UG8P2LV-059 is ideal for small
businesses and workgroups requiring deploying the PoE for the wireless access points,
IP-based surveillance IP phones in any places easily, efficiently and cost-effectively.
visit our website
www.machpower.it
USER MANUAL SW-UG8P2LV-059
Front panel
1. Rack-mounting ears: Cabinets for product installation or Wall installation
2. Power indicator: Red Light on: with power; Light off: no power
3. PoE indicator: Yellow Light on: when device is powered
Light off: when device is not detected or not powered
4. Link/ Act Indicator: Green LED on: link up
Green LED off: link down
Green LED blinks: data transfer
5. Downlink Port: Transfer data from other IP devices to the switch
6.Uplink Indicator: Green LED on: link up
Green LED off: link down
Green LED blinks: data transfer
Yellow LED on: link speed is 10/100/1000Mbps
Yellow LED off: link speed is 10/100Mbps
7. Uplink Port: Transfer data from PoE ports to other devices (NVR/Switch/ADSL)
Rear panel
1. Reset button: Press the reset button to turn on indicator and the device restarts
2. Reset button indicator: Green
3. LAN Button: Turn on VLAN button: indicator on and VLAN function starts
Turn on VLAN button: indicator off and VLAN function stops
4. VLAN Indicator: Green
5. Ground Connection
6. Input: DC 48~56V
