Sida 1/4
Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 11/19/19 INST108-UNO2
INSTALLATION INSTRUCTIONS
108-UN02
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
Patent Pending
KIT FEATURES
KIT COMPONENTS
• A) Assembly mount • B) Display housing • C) Display trim ring • D) Display brackets • E) Display brackets (5-degree angle)
• F) (4) #8 x 1/2” Phillips screws • G) (4) 4mm Allen head screws
A B C D E
G
Floating Mount Kit Pioneer 8-inch
TOOLS REQUIRED
• Phillips screwdriver
• 4mm Allen head screwdriver
TABLE OF CONTENTS
Preface ....................................................................2
Kit Assembly ..........................................................3
WIRING & ANTENNA CONNECTIONS
(sold separately)
RGB Extension Cable: CD-RGB150E
(not sold by Metra)
F
The 108-UN02 is a universal mount
designed to “float” the Pioneer 8-inch
screen in front of a vehicle’s original
radio location using a series of brackets
that provide the ability to easily mount
the radio’s chassis into the radio/
pocket location of more than 250
existing Metra Double-DIN kits for 1990
to current vehicle applications.
• Engineered exclusively for the new
8-inch Pioneer
®
Modular Solutions
Receiver (DMH-C5500NEX) Radio
• A complete housing encases
the Pioneer 8-inch screen
• Patent-pending design
1.800.221.0932
|
MetraOnline.com
2
PREFACE
• The 108-UN02 is designed to work with select newer Metra dash kits (sold separately). When
assembling the dash kit, follow the instructions for an ISO DIN radio provision with pocket.
a) The 108-UN02 assembly mount will take place of the pocket provided with the dash kit.
b) The Pioneer radio chassis will take place of the aftermarket radio.
• The 108-UN02 can be installed in many different configurations to fit many applications,
and can also be customized to take adjustments even further. Careful consideration must
be taken ahead of time before assembling the kit. Items to consider are the angle of the
factory radio and dash, the depth of the radio opening, and items which may be blocked by
the radio display or interfere with it.
• The cable from the radio chassis to the radio display may not be long enough in certain
installations. It is highly recommended to purchase an RGB extension cable from Pioneer,
part number CD-RGB150E.
• Assembly mount: As laid out and shown in Kit Components, the assembly mount will
mount into the lower portion of the dash kit, and the radio chassis will mount above that.
The assembly mount can be flipped 180-degrees to allow more room above in certain
installations where upper sub-dash depth is an issue. There is also play in the mounting legs
to allow depth adjustments into the dash. New holes can also be drilled into the legs to take
this play even further if necessary.
• Display Brackets: Two different brackets are provided to compensate for different dash
angles. If the dash is angled, use the 5-degree brackets. Washers (not provided) can
also be used if more than a 5-degree angle is necessary. The brackets can also be flipped
180-degrees to allow the display screen to sit higher.
• Display Housing: When attaching the display housing to the display brackets, use the
upper mounting holes to place the display screen higher if necessary.
