Sida 1/2
Match wires below to the matching function of each wire on your receiver (refer to instructions supplied with receiver).
The wire colors of your new receiver may, or may not, match the wire colors of the adaptor. Match adaptor and receiver
wires by function, disregarding color.
Connect Black wire to Ground wire of new receiver.
Individually tape off any unused wires.
Make final wiring connections following instructions on the next page.
Receiver Wiring Adaptor
120 70-8116
Revision 01/10/11
STEP 1 -- CONNECT WIRES
Plug housings into factory harnesses in vehicle.
Before starting, compare items on your invoice with items
received. Thoroughly check packing materials. If an item
is missing, please call:
Crutchfield
*120708116*
IMPORTANT
STEP 2 -- INSTALL
White - Left Front Speaker Positive
Violet/Black - Right Rear Speaker Negative
Red - 12 Volts Switched Power
Violet - Right Rear Speaker Positive
Green - Left Rear Speaker Positive
Yellow - 12 Volts Constant Power
Gray - Right Front Speaker Positive
Gray/Black - Right Front Speaker Negative
Green/Black - Left Rear Speaker Negative
White/Black - Left Front Speaker Negative
Black - Chassis Ground
Blue - Power Antenna
Copyright 2011 Crutchfield Corporation
R
Green/White - Subwoofer Positive Coil 1
White/Red - Subwoofer Negative Coil 1
Brown/Blue - Subwoofer Negative Coil 2 Brown/Yellow - Subwoofer Positive Coil 2
Wires in this plug are illustrated as
short, but are actually 17 feet long.
Note: The subwoofer wires are not used and should be taped off for the Celica,
Camry, Highlander and Solara. The 2003-04 Avalon uses only the sub coil #1
wires. Both sets of subwoofer wires are used for the Landcruiser.
Note: In order to use the factory subwoofers, we recommend a low-power amp
(50W or less) with a low-pass crossover. Connecting these wires directly to an
aftermarket receiver's speaker leads will produce unsatisfactory results.
at 1-888-955-6000
Tools Required
Soldering
Iron
Solder
(Rosin Core
Suggested)
Electrical
Tape
Receiver Wiring Adaptor Connections
C. Solder:
1. Heat wire.
2. Touch solder to wire, not to iron.
Page 2
Tools Required
Crimp Tool/
Wire Stripper
Crimp Caps
A. Strip wires back 1/2”.
B. Twist wires together and
insert in crimp cap.
C. Squeeze middle of cap
for tight connection.
A. Strip wires back 1/2”.
B. Twist wires together.
D. Tape
CRIMP METHOD SOLDER METHOD
120 70-8116
Copyright 2011 Crutchfield Corporation
R
