Introduction
The AHRS-1 / MAG-1 is a 2 1/4” sunlight readable color display instrument providing a display for an artificial horizon
reference system (AHRS), an advanced digital compass, or both depending on which sensor packages is connected.
The AHRS-1 / MAG-1 can be setup to display the following:
•Compass with optional slip indicator (requires MGL Avionics SP-6 sensor package)
•Horizon with optional slip, turn indicator & G-Force (requires MGL Avionics SP-7/9 sensor package)
•Turn and bank indicator (requires MGL Avionics SP-7/9 sensor package)
•Combined compass and horizon display with bank indicator, optional slip indicator & G-Force (requires MGL
Avionics SP6 & SP-7/9 sensor packages)
1 Features
•Large 1.8” high resolution 160x128, sunlight readable, wide viewing angle, 1000 cd/m2 TFT LCD display
•Artificial horizon reference system (AHRS) display unit with slip indication, turn and bank and G-Force
indication
•Advanced magnetic compass with a course steering feature and slip indication
•Can be setup as an individual compass display, artificial horizon or both
•The AHRS-1 / MAG-1 is connected to the AHRS / Compass sensor packages by a simple CAN bus
interface. This allows for the optimum placement of the sensor packages in the aircraft
•More then one AHRS-1 / MAG-1 unit can be connected onto the CAN bus. This allows the compass,
artificial horizon and the turn and bank indicator to be displayed on different units
•G-Force indicator (MGL Avionics SP7 required)
•Standard 2 1/4” aircraft enclosure (can be front or rear mounted)
•Rotary control plus 2 independent buttons for easy menu navigation and user input
•An external output activates when a high alarm condition has been reached
•Wide input supply voltage range of 8 to 30V DC with built in voltage reversal and over voltage protection
for harsh electrical environments
•1 year limited warranty
Vega AHRS-1 / MAG-1
AHRS-1: Artificial Horizon and Magnetic
Compass indicator
MAG-1: Magnetic Compass Indicator
Operating Manual – English 1.00
