Setting Up Your RackLink Device

-- 2

-- 3

-- 4

IMPORTANT SAFETY INSTRUCTIONS—EN

SAVE THESE INSTRUCTIONS This manual contains important instructions that should -

be followed during installation and maintenance of the power distribution unit (PDU).

For complete safety instructions, refer to the Premium+ PDU with RackLinUser

Manual (I00826) at .-www.legrandav.com

• Only use attachments and accessories specified by the manufacturer.

• Read all instructions before using the product.

INSTRUCTIONS IMPORTANTES SUR LA SÉCURITÉ–FR

CONSERVER CES INSTRUCTIONS Ce manuel contient des instructions importantes -

qui doivent être suivies lors de linstallation et de la maintenance de unité de distribution ’

d'énergie (PDU).

Pour obtenir des instructions de sécurité complètes, reportezvous aux manuel dutilisa--’

tion Premium+ PDU with RackLinUser Manual (I00826) à .-www.legrandav.com

• Utiliser uniquement les accessoires spécifiés par le fabricant.

• Lisez toutes les instructions avant dutiliser le produit.’

Supplied Components and Hardware

After carefully opening all product packaging, identify the supplied components and hard-

ware shown. If pieces are missing or damaged, please report it immediately to Technical

Support at or (866) 9773901.av.middleatlantic.techsup[email protected]-

Keep the original packaging in a safe place for future use.

NOTE:

• To order more hardware, contact support at av.support@legrand.com or (866) 977-

3901.

• Additional hardware is included that may not be required for your installation.

• #1 Phillips Screwdriver

Required Tools

WARNING

Use tools with caution and

follow all safety protocols.

AVERTISSEMENT

Utiliser des outils avec pru-

dence et suivre tous les

protocoles de sécurité.

Supplied Components and Hardware (Continued)

NOTE: Prepare the installation site. Make sure the installation area is clean

and not exposed to extreme temperatures or humidity. Allow sufficient space

around the device for cabling and outlet connections.

1.Use #1 Phillips screwdriver and remove (2x) preinstalled -5/16”

screws from both sides of the PDU (A) as shown. ()FIGURE A

(2x)

Mounting

Bracket

C

(4x)

5/16”

Phillips

Screw

B

Power Cord

NOTE: Cord provided varies

based on model purchased.

E

Quick

Start

Guide

Cord

Retainer

D

2.Use screwdriver, (2x) removed screws, and additional (2x) screws 5/16”

(B) to attach a mounting bracket (C) to each side of the unit as shown

(4x screws pre bracket). (FIGURE B)

A

Setting Up Your RackLink Device (Continued)

FIGURE C

Rack

Screw

FIGURE A

C

FIGURE B

B

3.Attach the mounting brackets to the rack using rack screws (not provided)

as shown. ()FIGURE C

PreInstalled -

Screws

Premium+ Series PDU with RackLin

Quick Start Guide

I00827 Rev D-

Rackmount

Unit

NOTE: Form factor

and outlet type vary

based on model

purchased.

A
