Sida 1/19

EN - English -Quick Guide

EN - English -Quick GuideEN - English -Quick Guide:

This Quick Guide covers the model: CCR2004-16G-2S+PC.

This is a Network Device. You can find the product model name on the case label (ID).

Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um

The most important technical specifications for this product can be found on the last page of this Quick Guide.

Technical specifications, Full EU Declaration of Conformity, brochures, and more info about products at https://mikrotik.com/products

Configuration manual for software in your language with additional information can be found athttps://mt.lv/help

MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants

First steps:

First steps:First steps:

Connect with your PC to the Ethernet15 port.

Connect the device to a power source.

Set your IP for PC to 192.168.88.2/24

Use Web browser or WinBox to connect to the default IP address of 192.168.88.1, with the username:

admin

and no password .

In case IP is not available then use WinBox and connect with the MAC address.

Update the device by clicking the (Check_for_updates) button to the latest RouterOS software for this to work the device needs to have an active Internet

connection.

To manually update the device without public IP, go to our download pagehttps://mikrotik.com/download

Choose your architecture based on your device model under (System/Resources) and download the latest packages from a stable channel to your PC.

Open WinBox and upload packages in the (Files) menu.

Reboot the device.

Set up your password to secure the device.

Safety Information:

Safety Information:Safety Information:

Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents. The installer should be familiar with network structures, terms, and concepts.

Use only the power supply and accessories approved by the manufacturer, which can be found in the original packaging of this product.

This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the

Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.

This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own

risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate

measures

Manufacturer: Mikrotikls SIA, Unijas 2, Riga, Latvia, LV1039.

Note:

Note:Note:For some models, check the user and wireless passwords on the sticker.

BG - Български. Бързо ръководство

BG - Български. Бързо ръководствоBG - Български. Бързо ръководство:

Това бързо ръководство обхваща модела: CCR2004-16G-2S+PC.



Това е мрежово устройство. Можете да намерите името на модела на продукта на етикета на регистъра (ID).

Моля, посетете страницата с ръководството за потребителя на за пълното актуализирано ръководство за употреба.https://mt.lv/um-bg

Или сканирайте QR кода с мобилния си телефон.

Най-важните технически спецификации за този продукт могат да бъдат намерени на последната страница на това Кратко ръководство.

Технически спецификации, пълна ЕС декларация за съответствие, брошури и повече информация за продуктите на https://mikrotik.com

/products

Ръководство за конфигуриране на софтуер на вашия език с допълнителна информация можете да намерите на https://mt.lv/help-bg

Устройствата MikroTik са за професионална употреба. Ако нямате квалификация, моля, потърсете консултантhttps://mikrotik.com/consultants

Първи стъпки:

Първи стъпки:Първи стъпки:

This device needs to be upgraded to v7.10 or the latest software version to ensure compliance with local authority regulations!

It is the end user's responsibility to follow local country regulations. All MikroTik devices must be professionally installed.

Това устройство трябва да бъде надстроено до най-новата версия v7.10 на софтуера, за да се гарантира спазването на местните наредби!

Крайните потребители са отговорни за спазването на местните разпоредби. Всички устройства на MikroTik трябва да бъдат инсталирани

професионално.

Produktspecifikationer

Varumärke:	Mikrotik
Kategori:	Router
Modell:	CCR2004-16G-2S+PC
Bredd:	272 mm
Djup:	195 mm
Höjd:	44 mm
Internminne:	4 MB
Flashminne:	128 MB
Medeltid mellan fel (MTBF):	200000 h
Produktens färg:	Vit
Typ av ethernet-gränssnitt:	Snabb Ethernet
Antal LAN (RJ-45) anslutningar:	16
Strömförbrukning (vanlig):	36 W
Temperatur vid drift:	-20 - 60 ° C
Antal SFP+-modulplatser:	2
