Sida 1/19

EN - English -Quick Guide

EN - English -Quick GuideEN - English -Quick Guide:

This Quick Guide covers the model: CCR2116-12G-4S+.

This is a network device. You can find the product model name on the case label (ID).

Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um

The most relevant technical specifications for this product can be found on the last page of this Quick Guide.

Technical specifications, Full EU Declaration of Conformity, brochures, and more info about products at https://mikrotik.com/products

Configuration manual for software in your language with additional information can be found athttps://mt.lv/help

MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants

First steps:

First steps:First steps:

Connect your PC to the Ethernet1 port;

Connect the device to a power source;

Configure the IP settings of your network card to 192.168.88.2/24;

Configuration should be made using Webfig in a web browser or the WinBox configuration tool ;https://mt.lv/winbox

Open in a web browser to start setup. If the IP address is unavailable, use Winbox and choose the "Neighbors" tab to find the device. http://192.168.88.1

Proceed to connect using the MAC address. The username is "admin", and there is no password (or, for some models, check user and wireless passwords on

the sticker);

For a manual update, visit the products page at to find your product. The required packages are accessible under the https://mikrotik.com/products

"Support&Downloads" menu;

Upload downloaded packages to the Webfig or Winbox "Files" menu and reboot the device;

By upgrading your RouterOS software to the latest version, you can ensure optimal performance, stability, and security updates;

Set up your router password.

Safety Information:

Safety Information:Safety Information:

Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents. The installer should be familiar with network structures, terms, and concepts.

Use only the power supply and accessories approved by the manufacturer, which can be found in the original packaging of this product.

This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the

Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.

This product is intended to be installed indoors. Keep this product away from water, fire, humidity, or hot environments.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own

risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.

This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate

measures.

To avoid contamination of the environment, separate the device from household waste and dispose of it in a safe manner, for example, in designated areas.

Become familiar with procedures for properly transporting the equipment to designated collection points in your area.

Electric shock hazard. This equipment is to be serviced by trained personnel only

Manufacturer: Mikrotikls SIA, Unijas 2, Riga, Latvia, LV1039.

This device needs to be upgraded to RouterOS v7.10.1 or the latest version to ensure compliance with local authority regulations!

It is the end users' responsibility to follow local country regulations. All MikroTik devices must be professionally installed.

Produktspecifikationer

Varumärke:	Mikrotik
Kategori:	Router
Modell:	CCR2116-12G-4S+
Processorfrekvens:	2000 MHz
SIM-kortplats:	Nej
Ethernet WAN:	Ja
Medeltid mellan fel (MTBF):	200000 h
DSL WAN:	Nej
Produktens färg:	Vit
Inbyggd processor:	Ja
Typ av ethernet-gränssnitt:	Gigabit Ethernet
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Antal LAN (RJ-45) anslutningar:	13
Strömförbrukning (vanlig):	72 W
Temperatur vid drift:	-20 - 60 ° C
Hållbarhetscertifiering:	CE, RoHS
Typ av internminne:	DDR4
AC-inspänning:	100 - 240 V
Antal installerade SFP+-moduler:	4
Temperaturbevakning:	Ja
