EN - English -Quick Guide

EN - English -Quick GuideEN - English -Quick Guide:

This "mANTBox 52 15s" series Quick Guide covers models:RBD22UGS-5HPacD2HnD-15S (mANTBox 52 15s).

This is a wireless network device. You can find the product model name on the case label (ID).

Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um

Technical specifications, brochures, and more info about products at https://mikrotik.com/products

The most important technical specifications for this product can be found on the last page of this Quick Guide.

Configuration manual for software in your language with additional information can be found athttps://mt.lv/help

If you need help with configuration, please seek a consultanthttps://mikrotik.com/consultants

Depending on the antenna used, you must set its gain and set the installation setting to 'Outdoor'. This is to ensure that EIRP meets the limit set by the local

authorities. This is done in the Quickset, CPE menu.

First steps:

First steps:First steps:

Open the cover;

Connect Ethernet cable from your computer to the Ethernet port;

Plug the device into the power source;

Download WinBox configuration tool ;https://mt.lv/winbox

Default IP: 192.168.88.1, user name: and there is no password, or use

admin

Neighborstab and connect through MAC address(or, for some models, check

user and wireless passwords on the sticker);

Once connected configure the device, so it has an active Internet connection ;https://mt.lv/configuration

Upgrade the RouterOS software to the latest version ;https://mt.lv/upgrade

Connect again and in the QuickSet menu choose your country, to apply country regulation settings;

Set the antenna gain, depending on the antenna used;

set the installation setting to 'Outdoor';

Set up your wireless network password, the password must be at least eight symbols;

Set up your router password in the bottom field to the right and repeat it, it will be used to log in next time.

Safety Information:

Safety Information:Safety Information:

Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing

accidents. The installer should be familiar with network structures, terms, and concepts.

Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.

This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the

Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.

This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the

correct hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system.

We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own

risk!

In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.

This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate

measures!

This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an

Exposu

ExposuExposure

re re to

to to Ra

RaRadio

dio

dio dio Freque

Freque

FrequeFrequency

ncy

ncy ncy Radiati

Radiati

RadiatiRadiation:

on:

on:on:

uncontrolled environment.This MikroTik device should be installed and operated no closer than 25 centimeters from your body, occupational user, or the general

public.

Manufacturer: Mikrotikls SIA, Brivibas gatve 214i Riga, Latvia, LV1039.

Note:

Note:Note:For some models, check the user and wireless passwords on the sticker.

BG - Български. Бързо ръководство

BG - Български. Бързо ръководствоBG - Български. Бързо ръководство:

Това бързо ръководство за серията "mANTBox 52 15s" обхваща модели:

RBD22UGS-5HPacD2HnD-15S (mANTBox 52 15s).



Това е устройство за безжична мрежа. Можете да намерите името на модела на продукта на етикета на регистъра (ID).

Моля, посетете страницата с ръководството за потребителя на за пълното актуализирано ръководство за употреба.https://mt.lv/um-bg

Или сканирайте QR кода с мобилния си телефон.

Технически спецификации, брошури и повече информация за продуктите наhttps://mikrotik.com/products

Най-важните технически спецификации за този продукт могат да бъдат намерени на последната страница на това Кратко ръководство.

Ръководство за конфигуриране на софтуер на вашия език с допълнителна информация можете да намерите на https://mt.lv/help-bg

Ако имате нужда от помощ при конфигуриране, моля, потърсете консултант https://mikrotik.com/consultants

This device needs to be upgraded to RouterOS v7.3.1 or the latest stable version, to ensure compliance with local authority regulations!

It is the end users' responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling

requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be installed according to instructions.

Това устройство трябва да бъде надстроено до RouterOS v7.3.1 или най-новата стабилна версия, за да се гарантира спазването на местните

наредби!

Крайните потребители са задължени да следват местните разпоредби, включително работа в рамките на законни честотни канали, изходна

мощност, изисквания за окабеляване и изисквания за динамичен избор на честота (DFS).Всички радиоустройства MikroTik трябва да бъдат

инсталирани съгласно инструкциите.

Produktspecifikationer

Varumärke:	Mikrotik
Kategori:	accesspunkt
Modell:	mANTBox 52 15s
Bredd:	348 mm
Djup:	140 mm
Höjd:	82 mm
Frekvensband:	2.4/5 GHz
Strömförbrukning (max):	21 W
Montage:	Stav
Antal per förpackning:	1 styck
Temperatur vid drift:	-30 - 70 ° C
Antenn ökningsnivå (max):	15 dBi
Kommunikationsstandarder:	IEEE 802.11b, IEEE 802.11g
Harmonized System (HS)-kod:	85177100
Antenntyp:	Sektorantenn
Polarisation:	Dubbelpolarisering
