TECHNICAL MANUAL GS 3x.10 KNX – ENGLISH

Technical manual GS 3x.10 knx

Application description – air quality sensor & control

General Information

The device fits for the particular use of the following tasks: monitoring of the air quality in building systems technology (schools, offices, hotels, conference venue etc.), data

transfer and regulation via bus system. The device is intended for use in accordance with the defined technical data. Operate the device exclusively in a dry room! The device is

not qualified for security relevant tasks such as emergency doors, fire protection equipment, fermenting cellars etc.

The air quality sensor GS 3x.10 knx can provide the following data and control for the KNX bus:

Please consider that handling and installation of the device is explained in the instruction manual enclosed to the product!

Please take into account the resolution of the 2 Bytes data type (see KNX Specification)!

Relative humidity: Value output

Control (step and PI control)

Temperature: Value output

Control heating / cooling (2-point and PI control)

Alarms

Dew point: Value output

Alarm

Air pressure: Value output

GS 30.10 knx

GS 31.10 knx

TECHNICAL MANUAL GS 3x.10 KNX – ENGLISH

Table of contents

General Information ......................................................................................................................................................................................................................................................................................... 1

Application program ........................................................................................................................................................................................................................................................................................ 3

Technische Daten ..................................................................................................................................................................................................................................... Fehler! Textmarke nicht definiert.

Overview parameters ...................................................................................................................................................................................................................................................................................... 4

Communication objects ................................................................................................................................................................................................................................................................................... 5

Communication flags ..................................................................................................................................................................................................................................................................................... 17

1. Global Settings ................................................................................................................................................................................................................................................................................... 19

2. Relative humidity sensor ..................................................................................................................................................................................................................................................................... 20

3. Relative humidity control ..................................................................................................................................................................................................................................................................... 21

3.1 Switching commands and priority relative humidity control – Threshold 1 / 2 / 3 ................................................................................................................................................................................ 22

3.2 PI control for relative humidity ............................................................................................................................................................................................................................................................. 23

4. Temperature Sensor ........................................................................................................................................................................................................................................................................... 24

5. Temperature Alarme ........................................................................................................................................................................................................................................................................... 25

6. Temperature control ............................................................................................................................................................................................................................................................................ 26

6.1 Temperature control – heating and cooling ......................................................................................................................................................................................................................................... 26

6.2 Temperature control – General ........................................................................................................................................................................................................................................................... 27

6.3 Temperature control – Set points ........................................................................................................................................................................................................................................................ 28

6.4 Temperature control – Main level and extra level heating / cooling .................................................................................................................................................................................................... 29

7. Dew point Temperature ...................................................................................................................................................................................................................................................................... 30

8. Dew point Alarm ................................................................................................................................................................................................................................................................................. 31

9. Air pressure sensor ............................................................................................................................................................................................................................................................................. 32

10. VAV control ......................................................................................................................................................................................................................................................................................... 33

11. Inputs .................................................................................................................................................................................................................................................................................................. 34

11.1 General ........................................................................................................................................................................................................................................................................................... 34

11.2 E1 – E5 General ............................................................................................................................................................................................................................................................................. 35

11.2.1 E1 – E5 as binary inputs ................................................................................................................................................................................................................................................................. 36

11.2.1.1 Switching/Alarm function ............................................................................................................................................................................................................................................................ 36

11.2.1.2 Dimming ..................................................................................................................................................................................................................................................................................... 38

11.2.1.3 Blind sensor ............................................................................................................................................................................................................................................................................... 39

11.2.1.4 Value / forced operation ............................................................................................................................................................................................................................................................. 40

11.2.1.5 Scene ......................................................................................................................................................................................................................................................................................... 42

11.2.1.6 Switching sequences ................................................................................................................................................................................................................................................................. 43

11.2.1.7 Multiple operation ....................................................................................................................................................................................................................................................................... 44

11.2.1.8 Pulse counter ............................................................................................................................................................................................................................................................................. 45

11.2.1.8.1. Intermediate counter (with function pulse counter) ................................................................................................................................................................................................................ 46

11.2.2 Function analogue input (Only available at input E1) ..................................................................................................................................................................................................................... 47

11.2.2.1 E1 Voltage ................................................................................................................................................................................................................................................................................. 47

11.2.2.2 E1 Output ................................................................................................................................................................................................................................................................................... 48

11.2.2.3 E1 Threshold value .................................................................................................................................................................................................................................................................... 49

11.2.2.4 E1 Output threshold value .......................................................................................................................................................................................................................................................... 50

11.2.3 Function external Temperature sensor (input E4/5 only) ................................................................................................................................................................................................................ 51

11.2.3.1 E4 General ................................................................................................................................................................................................................................................................................. 51

11.2.3.2 E4/5 External temperature sensor / floor heating thermal limiter ............................................................................................................................................................................................... 52

11.2.3.3 E4/5 Output ................................................................................................................................................................................................................................................................................ 53

11.2.3.4 E4/5 Threshold value 1 / 2 (only if E4 General  temperature function = Temperature) ........................................................................................................................................................... 54

11.2.3.5 E4/5 Output threshold value 1 / 2 (only if E4 general  temperature function = Temperature) ................................................................................................................................................. 55

11.2.3.6 E4/5 Threshold values (only if E4 general  temperature function = Floor heating thermal limiter) .......................................................................................................................................... 55
