Sida 1/2
© MuxLab Inc. 2018 94-000825-B SE-000825-B
2321 Cohen St, Montreal, QC Canada H4R 2N7
Tel: (514) 905-0588 Fax: (514) 905-0589
Toll Free (North America): (877) 689-5228
E-mail: info@muxlab.com URL: www.muxlab.com
Specifications
Environment
HDMI 2.0a
Devices
Ultra HD Blu-Ray, projectors, monitors, TV, PC, laptops.
Transmission
Transparent to the user.
Video Bandwidth
18 Gbps
Frequency Range
25 to 600 MHz
Signals
HDMI 2.0a protocol.
HDCP
Revision 1.4 & 2.2 compliant.
Connectors
HDMI receptacle.
Dip Switch
For setting the EDID to be sent to the source (pins: 2, 3 and 4).
(Note: Pin 1 is used to select between normal operation and firmware updates via
the USB service port.)
LEDs
Power: Blue
Input & Output Link: Green
Resolution
480i to 1080p @ 50/60 FPS
1080p @ 24/50/60 FPS
3840 X 2160 @ 24/25/30/60 FPS
Color
8, 10 & 12 bit
Audio
LPCM 7.1CH, Dolby TrueHD, Dolby Atmos, DTS-HD Master
Audio and DTS:X
Cable
HDMI cable of appropriate length for video resolution selected.
Power Supply
One (1) 110-240V/5VDC , 4A power supply
Temperature
Operating: 0° to 40°C Storage: -20° to 60°C
Humidity: up to 90% non-condensing
Enclosure
Metal enclosure
Bracket
Included
Dimensions
9.53” x 3.82” x 1.00” (242 mm x 97 mm x 25 mm)
Weight
3.2 lbs (1.45 Kg)
Compliance
Regulatory: FCC, CE, RoHS
Warranty
2 years
Order Information
500427 HDMI 1X8 Splitter, 4K/60 (UPC: 627699004272)
HDMI 1X8 Splitter, 4K/60 (500427)
Quick Installation Guide
Overview
The HDMI 1x8 Splitter (500427) allows one (1) HDMI source to be distributed to
up to eight (8) HDMI displays. The splitter supports up to 4K (3840 X 2160)
video, HDR and HD audio. The splitter is HDCP 1.4 & 2.2 compliant, supports
EDID management and features LED diagnostics. Each output supports an
independent down-scaler from 4K to 1080p, depending on the connected display.
Additionally, all connectors are on the rear panel for neater cabling. Applications
include; commercial and residential AV systems, classroom projector systems,
digital signage, boardroom systems, collaborative PC systems, medical information
systems.
Pre-Installation Check
Identify the connectors as indicated on the product diagram above. LEDs are
located on the front and the connectors and mode switch on the rear.
