IR Emitter (500998)
© MuxLab Inc. 2015 500998
MuxLab Inc. | 8495 Dalton Road, Mount Royal, Quebec, Canada, H4T 1V5
Tel: (514) 905 0588 |Fax: (514) 905 0589 | Toll Free:1 877 689- 5228
E-mail: | [email protected]www.muxlab.com
Overview:
The IR Emitter (500998) works in conjunction with
MuxLab products to support IR source control
between the AV source and the AV display. The
500998 connects to an active balun transmitter.
The IR Sensor (500999) is the complementary
product that connects to the active balun receiver.
The handheld remote control is not included.
Key Features:
Suitable for IR data format: NEC code, RC5 code, RC6
code, Grunding code, RCA Code, Zenith code and Sony
12-bit code.
Carrier frequency: 38 kHz
Specications
Environment
Infra-red (IR) control
Devices
TV Sets, STB, DVD, DVR, PVR, satellite receivers.
Works with MuxLab P/Ns
500145, 500405, 500406, 500415, 500416, 500418, 500419, 500420, 500450,
500451, 500453, 500454, 500456, 500460, 500468, 500469, 500600
Transmission
Transparent to the user
IR data format supported
NEC code, RC5 code, RC6 code, Grunding code, RCA Code, Zenith code and
Sony 12-bit code
Frequency
38 K Hz
IR Wavelength
940 nm
Connectors
3.5mm (mono) plug
Temperature
Operating: 0° to 40°C Storage: -10° to 70°C
Humidity: up to 95% non-condensing
Enclosure
Dark purple epoxy resin
Dimensions
0.790.955 mm x mm x 13 mm) ” x ” x 0.1” (2024with 71” (1.8m) cable
Weight
0.64 oz. (18 gms )
Compliance
RoHS
Warranty
2 years
Order Information
500998 IR Emitter (UPC: 627699009987)
Typical Application:
