Sida 1/2
© MuxLab Inc. 2020 -000940-A - 09 -A94 SE 00 40
2321 Rue Cohen, Montreal, Quebec, Canada. H4R 2N7
Tel: (514) 9 -0588 Fax: (514) 905-0589 05
Toll Free (North America): (877) 689-5228
E-mail: URL: www.muxlab.com
info@muxlab.com
Specications
Environment
HDMI 1.3
Devices
Computers, Game Consoles TV Set Top Box, es and other HDMI
sources
Transmission
Transparent to the user
Bandwidth
148 MHz
Signals
HDMI 1.3 protocol and HDCP 1.4
Connectors
Cables not included.
Two (2) HDMI receptacles.
One (1) USB Type A Connector.
Two (2) 3.5mm jacks for Microphone and Headphone.
Supported HDMI
Resolution
720x480p(60), 720x576p(50), 1280x720p(50), 1280x (60), 720p
1920x1080i(50),1920x1080i(60), 1920x1080p(24),
1920x1080p(25),1920x (30), 1920x1080p(50), 1920x1080p 1080p(60)
Recording Resolution
720x480p(60), 720x576p(50), 1280x720p(50), 1280x (60), 720p
1920x1080i(50), 1920x1080i(60), 1920x1080p(24), 1920x1080p(25),
1920x1080p(30)
Audio Signal
Up to16bit 48KHz dual channel (via HDMI input interface) and 3.5mm
analog audio input
Recording Format
Video: MP4, Audio: AAC Stereo
Coding Format
H.264 (Video) and AAC (Audio)
Recording Quality
Highest: 16Mbps@ /30 1080p
Maximum Storage
Capacity
USB Flash Drive (≤64G), Mobile Hard Disk (≤2TB)
Power Supply
One (1) 110-240V/ VDC power supplies 12
Temperature
Operating: 0° to 40°C Storage: -20° to 85°C
Humidity: Up to 95% non-condensing
Enclosure
Metal
Dimensions
4.8” x ” x 2.9 0.6” (12.20 x 7. 1.5 cm) 37 x
Weight
0.6 lbs (0. kg) 27
Compliance
Regulatory: FCC, CE, RoHS Flammability: 94V0
Warranty
1 year
Order Information
1 5 Video Capture & Recorder 00 12
Video Capture and Recorder (1005 ) 12
Quick Installation Guide
Overview
The Video Capture and Recorder (100512) allows the user to record from HDMI video
sources to a USB Flash Drive or Removable Hard Drive. High denition video
recording does not require a computer and can be recorded from a variety of HDMI
source equipment like Computers, Game Consoles TV S Top B and other , et oxes,
sources.
The maximum input resolution supported is 1080p/60 and the maximum recording
resolution is 1080p/30. The unit supports microphone mixing, recording and a
headphone output.
Operation is as easy as placing the device between an HDMI source and an optional
display and simply pressing a button to start recording.
Applications
Applications include home video recording, video game capture, security and trac
recording education/classroom systems, and medical systems. ,
Installation
1. Identify the connectors on the product as indicated on the product labels.
2. Connect the source to the HDMI Input of the Recorder.
3. Connect the Display to the HDMI Output of the Recorder
4. Connect a microphone to the 3.5mm Microphone input of the recorder. The
microphone audio will be mixed with the HDMI Audio.
5. Connect an Audio Headphone to the 3.5mm Headset output of the recorder.
6. Insert a USB Flash Drive or removable hard drive to the USB Connector of the
Recorder. e recorder supports FAT32 and NTFS Formats If the drive is Th .
© MuxLab Inc. 2020
formatted in F 32 the video will be automatically split in 2GB le se ents AT gm
because of the limitation of F Formatting the drive in NTFS not AT32. does
split the video le.
7. Power up the unit by connecting the Power Supp to the unit rst and then to ly
the AC wall outlet.
8. Quickly press the REC Button to select the recording resolution of 1080p or
720p.
9. Press and hold the REC Button for 3 seconds to start the recording. The
recording is started when the bottom LED line scrolls from left to right.
10. To stop the recording, press and hold the REC button for 3 seconds. The
recording is stopped when the bottom line ashes for 2 seconds .
Recording Resolution
Television 1080p
Television 720p
Signal Sources
Resolution
Record Resolution
Signal Sources
Resolution
Record
Resolution
1080p/i(60)
1080p(30)
1080p/i(60)
720p(60)
1080p/i(50)
1080p(25)
1080p/i(50)
720p(50)
1080p(59)
1080p(29.97)
1080p(59)
720p(59.94)
1080p/i(30)
1080p(30)
1080p/i(30)
720p(30)
1080p/i(25)
1080p(25)
1080p/l(25)
720p(25)
1080p(29)
1080p(29.97)
1080p(29)
720p(29.97)
1080p(24)
1080p(24)
1080p(24)
720p(24)
1080p(23)
1080p(23.98)
1080p(23)
720p(23.98)
1080i(29)
1080p(14.99)
1080i(29)
720p(29.97)
1680xl050x60 or
1600xl024x60 or
1600x900x60
1680x1050x30
1680x1050x60 or
1600x1024x60 or
1600x900x60
720p(60)
1400x900x60 or
1366x768x60 or
1360x765x60
1400x900x30
1400x900x60 or
1366x768x60 or
1360x765x60
720p(60)
1280x1024x60
1280x1024x30
1280x1024x60
720p(60)
1280x960x60 or
1280x800x60 or
1280x768x60 or
1152x864x60
1280x960x30
1280x960x60 or
1280x800x60 or
1280x768x60 or
1152x864x60
720p(60)
1280x720x60
720p(60)
1280x720x60
None
1280x720x59
720p(59.94)
1280x720x59
None
1280x720x50
720p(50)
1280x720x50
None
1152x674x60
720p(60)
1152x674x60
None
1024x768x60
720p(60)
1024x768x60
None
Troubleshooting
The following table describes some of the symptoms, probable causes and possible solutions
in regard to the installation of the Video Capture and Recorder:
Symptom
Probable Cause
Possible Solutions
No Image
No power
• Check power connections.
No Image
HDMI Cable
• Check the HDMI Cable.
No Image
Synchronization
• Check HDMI cable length.
Flickering Image
Synchronization
• Check HDMI cable length.
• Check the HDMI Cable Quality.
Choppy sound
Synchronization
• Check HDMI cable length.
• Check the HDMI Cable Quality.
Green or pink hue
DDC communication
• Power-cycle the HDMI Recorder.
Cannot record
Storage Problem
• Check that the storage is formatted as FAT32
or NTFS.
Cannot record
Storage Problem
• Check that the storage is not full.
Recorded Video not
Working
Storage corrupted
• To avoid corrupting the USB Storage, unplug
the power rst before disconnecting or
connecting the USB Storage.
Cannot record
Computer Video and/or
Audio
Computer congured in
extended mode
• Choose video duplicate mode (Win+P) and for
the audio select the recording unit for playback.
Microphone not heard
Microphone problem
• Check the microphone connection.
If you still cannot diagnose the problem, please call MuxLab Customer Technical Support at
877-689-5228 (toll-free in North America) or (+1) 514-905-0588 (International).
