Sida 1/9
MOST-AUX
Fiber-optic AUX input for select MOST vehicles
NTV-KIT001/002/007/008/143/151/152
BHM
01/26/15
NTV-DOC006
3950 NW 120
th
Ave, Coral Springs, FL 33065 TEL 561-955-9770 FAX 561-955-9760
I N T E R F A C E
BHM
01/26/15
NTV-DOC006
rB7
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
2 | P a g e
The NAV-TV MOST AUX module is a M.O.S.T. fiber optic auxiliary audio input interface that
introduces audio into select MOST fiber optic equipped vehicle with no degradation in sound
quality. There are TWO HARDWARE PLATFORMS: TYPE 1 & TYPE 2 THAT ARE NOT
INTERCHANGEABLE. Although you cannot use a Type 1 hardware in a Type 2 vehicle (and vice
versa), the software coding and installation is the same for both. The following chart lists
compatible vehicles and platforms:
Vehicle
Compatible Interface
Hardware TYPE
Manual Page
Aston Martin
MOST-AUX Aston
1
4
Audi
MOST-AUX Audi
1
5
BMW
MOST-AUX BMW
1
5 & 6
Mercedes
MOST-AUX MB
1
7
Porsche
MOST-AUX POR
1
8 & 9
Jaguar
MOST-AUX JAG
2
6
Land/Range Rover
MOST-AUX RR
2
7
Volvo
MOST-AUX Volvo
2
9
This module can be installed in any position within the fiber optic loop.
Kit Contents
Overview
MOST AUX module
NTV-ASY149
Power/RCA
Harness
NTV-ASY012
Fiber optic cable
NTV-ASY03
MOST Bypass (MB only)
NTV-CON001
USB cable
NTV-CAB009
BHM
01/26/15
NTV-DOC006
rB7
Agreement: End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for
misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is
intended for off-road use and passenger entertainment only.
3 | P a g e
Installation Overview (ALL vehicles)
- Black wire: Connect to chassis ground.
- Red wire: Connect to 12v Constant
- Blue wire: Supply 12v + (through a toggle switch) to
activate AUX input
- Fiber optic cable configuration (see diagram at right):
General Install notes:
- Do not grab power from the CD Changer’s power harness.
- Grabbing power from the radio’s harness may cause problems as well.
MOST AUX Note: For most vehicles, this kit will work right out of the box. However, some
vehicles will require setup adjustments via the USB and the Nav-TV USB updater program. The
following 7 pages will cover the qualifications and setup walk-throughs for each car, if
necessary.
Installation of the Nav-TV USB Updater:
Using Windows XP or Windows 7:
1) Download the device driver form navtv.com>support>downloads at the top of the screen in
BLUE that says updated driver and save it to A NEW FOLDER ON THE DESKTOP. .
2) Install the driver. It will ask you if you want to update the driver during installation. Click yes
and proceed through all installation steps. If prompted to restart the computer do so at this
time. If not proceed to 3.
3) Download and unzip the proper file packet for the corresponding NAV-TV product (follow the
exact same directions you would follow if the computer did not have DEI© software on it)
4) Launch the USB Updater program and plug in the NAV-TV device to an available USB port.
5) If it recognizes right away you are done. If not, proceed to step 6.
MOST-AUX MB: This specific kit (only) will include a fiber
optic bypass loop. In this car, the CD changer MUST be
bypassed for the MOST-AUX to function properly.
Before
After
Factory MOST
Fiber Optic cable
Supplied NAV-TV
MOST-AUX Fiber
