Sida 1/6

BHM

01/07/13

NTV-DOC158

Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for :

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

1 | P a g e

3950 NW 120th Ave, Coral Springs, FL 33 TEL 561-955-9770 FAX 561-955-9760 065

www.nav-tv.com info@nav-tv.com

GVIF- RR

NTV-KIT 167

Overview

The GVIF- Kit allows the user to add up to 3 video inputs and a backup camera input to the RR

factory media screen in select Range Rover (LR3/HSE) vehicles. This kit has a dedicated rear

view camera input, 3 composite (RCA) audio/video inputs, an RGB input and an AV output with

AV switching.

Kit Contents

AV Input Harness

Power/CAN Harness

LVDS Video cable

GVIF- Interface RR

Remote

RGB Input cable

Input Toggle Switch

IR Eye Harness

BHM

01/07/13

NTV-DOC158

Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for :

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

2 | P a g e

Interface Connectors

Dip Switch Sengs* Congure prior to installaon

Dip SW:

Enables

RGB

Enables

Land Rover

Aermarket

NAV

Factory or

no Rev-Cam

N/A

DOWN

Skips

RGB

Skips

Lexus

Factory

NAV

Acvates

aermarket

Rev-Cam

N/A

AV IN/OUT

Power/CAN

Dip Switches

Status LEDs

*Note: If the dip switches are not congured prior to

installaon you must remove power to the unit prior to

making adjustments to the dip switches. When power is

reconnected aer the dip switch adjustment the new

sengs will be stored into memory.

LCD IN/OUT

(LVDS Cable)

BHM

01/07/13

NTV-DOC158

Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for :

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

3 | P a g e

Installaon

THIS INTERFACE INSTALLS AT THE NAV DRIVE UNDER THE SEAT AT THE SCREEN , NOT !

1. Locate the factory NAV drive under the driver/passenger seat.

2. Gather the provided from the GVIF-RR kit. Connect the following ‘Power/CAN Harness’

wires to the car:

Note: CAN connecon is not supported at this me. You must connect the GRAY wire

to a reverse lamp for reverse acvaon!

3. Disconnect the factory LVDS cable from the NAV drive, this is oen a black or blue

connector.

4. Connect the provided LVDS male side (labeled ‘LRIN’) of the

video cable to the factory NAV drive. Be certain you’re inserng

this connector properly, it is keyed but it may sll be ght!

5. Connect the free end (removed in step 3) of the factory video cable to the female side of

the provided LVDS video cable (labeled ‘LROUT’).

6. Connect the white end of the LVDS video cable to the interface at the port labeled ‘LVDS

IN/OUT’ Note: If aer installaon you receive a ‘NAV NOT AVAILABLE’ message, the .

LVDS cables may not be seated fully.

7. Connect the AV Input cable to the port on the GVIF- interface labeled RR ‘AV IN/OUT’. If

you’re only connecng a reverse camera (and no other

inputs), the signal input from the camera must connect

to the RCA labeled . Refer to the dip-‘REAR-C’

switch sengs chart to skip/enable AV sources

upon toggle switch presses (oponal. Page 2 ).

8. Adjust dip switches on the GVIF-RR interface properly, refer to the chart on page 2 for

qualicaons.

9. Connect the white plug from the to the port on the GVIF-‘Power/CAN Harness’ RR

interface labeled ‘Power/CAN/RGB’.

10. Mount the interface down where it will not interfere with seat movement or passengers

feet.

Interface wires

Connect to car

Black (GND)

Chassis Ground

Red (ACC)

Accessory

Gray (Rear)

Reverse lamp 12v (+)
