Sida 1/30
Portable Smart Tire Inflator
PAAC10BK
B
C
D
1
7
8
9
e
2
3
5
4
6
q
w
r t
y u i
A
a
Quick start guide
Portable Smart Tire Inator
PAAC10BK
For more information see the extended manual online:
ned.is/paac10bk
Thank you for purchasing the rechargeable air compressor. Please read this
user manual carefully before using this product , and keep it, as well as the
packaging, for future reference.
1. Packing list
1 x Smart air pump
1 x Flexible hose (US standard connector)
1 x French standard adapter
1 x Dunlop valve adapter
1 x Ball needle
1 x Nozzle for swimming ring
1 x Type-C cable
1 x Carrying pouch
2. Specication
Product name: Rechargeable Air Compressor
Product model: PAAC10BK
Product size: 157*64*44mm
Weight: 420g
Ination pressure: 10.3 bar (max)
No-load ow: 15-18L/min
Working temperature: -10° ~ 45°C
Battery capacity: 14.8Wh
Charging input: 5V/2A
Charging time: 2~3h
3. Illustration (image A)
1 LED light
2 Hose connector
3 Type-c charging port
4 Unit
5 Measured pressure
6 Mode
7 Battery level
8 LED torch unit switch
9 Preset −
q Power on/o
w Preset +
e Application scenario
4. How to use
4.1 Charging Method (image B)
r
Green light: 60~100%
t
Red light: 0~30%
The USB charger is recommended to use 5V / 2A. Use the Type-C charging cable
to connect the air pump and power adapter (sold separately) for charging.
Charging status: battery indicator ashes.
Full state: the battery indicator is green and does not ash. The product
cannot be used during charging.
4.2 Power On/O
Switch on When starting, press the power button for 3 seconds.
Shutdown When shutting down, press the power button for 3 seconds.
4.3 Application scenario switching
Short press mode selection key e,you can choose 5 inatable scene modes.
They are:
Scene mode Reference value Adjustable range
Car mode 2.4 bar 0-4.4 bar
Motorcycle mode 2.8 bar 0-3.7 bar
Bicycle mode 2.6 bar 0-10.3 bar
Custom mode 6.8 bar 0-10.3 bar
Ball mode 0.5 bar 0-1.0 bar
4.4 Unit switching
Short press the unit switch key 8, you can switch the air pressure display
unit. The unit conversion formula is shown below:
1PSI = 6.89KPA 1BAR = 100KPA 1Kg/cm
2
= 98KPA
4.5 Preset pressure value
Short press +/− button: Adjust the preset pressure value. Long press +/−
button: can quickly adjust the preset pressure value.
Note: The scene switch and preset pressure value are automatically saved
by the software. You only need to switch the scene for the next use, and the
preset pressure is automatically set.
4.6 Hose connection (image C)
The connection of the hose is shown in the following gure:
y
Schrader valve
u
Presta Valve
i
Ball needle nozzle
4.7 Start ination
Short press the ination switch
q
to start ination. The digital display of
the real-time air pressure value
5
changes during ination. Noise will be
generated during ination, and the hose produces high temperature during
long-term work. Avoid prolonged contact with hose and hose joints by
hand
2
.
4.8 Stop ination
Short press the ination switch
q
to stop ination manually.
When switching scene modes or preset pressure values, the screen will ash
three times for the currently set scene mode and pressure value, will be
displayed after ashing real-time pressure value.
4.9 LED Lighting
Long press LED
8
to turn on LED lighting.
Press and hold the LED light button
8
to turn o the LED light.
4.10 Measuring pressure
After switching on, connect the air pipe to the measured object, and the
measured pressure value
5
shows the current pressure value.
4.11 Reset
After switching on, when the measured pressure value is not zero, press the
preset +/– key for 3 seconds at the same time to enter auto clear.
Note: The product has been cleared from the factory. When the dierence
in altitude or the sensor tolerance shows that the measured pressure is not
zero, manual clearing can improve the accuracy of pressure detection. Do not
connect inatable objects when clearing
