Sida 1/100

LTE Modem

Model LB2120

User Manual

November 2017

202-11658-02

350 E. Plumeria Drive

San Jose, CA 95134

USA

Support

Thank you for purchasing this NETGEAR product.You can visit www.netgear.com/support to register your

product, get help, access the latest downloads and user manuals, and join our community.We recommend that

you use only official NETGEAR support resources.

Conformity

For the current EU Declaration of Conformity, visit http://kb.netgear.com/app/answers/detail/a_id/11621.

Compliance

For regulatory compliance information, visit http://www.netgear.com/about/regulatory.

See the regulatory compliance document before connecting the power supply.

Trademarks

trademarks are used for reference purposes only.

LTE Modem Model LB2120

Contents

Chapter 1 Introduction and Hardware Overview

Introduction............................................................................................................7

Supported Mobile Broadband Bands.....................................................................7

Package Contents..................................................................................................8

Install the Micro SIM Card......................................................................................8

Top Panel With Status LEDs................................................................................11

Back Panel With Ports, Connectors, and Button..................................................12

Modem Label.......................................................................................................12

Position the Modem.............................................................................................13

Optional External Antenna...................................................................................14

Chapter 2 Get Started

Internet Connection Over Mobile Broadband.......................................................16

Connect the Modem to a Wireline Broadband Modem........................................16

Connect a Computer, Switch, Hub, Router, or WiFi Router to the Modem..........17

Connect a Computer to the LAN Port of the Modem.......................................17

Connect a Router or WiFi Router to the LAN Port of the Modem....................17

Access the Modem’s Web Pages for the First Time.............................................17

Change the Language.........................................................................................20

Manage Automatic Failover Detection.................................................................20

Chapter 3 Manage the Modem LAN Settings

Change the LAN Settings....................................................................................24

Manage Router Mode and Bridge Mode..............................................................26

Change the DHCP Server Settings......................................................................27

Disable the DHCP Server....................................................................................29

Enable the DMZ...................................................................................................30

Disable VPN Pass-Through.................................................................................31

Chapter 4 Manage the Mobile Broadband Connection

Manage Mobile Broadband Auto Connect Options..............................................33

Manually Connect to or Disconnect From the Mobile Broadband Network..........34

Manage APN Profiles for Mobile Broadband Connections..................................34

View APN Profiles or Add a Custom APN Profile............................................35

Select an APN Profile......................................................................................37

Change an APN Profile...................................................................................38

Remove an APN Profile..................................................................................39

Chapter 5 Secure Your Network

Change the Modem Password.............................................................................41

Manage Port Forwarding for Incoming Traffic.......................................................41

Enable Port Forwarding and Add a Service or Application.............................42

Produktspecifikationer

Varumärke:	Netgear
Kategori:	Router
Modell:	LB2120
Vikt:	181.4 g
Bredd:	25.4 mm
Djup:	99 mm
Höjd:	30.5 mm
LED-indikatorer:	Ja
Snabbstartsguide:	Ja
Kabelteknik:	10/100/1000Base-T(X)
Uteffekt:	1 A
Rackmontering:	Nej
Produktens färg:	Svart
Enhetstyp:	Mobilnät, modem/router
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Antal LAN (RJ-45) anslutningar:	2
Utgångsspänning:	12 V
Kabel inkluderad:	AC, LAN (RJ-45)
Nätverksansluten (Ethernet):	Ja
Likströmsingång:	Ja
Strömkälla av typen:	AC, DC
På / av-knapp:	Ja
Antenntyp:	Intern
Datanät:	3G, LTE
Stöder xDSL anslutning:	Nej
