Universal Ultra Slim Flat Wall Mount

For 37" to 75" Ultra-thin Displays*

One of the world’s slimmest mounts, at only 0.19" (5mm) thin, the SUF651 brings displays closer

to the wall than most other products in the industry. This near-invisible mount is the beauty that

supports the modern style of the latest ultra-thin displays while the locking arm ensures a secure

installation. This unmatched solution delivers space-saving, ultra-sleek looks and brings the display

ultra-close to the wall.

Easy InstallatIon

Simply install the mount, attach the

display and slide in the locking arm

Ultra slIm

dEsIgn

At only 5mm

deep, the

mount virtually

disappears

behind the

display

sEcUrE InstallatIon

Locking arm holds display in place

preventing accidental bump-off or

undesired horizontal adjustment

Display size: 37"-75" Max load: 150lb (68kg)

SUF651

 Ultra slim design holds

ultra-thin display only 0.19"

(5mm) from the wall for a

near-invisible application

 Mount compatible with

ultra-thin displays with

150-400mm (in 25mm

increments) and 550-700mm

(in 25mm increments)

horizontal mounting hole

patterns

 Mounts to wood studs

and concrete

 Comes with fastener pack

with all necessary display

attachment hardware

 Locking arm holds display

in place and prevents

accidental bump-offs

and unwanted horizontal

adjustment

 Theft resistant security screw

on locking arm

 Easy three-step installation,

mount the wall plate, hang

the at panel display and

insert the locking arm

FEatUrEs

Holds display 0.19"

(5mm) from the wall

Locking arm holds

display in place

clIcK: call: FaX: peerless-av.com 800.865.2112 800.359.6500

* Designed exclusively for use with ultra-thin

displays 2” (51mm) deep or less

Patented. Design Patent No. D679,571; D665,813; D663,308; D656,138.

PACKAGE SIZE (W x H x D) PACKAGE SHIP WEIGHT PACKAGE UPC CODE PACKAGE CONTENTS UNITS IN PACKAGE

SUF651 6" x 1.375" x 39.75"

(152.4 x 39.925 x 1009.65mm) 5.8lb (2.61kg) 735029278375

Wall Mount, Locking Arm,

mounting and display

attachment hardware

Package Speciﬁcations

Accessories

DImENSIONS (W x H x D) LOAD CAPACITy FINISH AVAILABLE COLORSPRODUCT WEIGHT

SUF651 32.00" x 5.50" x 0.19"

(813 x 140 x 5mm) 4.32lb (1.94kg) 150lb (68kg)

Scratch

resistant

fused

epoxy

Gloss Black

Product Speciﬁcations

Model Numbers WARRANTY: Limited 5-year

A R C H I T E C T S S P E C I F I C A T I O N S

The Universal Ultra Slim Flat Wall Mount shall be a Peerless-AV model SUF651 and shall be located where indicated on the plans.

It shall feature scratch resistant black fused epoxy nish. Assembly and installation shall be done according to instructions provided by the manufacturer.

Above Display Security Lock AccessoryACC952:

All dimensions = (mm)inch

Universal Ultra Slim Flat Wall Mount for 37" to 75" Ultra-thin DisplaysSUF651:

LIT-0704 rev.3
