Sida 1/188

2021

OWNER’S

MANUAL

RANGER XP 1000 Tractor

For Maintenance and Safety

WARNING

Read this manual carefully. It contains important safety

information. This is an adult vehicle only.

Operation is prohibited for those under 16 years of age.

WARNING

Operating, servicing, and maintaining a passenger vehicle or off-road

vehicle can expose you to chemicals including engine exhaust, carbon

monoxide, phthalates, and lead, which are known to the State of California

to cause cancer and birth defects or other reproductive harm. To minimize

exposure, avoid breathing exhaust, do not idle the engine except as

necessary, service your vehicle in a well-ventilated area and wear gloves

or wash your hands frequently when servicing your vehicle.

For more information go to www.P65Warnings.ca.gov/passenger-vehicle.

!WARNING

Read, understand, and follow all of the instructions and safety

precautions in this manual and on all product labels.

Failure to follow the safety precautions

could result in serious injury or death.

For videos and more information

about a safe riding experience with

your Polaris vehicle, scan this QR

Code® with your smartphone.

2021 Owner’s Manual

RANGER XP 1000 Tractor

Unless noted, trademarks are the property of Polaris, Inc.

Recreational Off-Highway Vehicle Association® and ROHVA® are registered

trademarks of Recreational Off-Highway Vehicle Association.

Tread Lightly® is a registered trademark of the United States Department of

Agriculture.

BatteryMINDer® is a registered trademark of VDC Electronics Inc.

Loctite® is a registered trademark of Henkel Corporation.

NYOGEL® is a registered trademark of Nye Lubricants, Inc.

WD-40® is registered to WD-40 Manufacturing Company.

QR Code® is a registered trademark of DENSO WAVE INCORPORATED.

Maxxis® is a registered trademark of Cheng Shin Rubber Ind. Co., Ltd.

OSHA® is a registered trademark of the Occupational Safety and Health

Administration, U.S. Department of Labor.

based on the latest product information at the time of publication. Due to

constant improvements in the design and quality of production components,

some minor discrepancies may result between the actual vehicle and the

information presented in this publication. Depictions and/or procedures in this

publication are intended for reference use only. No liability can be accepted

for omissions or inaccuracies. Any reprinting or reuse of the depictions and/or

procedures contained within, whether whole or in part, is expressly

prohibited.

The original instructions for this vehicle are in English. Other languages are

provided as translations of the original instructions.

Printed in Czech Republic

9940074 R01

Thank you for purchasing a POLARIS vehicle, and welcome to our world-wide

family of POLARIS enthusiasts. Be sure to visit us online at www.polaris.com for

the latest news, new product introductions, upcoming events, career

opportunities and more.

Here at POLARIS we proudly produce an exciting line of utility and recreational

products. We believe POLARIS sets a standard of excellence for all utility and

recreational vehicles manufactured in the world today. Many years of experience

have gone into the engineering, design, and development of your POLARIS

vehicle, making it the finest machine we’ve ever produced.

For safe and enjoyable operation of your vehicle, be sure to follow the

instructions and recommendations in this owner’s manual. Your manual contains

instructions for minor maintenance, but information about major repairs is

outlined in the POLARIS Service Manual and can be performed by a factory

certified Master Service Dealer (MSD) technician.

Your POLARIS dealer knows your vehicle best and is interested in your total

satisfaction. Your POLARIS dealership can perform all of your service needs

during and after the warranty period.

For the most up-to-date owner’s manual visit https://www. polaris. com/en-us/

owners-manuals.

WELCOME

IMPORTANT ISRAEL MODEL INFORMATION . . . . . . 7

Introduction . . . . . . . . . . . . . . . . . . . . 9

Safety . . . . . . . . . . . . . . . . . . . . . . 13

Features and Controls . . . . . . . . . . . . . . 35

Operation . . . . . . . . . . . . . . . . . . . . 83

Winch Guide. . . . . . . . . . . . . . . . . . . 103

Emission Control Systems . . . . . . . . . . . . . 113

Maintenance . . . . . . . . . . . . . . . . . . 115

Specifications . . . . . . . . . . . . . . . . . . 163

POLARIS Products . . . . . . . . . . . . . . . . 167

Troubleshooting . . . . . . . . . . . . . . . . . 169

Warranty . . . . . . . . . . . . . . . . . . . . 173

Maintenance Log . . . . . . . . . . . . . . . . 179

IMPORTANT ISRAEL MODEL

INFORMATION

ISRAEL MODEL DIFFERENCES

IMPORTANT

Israel models are different in important ways from the other models covered by

this owner’s manual. The unique characteristics of Israel models are not

referenced throughout the rest of this owner’s manual. If you are using an

Israel model, carefully read the statements below and keep them in mind

before consulting the rest of the owner’s manual.

ISRAEL MODELS ARE TWO-

PERSON VEHICLES.

Israel models are designed to

accommodate two individuals - a driver

and a passenger. Do not operate Israel

models with more than one passenger,

as there are only two seat belts

available for use. Disregard all mentions

of “passengers” in the manual text if you

are using an Israel model.

ISRAEL MODELS ARE NON-

TRACTOR VEHICLES.

Israel models have not completed

testing to be certified as tractors.

Disregard all mentions of “tractor” in the

manual text if you are using an Israel

model.

SEAT ADJUSTMENT NOTE

The text in the “Seat Adjustments”

section (in the Features and Controls

chapter) does not apply to Israel

models. Disregard the text in the “Seat

Adjustments” section if you are using an

Israel model.

IMPORTANT ISRAEL MODEL INFORMATION

INTRODUCTION

BEFORE YOU RIDE

This POLARIS vehicle is an off-road vehicle. Familiarize yourself with all laws

and regulations concerning the operation of this vehicle in your area.

WARNING

Failure to heed the warnings and safety precautions contained in this manual

can result in severe injury or death. Your POLARIS vehicle is not a toy and can

be hazardous to operate. This vehicle handles differently than cars, trucks or

other off-road vehicles. A collision or rollover can occur quickly, even during

routine maneuvers like turning, or driving on hills or over obstacles, if you fail to

take proper precautions.

• Read this owner’s manual and review the safety DVD that came with your

vehicle. A free extra copy of the DVD can be obtained by contacting your

local POLARIS dealer. Understand all safety warnings, precautions and

operating procedures before operating the vehicle. Keep this manual with

the vehicle.

• Never operate this vehicle without proper instruction. Take an authorized

training course. See the Safety Training section for more information.

• This vehicle is an ADULT VEHICLE ONLY. You MUST be at least age 16

and have a valid driver’s license to operate this vehicle.

• Always use the cab nets (or doors) while riding in this vehicle. Always keep

hands, feet and all other body parts inside the vehicle at all times.

• Always wear a helmet, eye protection, gloves, long-sleeve shirt, long pants

and over-the-ankle boots.

• Never operate this vehicle under the influence of drugs or alcohol, as these

conditions impair judgement and reduce the operator’s ability to react.

• Complete the New Operator Driving Procedures outlined in this manual.

Never allow a guest to operate this vehicle until the guest has completed the

New Operator Driving Procedures.

• Never permit a guest to operate this vehicle unless the guest has reviewed

the owner’s manual and all safety labels and has completed a safety training

INTRODUCTION

SAFETY SYMBOLS AND SIGNAL WORDS

The following signal words and symbols appear throughout this manual and on

your vehicle. Your safety is involved when these words and symbols are used.

Become familiar with their meanings before reading the manual.

DANGER

DANGER indicates a hazardous situation which, if not avoided, WILL result in

death or serious injury.

WARNING

WARNING indicates a hazardous situation which, if not avoided, COULD result

in death or serious injury.

CAUTION

CAUTION indicates a hazardous situation which, if not avoided, COULD result

in minor to moderate injury.

NOTICE

NOTICE provides key information by clarifying instructions.

IMPORTANT

IMPORTANT provides key reminders during disassembly, assembly, and

inspection of components.

The Prohibition Safety Sign indicates an action NOT to take in

order to avoid a hazard.

The Mandatory Action Sign indicates an action that NEEDS to

be taken to avoid a hazard.

INTRODUCTION

VEHICLE IDENTIFICATION NUMBERS

Record your vehicle's identification numbers and key number in the spaces

provided. Remove the spare key and store it in a safe place. An ignition key can

be duplicated only by ordering a POLARIS key blank (using your key number)

and mating it with one of your existing keys. The ignition switch must be

replaced if all keys are lost.

The engine serial number can be found on a decal applied to the front of the

engine crankcase q

or stamped into the crankcase on the PTO side of the

engine w. The VIN can be found on the vehicle’s frame, just above the right

front wheel e.

The key number can be found on the

key r.

Vehicle Model Number:

Vehicle Identification Number (VIN):

Engine Serial Number:

Key Number:

INTRODUCTION

SAFETY

SAFETY TRAINING

Safety training is a top priority for POLARIS. POLARIS strongly encourages you

and any family members who will be riding this vehicle to take a training course.

For more information about safety, contact an authorized POLARIS dealer or

visit the POLARIS web site at www.polaris.com.

Your POLARIS vehicle is designed for off-road operation. Familiarize yourself

with all laws and regulations concerning the operation of this vehicle in your

area.

We strongly advise you to strictly follow the recommended maintenance

program outlined in your owner's manual. This preventive maintenance program

is designed to ensure that all critical components on your vehicle are thoroughly

inspected at specific intervals.

SAFE RIDING GEAR

Always wear a helmet, eye protection, gloves, long-sleeve shirt, long pants,

over-the-ankle boots and seat belt at all times. Protective gear reduces the

chance of injury.

RIDER COMFORT

Under certain operating conditions, heat generated by the engine and exhaust

system can elevate temperatures in the rider cab area. The condition occurs

most frequently when a vehicle is being operated in high ambient temperatures

at low speeds and/or high load conditions for an extended period of time. The

use of certain windshield, roof and/or cab systems may contribute to this

condition by restricting airflow.

Any discomfort due to heat buildup in this area can

be minimized by wearing proper riding apparel and

by varying speeds to increase airflow.

Helmet

Eye Protection

Long Sleeves

Gloves

Long Pants

Over-the-Ankle Boots

SAFETY

HELMET

Wearing a helmet can prevent a severe head injury. Whenever riding this

POLARIS vehicle, always wear a helmet that meets or exceeds established

safety standards. Clasp the buckle and pull each strap tight to ensure the helmet

is properly secured to the head.

Approved helmets in the USA and Canada bear a

U.S. Department of Transportation (DOT) label.

Approved helmets in Europe, Asia and Oceania

bear the ECE 22.05 label. The ECE mark consists

of a circle surrounding the letter E, followed by the

distinguishing number of the country which has

granted approval. The approval number and serial

number will also be displayed on the label.

EYE PROTECTION

Do not depend on eyeglasses or sunglasses for eye protection. Whenever riding

this POLARIS vehicle, always wear shatterproof goggles or use a shatterproof

helmet face shield. POLARIS recommends wearing approved Personal

Protective Equipment (PPE) bearing markings such as VESC 8, V-8, Z87.1, or

CE. Make sure protective eye wear is kept clean.

GLOVES

Wear gloves for comfort and for protection from sun, cold weather and other

elements.

BOOTS

Wear sturdy over-the-ankle boots for support and protection. Never ride a

POLARIS vehicle with bare feet or sandals.

CLOTHING

Wear long sleeves and long pants to protect arms and legs.

SAFETY

SAFETY WARNINGS

WARNING

Failure to operate this vehicle properly can result in a collision, loss of control,

accident or rollover, which may result in serious injury or death. Heed all safety

warnings outlined in this section of the owner’s manual and in the safety DVD

provided with your vehicle. See the OPERATION section of the owner’s

manual for proper operating procedures.

OPERATOR SAFETY

WARNING

Serious injury or death can result if you do not follow these instructions and

procedures, which are outlined in further detail within your owner's manual.

• Read this entire manual and all labels carefully. Follow the operating

procedures described.

• Never allow anyone under the age of 16 to operate this vehicle and never

allow anyone without a valid driver's license to operate this vehicle.

• Do not carry a passenger until you have at least two hours of driving

experience with this vehicle.

• All riders must be able to sit with backs against the seat, both feet flat on the

floor and both hands on the steering wheel (if driving) or on a passenger hand

hold.

• The driver and all passengers must wear helmets, eye protection, gloves,

long-sleeve shirts, long pants, over-the-ankle boots and their seat belts at all

times.

• Always use the cab nets (or doors) while riding in this vehicle.

• Always keep hands and feet inside the vehicle at all times.

• Always keep both hands on the steering wheel and both feet on the

floorboards of the vehicle during operation.

• Never permit a guest to operate this vehicle unless the guest has read this

manual and all product labels.

• To reduce rollover risk, be especially careful when encountering obstacles

and slopes and when braking on hills or during turns.

• This vehicle is for off road use only. Never operate on public roads (unless

marked for off-road use). Always avoid paved surfaces.

• Never consume alcohol or drugs before or while operating this vehicle.

• Never operate at excessive speeds. Always travel at a speed proper for the

terrain, visibility and operating conditions, and your experience.

• Never attempt jumps or other stunts.

SAFETY

• Always inspect the vehicle before each use to make sure it's in safe operating

condition.

• Always follow the inspection procedures described in this manual.

• Always travel slowly and use extra caution when operating on unfamiliar

terrain. Be alert to changing terrain.

• Never operate on excessively rough, slippery or loose terrain.

• Always follow proper procedures for turning. Practice turning at slow speeds

before attempting to turn at faster speeds. Never turn at excessive speeds.

• Always have this vehicle checked by an authorized POLARIS dealer if it has

been involved in an accident.

• Never operate this vehicle on hills too steep for the vehicle or for your abilities.

Practice on smaller hills before attempting larger hills.

• Always follow proper procedures for climbing hills as described in this manual.

Check the terrain carefully before attempting to climb a hill. Never climb hills

with excessively slippery or loose surfaces. Never apply throttle suddenly.

Never make sudden gear changes. Never go over the top of a hill at high

speed.

• Always follow the proper procedures outlined in this manual for traveling

downhill and for braking on hills. Check the terrain carefully before

descending a hill. Never travel downhill at high speed. Avoid going downhill at

an angle, which would cause the vehicle to lean sharply to one side. Travel

straight down the hill where possible.

• Always check for obstacles before operating in a new area. Never attempt to

operate over large obstacles such as large rocks or fallen trees. Always follow

the proper procedures outlined in this manual when operating over obstacles.

• Always be careful of skidding or sliding. On slippery surfaces such as ice,

travel slowly and exercise caution to reduce the chance of skidding or sliding

out of control.

• Never operate your vehicle in fast-flowing water or in water deeper than that

specified in this manual. Wet brakes may have reduced stopping ability. Test

your brakes after leaving water. If necessary, apply them lightly several times

to let friction dry out the pads.

• Always be sure there are no obstacles or people behind your vehicle when

operating in reverse. When it's safe to proceed in reverse, move slowly. Avoid

turning at sharp angles in reverse.

• Always use the proper size and type of tires specified in this manual. Always

maintain proper tire pressure as specified on safety labels. Failure to adhere

to either may impact vehicle stability, driveline durability, or general vehicle

handling.

• Never modify this vehicle through improper installation or use of non-

POLARIS approved accessories.

• Always re-install plastics and heat shields after vehicle is serviced.

SAFETY

• Never exceed the stated load capacity for this vehicle. Cargo should be

properly distributed and securely attached. Reduce speed and follow the

instructions in this manual for hauling cargo or pulling a trailer. Allow a greater

distance for braking.

• Always place the transmission in PARK before getting out of the vehicle.

• Always engage the park brake (if equipped) when leaving the vehicle

unattended.

• Always stop the engine before refueling. Make sure the refueling area is well

ventilated and free of any source of flame or sparks.

• Always remove the ignition key when the vehicle is not in use to prevent

unauthorized use by someone under the age of 16 or without a driver’s

license and proper training, or accidental starting.

OPERATING WITHOUT INSTRUCTION

Operating this vehicle without proper instruction increases the risk of an

accident. The operator must understand how to operate the vehicle properly in

different situations and on different types of terrain.

All operators must read and understand the

owner's manual and all warning and

instruction labels before operating the

vehicle.

All operators should review the safety DVD

provided with this vehicle and take a

ROHVA® training course (www.rohva.org).

AGE RESTRICTIONS

This vehicle is an ADULT VEHICLE ONLY.

Operation is prohibited for anyone under 16

years of age or anyone without a valid

driver’s license.

The operator must be tall enough to sit with

back against the seat, both feet flat on the

floor and both hands on the steering wheel (if

equipped) or handlebars.

SAFETY

USING ALCOHOL OR DRUGS

Never consume alcohol or drugs before or

while operating this vehicle.

Operating this vehicle after consuming

alcohol or drugs could adversely affect

operator judgment, reaction time, balance

and perception.

FAILURE TO INSPECT BEFORE OPERATING

WARNING

Failure to inspect and verify that the vehicle is in safe operating condition

before operating increases the risk of an accident. Always perform the Pre-

Ride Inspection outlined in the Operation chapter before each use of your

vehicle to make sure it's in safe operating condition. Always follow the

inspection and maintenance procedures and schedules described in this

owner’s manual. See the Periodic Maintenance section of the Maintenance

chapter.

PROTECTIVE APPAREL

Riding in this vehicle without wearing an approved helmet and protective

eyewear and footwear increases the risk of a serious injuries in the event of an

accident.

Operator and/or all passengers must always wear an approved helmet that fits

properly, gloves, long-sleeve shirt, long pants, over-the-ankle boots, and eye

protection (goggles or face shield).

DUST EXPOSURE

Exposure to dust created by the movement of the vehicle in dry weather may

lead to respiratory distress. Be aware of operating environments and take

precautions to avoid dust ingestion. Wear proper clothing, helmet, and eye

protection.

SAFETY

SEAT BELTS

WARNING

Riding in this vehicle without wearing the seat belt increases the risk of serious

injury in the event of rollover, loss of control, other accident or sudden stop.

Seat belts may reduce the severity of injury in these circumstances. The

operator and all passengers MUST wear their seat belt at all times.

OPERATING WITH A LOAD ON THE VEHICLE

The weight of the cargo, operator, and passengers impacts vehicle operation

and stability. For your safety and the safety of others, carefully consider how

your vehicle is loaded and how to safely operate the vehicle. Follow the

instructions in this manual for loading, tire pressure, gear selection and speed.

• Do not exceed vehicle weight capacities. The vehicle’s maximum weight

capacity is listed in the specifications section of this manual and on a label on

the vehicle. When determining the weight you are adding to the vehicle,

include the weight of the operator, passengers, accessories, loads in the rack

or box and the load on the trailer tongue. The combined weight of these items

must not exceed the maximum weight capacity.

• The recommended tire pressures are listed in the specifications section of this

manual and on a label on the vehicle.

Always follow these guidelines:

UNDER ANY OF THESE CONDITIONS: DO ALL OF THESE STEPS:

Operator and/or cargo exceeds half the

maximum weight capacity

1. Slow down.

2. Verify tire pressure.

3. Use extra caution when operating.

Operating in rough terrain

Operating over obstacles

Climbing an incline

Towing

CAB NETS (IF EQUIPPED)

Riding in this vehicle without using the cab nets (or doors, if equipped) increases

the risk of serious injury or death in the event of an accident or rollover. Cab nets

(or doors) must be used by both operator and passengers at all times. Make

sure all latches are secure before operating the vehicle.

SAFETY

Always inspect cab nets and latches for tightness, wear and damage before

each use of the vehicle. Use the strap adjusters to tighten any loose straps.

Promptly replace worn or damaged cab nets and latches with new cab nets and

latches. Your POLARIS dealer can assist.

CAB DOORS (IF EQUIPPED)

Riding in this vehicle without closed and latched cab doors increases the risk of

serious injury or death in the event of an accident or rollover. Always make sure

all cab doors are closed and latched while riding in this vehicle. Cab doors are

NOT intended to be used as arm rests. Always keep hands and feet inside the

vehicle at all times.

CARRYING A PASSENGER

A passenger must always be seated in

a passenger seat with seat belt

secured. Carrying more than one

passenger in a 2-seat vehicle can affect

the operator’s ability to steer and

operate the controls, which increases

the risk of loss of control and accident

or rollover. Never carry more than one

passenger in a 2-seat vehicle unless

specified otherwise.

IMPROPER TIRE MAINTENANCE

WARNING

Operating this vehicle with improper tires or with improper or uneven tire

pressure could cause loss of control or accident. Always use the size and type

of tires specified for your vehicle. Always maintain proper tire pressure as

described in the owner's manual and on safety labels.

OPERATING ON PAVEMENT (NON-ZUGMASCHINE

VEHICLES)

This vehicle's tires are designed for off-road use only, not for use on pavement.

Operating this vehicle on paved surfaces (including sidewalks, paths, parking

lots and driveways) may adversely affect the handling of the vehicle and may

increase the risk of loss of control and accident or rollover. Avoid operating the

vehicle on pavement. If it's unavoidable, travel slowly, travel short distances and

avoid sudden turns or stops.

SAFETY

OPERATING ON PUBLIC ROADS

Zugmaschine and Tractor Models

This vehicle is approved for on-road operation.

WARNING

Other Models

Operating this vehicle on public streets, roads or highways could result in a

collision with another vehicle. Never operate this vehicle on any public street,

road or highway, including dirt and gravel roads (unless designated for on-road

use).

OPERATING AT EXCESSIVE SPEEDS

CAUTION

Operating this vehicle at excessive speeds increases the operator's risk of

losing control. Always operate at a speed that's appropriate for the terrain, the

visibility and operating conditions and your skills and experience.

JUMPS AND STUNTS

CAUTION

Exhibition driving increases the risk of an accident or rollover. DO NOT do

power slides, “donuts”, jumps or other driving stunts. Avoid exhibition driving.

TURNING IMPROPERLY

CAUTION

Turning improperly could cause loss of traction, loss of control, accident or

rollover. Always follow proper procedures for turning as described in this

owner’s manual.

Avoid sharp turns. Never turn while applying heavy throttle. Never make abrupt

steering maneuvers. Practice turning at slow speeds before attempting to turn at

faster speeds.

SAFETY

IMPROPER HILL CLIMBING

CAUTION

Improper hill climbing could cause loss of control or rollover. Use extreme

caution when operating on hills. Always follow proper procedures for hill

climbing as described in this owner's manual.

DESCENDING HILLS IMPROPERLY

CAUTION

Improperly descending a hill could cause loss of control or rollover. Always

follow proper procedures for traveling down hills as described in this owner’s

manual.

CROSSING HILLSIDES

CAUTION

Driving on a sidehill is not recommended. Improper procedure could cause

loss of control or rollover. Avoid crossing the side of any hill unless absolutely

necessary. If crossing a hillside is unavoidable, always follow proper

procedures as described in this owner's manual.

STALLING WHILE CLIMBING A HILL

CAUTION

Stalling or rolling backwards while climbing a hill could cause a rollover.

Maintain a steady speed when climbing a hill.

If you lose all forward speed:

Apply the brakes gradually until the vehicle is fully stopped. Place the

transmission in reverse and slowly allow the vehicle to roll straight downhill while

applying light brake pressure to control speed.

If you begin rolling downhill:

Never apply engine power. Apply the brakes gradually until the vehicle is fully

stopped. Place the transmission in reverse and slowly allow the vehicle to roll

straight downhill while applying light brake pressure to control speed.

SAFETY

OPERATING IN UNFAMILIAR TERRAIN

CAUTION

Failure to use extra caution when operating on unfamiliar terrain could result in

an accident or rollover.

CAUTION

Unfamiliar terrain may contain hidden rocks, bumps, or holes that could cause

loss of control or rollover.

Travel slowly and use extra caution when operating on unfamiliar terrain. Always

be alert to changing terrain conditions.

OPERATING IMPROPERLY IN REVERSE

CAUTION

Improperly operating in reverse could result in a collision with an obstacle or

person. Always follow proper operating procedures as outlined in this manual.

Before shifting into reverse gear, always check for obstacles or people behind

the vehicle. When it's safe to proceed, back slowly.

SKIDDING OR SLIDING

CAUTION

Failure to use extra caution when operating on excessively rough, slippery or

loose terrain could cause loss of traction, loss of control, accident or rollover.

Do not operate on excessively slippery surfaces. Always slow down and use

additional caution when operating on slippery surfaces.

CAUTION

Skidding or sliding due to loss of traction can cause loss of control or rollover (if

tires regain traction unexpectedly). Always follow proper procedures for

operating on slippery surfaces as described in this owner's manual.

SAFETY

OPERATING OVER OBSTACLES

CAUTION

Improperly operating over obstacles could cause loss of control or rollover.

Before operating in a new area, check for obstacles. Avoid operating over

large obstacles such as large rocks and fallen trees. Always follow the proper

procedures outlined in this manual when operating over obstacles.

OPERATING THROUGH WATER

CAUTION

Operating through deep or fast-flowing water can cause loss of traction, loss of

control, rollover or accident. Never operate in fast-flowing water or in water that

exceeds the floor level of the vehicle.

Always follow proper procedures for operating in water as described in this

owner’s manual.

Wet brakes will have reduced stopping ability. After leaving water, test the

brakes. Apply them lightly several times while driving slowly. The friction will help

dry out the pads.

OPERATING ON FROZEN BODIES OF WATER

WARNING

Serious injury or death can result if the vehicle and/or the operator fall through

the ice. Never operate the vehicle on a frozen body of water unless you have

first verified that the ice is sufficiently thick to support the weight and moving

force of the vehicle, you and your cargo, together with any other vehicles in

your party.

Always check with local authorities and residents to confirm ice conditions and

thickness over your entire route. Vehicle operators assume all risk associated

with ice conditions on frozen bodies of water.

OPERATING A DAMAGED VEHICLE

CAUTION

Operating a damaged vehicle can result in an accident. After any rollover or

other accident, have a qualified service dealer inspect the entire machine for

possible damage, including (but not limited to) seat belts, rollover protection

devices, brakes, throttle, and steering systems.

SAFETY

IMPROPER CARGO LOADING

Overloading the vehicle or carrying cargo improperly may cause changes in

stability and handling, which could cause loss of control or an accident.

• Always follow the instructions in this owner’s manual for carrying cargo.

• Never exceed the stated load capacity for this vehicle.

• Cargo should be properly distributed and securely attached.

• Reduce speed when carrying cargo or pulling a trailer. Allow a greater

distance for braking.

POOR VISIBILITY

CAUTION

Operating this vehicle in darkness or inclement weather could result in a

collision or accident, especially if operating on a road or street. This vehicle is

not equipped with highway-approved lights. Operate this vehicle off-road only.

Use caution and drive at reduced speeds in conditions of reduced visibility

such as fog, rain and darkness. Clean headlights frequently and replace

burned out headlamps promptly.

HOT EXHAUST SYSTEMS

WARNING

Exhaust system components are very hot during and after use of the vehicle.

Hot components can cause burns and fire. Do not touch hot exhaust system

components. Always keep combustible materials away from the exhaust

system.

Use caution when traveling through tall grass, especially dry grass and when

traveling through muddy conditions. Always inspect the underside of the

vehicle and areas near the exhaust system after driving through tall grass,

weeds, brush, other tall ground cover, and muddy conditions. Promptly remove

any grass, debris or foreign matter clinging to the vehicle and pay particular

attention to the exhaust system area.

EXPOSURE TO EXHAUST

CAUTION

Engine exhaust fumes are poisonous and can cause loss of consciousness or

death in a short time. Never start the engine or let it run in an enclosed area.

Operate this vehicle only outdoors or in well-ventilated areas.

SAFETY

REFUELING

Gasoline is highly flammable and explosive under certain conditions.

• Always exercise extreme caution whenever handling gasoline.

• Always turn off the engine when refueling.

• Always refuel outdoors or in a well ventilated area free of any source of flame

or sparks.

• NEVER carry fuel or other flammable liquids on this vehicle. Failure to follow

this instruction could lead to serious burn injuries or death.

• Do not smoke or allow open flames or sparks in or near the area where

refueling is performed or where gasoline is stored.

• Do not overfill the tank. Do not fill the tank neck.

• If gasoline spills on your skin or clothing, immediately wash it off with soap

and water and change clothing.

UNAUTHORIZED USE OF THE VEHICLE

Leaving the keys in the ignition can lead to unauthorized use of the vehicle by

someone under the age of 16, without a drivers license, or without proper

training. This could result in an accident or rollover. Always remove the ignition

key when the vehicle is not in use.

EQUIPMENT MODIFICATIONS

Your POLARIS vehicle is designed to provide safe operation when used as

directed. Modifications to your vehicle may negatively impact vehicle stability.

Failure of critical machine components may result from operation with any

modifications, especially those that increase speed or power. This vehicle may

become less stable at speeds higher than those for which it is designed. Loss of

control may occur at higher speeds.

Do not install any non-POLARIS-approved accessory or modify the vehicle for

the purpose of increasing speed or power. Any modifications or installation of

non-POLARIS-approved accessories could create a substantial safety hazard

and increase the risk of bodily injury.

The POLARIS limited warranty on your POLARIS vehicle will be terminated if

any non-POLARIS approved equipment and/or modifications have been added

to the vehicle that increase speed or power.

The addition of certain accessories, including (but not limited to) mowers,

blades, tires, sprayers, or large racks, may change the handling characteristics

of the vehicle. Use only POLARIS-approved accessories, and familiarize

yourself with their function and effect on the vehicle.

SAFETY

The addition of certain accessories, including (but not limited to) overhead audio

speakers, may change the forward clearance in the vehicle. Polaris

recommends selecting a helmet that is compatible with the equipment on your

vehicle and provides the greatest amount of forward clearance. Always wear a

helmet that meets or exceeds the specifications in this owner’s manual. Refer to

the Safe Riding Gear section of this owner’s manual for more information. Use

only POLARIS-approved accessories.

FOR MORE INFORMATION ABOUT SAFETY IN THE UNITED STATES call

POLARIS at 1-800-342-3764.

LIGHTNING AND POWERLINES

Avoid operating this vehicle when lightning could occur or near powerlines.

Rubber tires, rubber handgrips, and a foam seat will not protect a rider from

lightning strikes or electrical surges. Always seek safe shelter when lightning is

imminent and keep a safe distance from powerlines.

For more information about safety, contact an authorized POLARIS

dealer or visit the POLARIS web site at www.polaris.com.

SAFETY

SAFETY LABELS AND LOCATIONS

Warning labels have been placed on the vehicle for your protection. Read and

follow the instructions of the labels on the vehicle carefully. If any of the labels

depicted in this manual differ from the labels on your vehicle, always read and

follow the instructions of the labels on the vehicle.

If any label becomes illegible or comes off, contact your POLARIS dealer to

purchase a replacement. Replacement safety labels are provided by POLARIS

at no charge. The part number is printed on the label.

LABEL LOCATIONS

General and Shift Alerts

Load/Passenger/Tire Pressure and Greasing/Jacking Points Alerts

Hitch Receiver Capacity Alert

Clutch Cover Alert

Intake Alert

SAFETY

INTAKE ALERT (7185975)

Use a Polaris approved air filter. The

use of a non-Polaris approved air filter

may cause engine damage. Before

installing filter ensure there is no dirt or

debris in the clean side of the intake

tube. The air filter must be properly

seated and the hinges fully inserted

when the lid is reinstalled. Please

reference your owner’s manual for

additional information regarding the air

filter service.

Label Location: on the air box.

SHIFT ALERT

CAUTION

To avoid transmission damage, shift

only when vehicle is stationary and

at idle.

APPLY BRAKE TO START. When

this vehicle is not in operation, or

unattended, place shift in the park

position.

GENERAL ALERT

Read the owner’s manual. Never allow anyone under 16 years of age to operate

this vehicle. Never use alcohol or drugs before or while driving or riding. This

vehicle is approved for on-road operation. Wear approved helmet, goggles, and

protective clothing. Always wear seat belts. Always use the cab nets or doors.

Never exceed seating capacity.

SAFETY

OWNER’S MANUAL ALERT

Read the owner’s manual.

JACKING POINTS ALERT (7184992)

Jacking positions are located beneath

the vehicle’s center points. Read the

owner’s manual.

GREASING POINTS ALERT (7185156)

Lubricate as recommended. Read

owner’s manual.

CLUTCH COVER ALERT (7181427)

Read your owner’s manual. Keep body parts

away from belt.

SAFETY

LOAD/PASSENGER/TIRE PRESSURE ALERT

(73000424)

Never carry passengers in cargo

box. Passengers can be thrown off.

This can cause serious injury or

death. Read owner's manual.

NEVER carry fuel or other

flammable liquids on this vehicle.

Failure to follow this instruction

could lead to serious burn injuries or

death.

SAFETY

RANGER TR NORDIC PRO

TRACTOR

MODELS

MAXIMUM CARGO BOX LOAD 454 kg 454 kg

TIRE PRESSURE IN kPa (bar) FRONT 69 kPa

(0,69 bar / 10 PSI)

REAR 97 kPa

(0,97 bar / 14 PSI)

FRONT 69 kPa

(0,69 bar / 10 PSI)

REAR 97 kPa

(0,97 bar / 14 PSI)

TIRE PRESSURE WITH FULL

LOAD

(MAX CARGO + PASSENGER) IN

kPa (bar)

FRONT 69 kPa

(0,69 bar / 10 PSI)

REAR 170 kPa

(1,7 bar / 24.6

PSI)

FRONT 69 kPa

(0,69 bar / 10 PSI)

REAR 170 kPa

(1,7 bar / 24.6

PSI)

MAXIMUM WEIGHT CAPACITY

INCLUDES WEIGHT OF

OPERATOR, PASSENGER,

CARGO AND ACCESSORIES

564 kg 543 kg

Read Operation and Maintenance Manual for more detailed loading

information.

RANGER EU/ZUG

MAXIMUM CARGO BOX LOAD 454 kg

TIRE PRESSURE IN kPa (bar) FRONT 69 kPa (0,69 bar

/ 10 PSI)

REAR 97 kPa (0,97 bar /

14 PSI)

TIRE PRESSURE WITH FULL LOAD

(MAX CARGO + PASSENGER) IN kPa (bar)

FRONT 69 kPa (0,69 bar

/ 10 PSI)

REAR 210 kPa (2,1 bar /

30.5 PSI)

MAXIMUM WEIGHT CAPACITY

INCLUDES WEIGHT OF OPERATOR,

PASSENGER, CARGO AND ACCESSORIES

569 kg

Read Operation and Maintenance Manual for more detailed loading

information.

SAFETY

RANGER CREW, EU

MAXIMUM CARGO BOX LOAD 454 kg

TIRE PRESSURE IN kPa (bar) FRONT 96 kPa (0,96 bar

/ 14 PSI)

REAR 110 kPa (1,10 bar /

16 PSI)

TIRE PRESSURE WITH FULL LOAD

(MAX CARGO + PASSENGER) IN kPa (bar)

FRONT 96 kPa (0,96 bar

/ 14 PSI)

REAR 210 kPa (2,10 bar /

30.5 PSI)

MAXIMUM WEIGHT CAPACITY

INCLUDES WEIGHT OF OPERATOR,

PASSENGER, CARGO AND ACCESSORIES

767 kg

Read Operation and Maintenance Manual for more detailed loading

information.

SAFETY

FEATURES AND CONTROLS

COMPONENT LOCATIONS

q Console

w Headlights

e Bumper/Brush Guard

r Radiator/Winch (if equipped)

t Tailgate

y Taillights

u CV Boot/Rear Caliper

i Receiver Hitch

o ROPS Cab Frame

a Hip Bar

s Cargo Box

d Fuel Cap

FEATURES AND CONTROLS

CONSOLE

q Turn Signal Lever

w Left-side Switch Panel

e Steering Wheel Adjustment Lever

r Ignition

t Park Brake Lever

y Right-side Switch Panel

u 12V Auxiliary Outlets

i Battery Trickle-Charging Outlet

o Storage Compartment

a Gear Selector (Shifter)

s Instrument Cluster

STEERING WHEEL

The steering wheel can be tilted upward

or downward for rider preference. Lift

and hold the steering wheel adjustment

lever q while moving the steering wheel

upward or downward. Release the lever

when the steering wheel is at the

desired position. Always make sure the

steering wheel position does not

impede proper operation of the brake

pedal, throttle pedal and all other

controls.

FEATURES AND CONTROLS

GEAR SELECTOR

To change gears, stop the vehicle, and with the engine idling, move the lever to

the desired gear. Do not attempt to shift gears with engine speed above idle or

while the vehicle is moving.

H: High Gear

L: Low Gear

N: Neutral

R: Reverse

P: Park

Low gear is the primary driving range for the RANGER. High gear is intended for

use on hard-packed surfaces with light loads. Whenever the vehicle is left

unattended, always place the transmission in PARK.

TIP

Maintaining shift linkage adjustment is important to assure proper transmission

function. Your POLARIS dealer can assist in resolving any shifting problems.

NOTICE

Do not attempt to shift the transmission while the vehicle is moving or damage

to the transmission could result. Always shift when the vehicle is stationary and

the engine is at idle.

USING LOW GEAR

Low gear is the primary driving range for the . High gear is intended for RANGER

use on hard-packed surfaces with light loads. Whenever the vehicle is left

unattended, always place the transmission in PARK.

Always shift into low gear for any of the following conditions.

• Operating in rough terrain or over obstacles

• Loading the vehicle onto a trailer

• Climbing hills

• Towing heavy loads

• Driving slowly - under 10 MPH (16 km/h)

• Operating with mud

FEATURES AND CONTROLS

SWITCHES

Not all switches are present on every model.

IGNITION SWITCH / LIGHT SWITCH

Use the ignition switch to start the engine and to turn the lights on or off. The key

can be removed from the switch when it is in the OFF position.

ICON DESCRIPTION FUNCTION

Off Turn the key to the OFF

position to stop the

engine. Electrical

circuits are OFF.

Light On All lights are ON.

Electrical circuits are

ON. Electrical

equipment can be used.

Position Lights On The headlights are OFF.

Position lights are ON.

Electrical equipment

can be used.

Start Turn the key to the

START position to

engage the electric

starter. See the Starting

the Engine section for

details.

FEATURES AND CONTROLS

TURN SIGNAL LEVER

Before turning, activate a turn signal to alert others of your intentions. Check turn

signal lamps before each ride.

TIP

The key must be in the ON position to activate the turn signals.

Move the turn signal lever downward q

to signal a left turn. The left turn signal

lamps in the taillight and below the front

headlight will flash. The turn signal

indicator in the gauge will also flash.

Move the lever upward w to signal a

right turn. The right signal lamps and

indicator will flash.

Return the lever to the center position to

end the signal.

Activate the horn switch by pressing on

the end of the turn signal lever. See the

Horn Switch section for details.

HORN SWITCH

The horn switch is located on the turn

signal lever q. Press the tip of the turn

signal lever inward to sound the horn.

FEATURES AND CONTROLS

DRIVELINE MODE SWITCH

The Driveline Mode Switch has three positions: All Wheel Drive (AWD),

Differential Lock/Two Wheel Drive (2WD) and Off (Turf Mode).

q AWD: Press the top of the switch to

engage All Wheel Drive (AWD).

w 2WD: Move the switch to the center

position to lock the differential and operate in

two wheel drive (2WD).

e TURF Mode: Press the bottom of the

switch for Turf Mode (unlocked differential

power). In Turf Mode, the rear drive wheels

operate independently (1WD) depending on

tire traction. This mode of operation is well

suited to turf driving or when active traction is

not needed.

HAZARD SWITCH

Push the hazard warning switch to cause all turn signal

lights to flash simultaneously. Both turn signal indicators

on the console will also flash. Use this feature to alert

others of an emergency or other situation requiring

caution.

FEATURES AND CONTROLS

TEMPERATURE CONTROLS (IF EQUIPPED)

Certain vehicles are equipped with temperature controls on the console.

Rotating the right-side knob will

adjust the temperature of the

airflow in the vehicle interior.

Rotating the left-side knob will

adjust the rate of airflow in the

vehicle interior.

ACTIVE DESCENT CONTROL (ADC) SWITCH

(IF EQUIPPED)

The ADC system allows engine braking to all four

wheels when the vehicle descends a hill or incline. Press

the top of the switch to engage ADC. Press the bottom

of the switch to turn off ADC. Always operate in low gear

and engage ADC before ascending or descending a hill.

FEATURES AND CONTROLS

AUXILIARY OUTLET

The vehicle is equipped with a 12-volt accessory

outlet on the dash. Use the outlet to power an

auxiliary light or other optional accessories or

lights. For service, the dash outlet connection is

under the dash.

BATTERY TRICKLE-CHARGING OUTLET

The vehicle is equipped with a dedicated outlet for trickle-charging the battery

during periods of extended inactivity.

If you do not drive the vehicle for more than TWO

WEEKS, Polaris recommends using a

BatteryMINDer® 2012 AGM - 2 AMP charger (PN

2415295), which can be ordered through your

dealer.

Polaris provides a charging accessory with your

vehicle that allows easy connection to the battery

through the Battery Trickle-Charging Outlet,

located on the dash. While charging, place the

charger outside of the vehicle and protect it from

moisture.

FEATURES AND CONTROLS

FOOT PEDALS

BRAKE PEDAL

Depress the brake pedal q to slow or stop the vehicle. Apply the brakes while

starting the engine.

When the brake pedal is depressed, the brake light comes on. Check the brake

light before each ride.

1. Turn the ignition switch to the ON position.

2. Apply the brakes. The brake light should come on after about 0.4 in (10 mm)

of pedal travel.

THROTTLE PEDAL

Push the throttle pedal w down to increase engine speed. Spring pressure

returns the pedal to the rest position when released. Always check that the

throttle pedal returns normally before starting the engine.

TIP

If the throttle pedal and brake pedal are applied simultaneously, engine power

may be limited.

FEATURES AND CONTROLS

PARK BRAKE LEVER

Always apply the service brakes

before engaging or releasing the

park brake. To help prevent the

vehicle from rolling, set the park

brake when parking the vehicle.

When the park brake is set and the

park brake indicator is illuminated,

engine speed is limited. If the

accelerator is applied, this limiting

feature prevents operation, which

protects the park brake pads from

excessive wear.

TIP

This feature will not operate properly if the park brake connector or switch

malfunctions or becomes disconnected, or if the switch has moved. Check for

disconnection, then see your dealer or other qualified service person promptly

if this feature fails to operate properly.

1. To set the park brake, apply the brakes. Pull the park brake lever q towards

yourself as far as possible.

2. To release the park brake, apply the brakes. Turn the park brake lever

counterclockwise and push it in as far as possible.

SEATS

CAUTION

Prolonged sun exposure can cause excessive heating of the steering wheel

and seats. Use caution when handling hot surfaces to avoid burns.

NOTE

These seats are designed for this tractor model. Replacement with different

seats is not possible.

Before operating the vehicle, always push down on all seat backs to ensure the

latches are secure.

FEATURES AND CONTROLS

SEAT REMOVAL

To remove the driver’s seat, lift up on the rear of the seat and rotate the seat

base up and forward.

To put the passenger seat into the upright position, lift up on the front of the seat

and raise it to the upright position.

SEAT BELTS

This vehicle is equipped with three-point lap and diagonal seat belts for the

operator and passengers. Always make sure the seat belts are secured for all

riders before operating. This vehicle is equipped with an Operator Presence

Control system that will sound a beeper if the ignition is on, the park brake is off,

and the seat belts are not fastened.

WARNING

Falling from a moving vehicle could result in serious injury or death. Always

fasten your seat belt securely before operating or riding in the vehicle.

To wear the seat belt properly, follow this procedure:

1. For 3-point belts, pull the seat belt latch q downward and across your chest

toward the buckle at the inner edge of the seat. The belt should fit snugly

across your hips and diagonally across your chest. Make sure the belt is not

twisted.

2. Push the latch plate q into the buckle w until it clicks.

FEATURES AND CONTROLS

3. Release the strap, it will self-tighten.

4. To release the seat belt, press the square red button in the buckle’s center.

SEAT BELT INSPECTION

Inspect all seat belts for proper operation before each use of the vehicle.

1. Push the latch plate into the buckle until it clicks. The latch plate must slide

smoothly into the buckle. A click indicates that it's securely latched.

2. Push the red release latch in the middle of the buckle to make sure it

releases freely.

3. Pull each seat belt completely out and inspect the full length for any damage,

including cuts, wear, fraying or stiffness. If any damage is found, or if the seat

belt does not operate properly, have the seat belt system checked and/or

replaced by an authorized dealer.

4. To clean dirt or debris from the seat belts, sponge the straps with mild soap

and water. Do not use bleach, dye or household detergents. Rinse the entire

length of the belt webbing. Use a garden hose to flush out the retractor and

latch housings regularly.

SEAT AND STORAGE COMPARTMENTS

The electrical compartment is located under the center rear-most seat. Never

use this area for storage. Storage compartments are located under all other

seats. Remove the storage bin under the center rear-most seat to access the

battery and electrical compartment.

Always make sure all seats are properly installed before operating.

PASSENGER’S SEAT

To access the storage area under the passenger seat, lift up on the front of the

passenger seat and raise it to the upright position.

SEAT ADJUSTMENTS

The driver’s seat is equipped with an adjustment lever and adjustment crank for

optimal spacing.

• Pull the adjustment lever to the left to move the seat forward or rearward.

Once released, the lever will lock into place.

• Rotate the adjustment crank to move the seat forward and upward or

rearward and downward.

To adjust the front passenger seat, loosen (do not remove) the four screws

located on the seat bottom. Slide the seat forward or rearward to the desired

position. Tighten the screws to 5.4 N m. (4 ft. lbs.) Do not overtighten.⋅

FEATURES AND CONTROLS

ELECTRONIC POWER STEERING

(IF EQUIPPED)

Electronic power steering (EPS) engages when the ignition key is turned to the

ON position. EPS remains engaged whether the vehicle is moving or idle. To

conserve battery power, the EPS will shut down 5 minutes after the engine is

stopped if the key remains in the ON position. The EPS warning indicator will

illuminate to indicate the EPS has shut down. Turn the key off and on to reset

the unit. If the light remains on after starting the engine, the EPS system is

inoperative. See your POLARIS dealer, or other qualified person, as soon as

possible for repair. Continued operation could result in permanent damage to the

EPS unit and increased steering effort.

FUEL CAP

The fuel tank filler cap q is located

on the left-hand side of the vehicle

near the driver’s seat. Always

ensure that the fuel tank filler cap is

fully tightened and secure before

operating or transporting the

vehicle.

When refueling, always use either

leaded or unleaded gasoline with a

minimum pump octane number of 87 R

+M/2 octane. Do not use fuel with

ethanol content greater than 10 percent,

such as E-85 fuel.

FEATURES AND CONTROLS

CAB NETS (IF EQUIPPED)

WARNING

Riding in this vehicle without using the cab nets (or doors, if equipped)

increases the risk of serious injury or death in the event of an accident or

rollover. Cab nets (or doors) must be used by both operator and passengers at

all times. Make sure all latches are secure before operating the vehicle

Always inspect cab nets and latches for tightness, wear and damage before

each use of the vehicle. Use the strap adjusters to tighten any loose straps.

Promptly replace worn or damaged cab nets and latches with new cab nets and

latches. Your POLARIS dealer or qualified technician can assist.

SECURING THE NET

1. Connect the latch at the top edge of the net to the receiver latch mounted on

the front frame.

OPENING THE NET

1. To exit the vehicle, release the top front latch.

2. Rotate the net rearward and slide the lower net rod out of the mount to

remove it.

3. Allow the net to hang freely outside the vehicle while dismounting.

ROLLOVER PROTECTIVE STRUCTURE (ROPS)

The Rollover Protective Structure (ROPS) on this vehicle meets OSHA®

1928.53 rollover performance requirements. Always have your authorized

dealer thoroughly inspect the ROPS if it ever becomes damaged in any way.

No device can assure occupant protection in the event of a rollover. Always

follow all safe operating practices outlined in this manual to avoid vehicle

rollover.

WARNING

Vehicle rollover could cause severe injury or death. Always avoid operating in

a manner that could result in vehicle rollover.

FEATURES AND CONTROLS

HOOD LATCHES

To remove the hood, rotate the hood

latches q 1/4-turn and lift the hood

away from the vehicle.

TRAILER HITCH BRACKET

This vehicle is equipped with a receiver hitch bracket for a trailer hitch. To avoid

injury and property damage, always heed the warnings and towing capacities

outlined on page 91.

HITCHES

WARNING

Whenever the vehicle is towing, always stay clear of the area between the

vehicle and the towed object.

REAR HITCH

NOTICE

After 1000 km of use, tighten the bolt holding the trailer ball to the hitch to 445

N m.⋅

Use the rear hitch for towing a trailer. See the Hauling Cargo section for details

and procedures.

The values given below pertain to factory-installed hitches and are provided for

informational purposes only.

IMPORTANT

For vehicle-specific trailering values, see the Specifications chapter.

The vehicle-specific values take precedent if they are lower than the

component values shown below.

FEATURES AND CONTROLS

REAR HITCH COMPONENT SPECIFICATIONS

Maximum Vertical Load(s) 100 kg

Maximum Towable Mass 3500 kg

Maximum Dynamic Force (D) 14,0 kN

Approval # E20 55R-01 3487

REAR HITCH CERTIFICATION LABEL

The hitch certification label is located near the hitch on models equipped with a

factory-installed rear hitch.

FEATURES AND CONTROLS

HITCH REMOVAL / INSTALLATION

1. To remove the hitch (if equipped), remove the cotter pin q and hitch pin w.

Remove the hitch, then reinstall the hitch pin w and secure the cotter pin q.

2. To install the hitch, remove the cotter pin q from the hitch pin and remove

the hitch pin w.

3. Install the hitch to the receiver.

4. Reinstall the hitch pin (from the left side of the hitch) through the bore of both

the receiver and the hitch.

5. Reinstall the cotter pin. Make sure the hitch assembly is secure at that the

cotter pin is properly engaged over the hitch pin.

7-WAY TRAILER CONNECTOR

The 7-way trailer connector (if

equipped) q installed on your

vehicle meets the requirements of

European standard ISO 1724.

This connector uses all 7 pins on

newer model trailers. An older

model trailer may not be compatible

with this connector.

Improper electrical wiring changes

can result in damage to both vehicle

and trailer components. When in

doubt about your trailer connection,

please contact a qualified tow-bar

specialist for assistance.

FEATURES AND CONTROLS

INSTRUMENT CLUSTER

NOTICE

High water pressure may damage components. Wash the vehicle by hand or

with a garden hose using mild soap. Certain products, including insect

repellents and chemicals, will damage the speedometer lens and other plastic

surfaces. Do not use alcohol to clean the instrument cluster. Do not allow

insect sprays to contact the lens. Immediately clean off any gasoline that

splashes on the instrument cluster.

q Speedometer

w Tachometer

e Indicator Lamps

r Mode Button

t Toggle Buttons

y Rider Information Center

SPEEDOMETER

The speedometer displays vehicle speed in either miles per hour (MPH) or

kilometers per hour (km/h).

TACHOMETER

The tachometer displays engine speed in revolutions per minute (RPM).

FEATURES AND CONTROLS

MODE AND TOGGLE BUTTONS

Press and hold the MODE button r to enter or exit the settings menu. Press

and release the MODE button to cycle through Area 1 modes and to select an

item.

Press and release either toggle button t to cycle through the options menu or

Area 2 modes. Press and hold either toggle button to reset an item. See page

58.

TIP

With the ignition key off, pressing the MODE button or either toggle button will

power up the Rider Information Center for 10 seconds to allow viewing of the

odometer and the clock.

INDICATOR LAMPS

INDICATOR ICON FUNCTION

Vehicle Speed When standard mode is selected, speed

displays in miles per hour.

When metric mode is selected, speed displays

in kilometers per hour.

Turn Signals One arrow flashes when the corresponding

turn signal is activated. Both arrows flash when

the hazard signal is activated. If there is a

problem in the signal system, the lamps will

flash at twice the normal rate.

Check Engine This indicator appears if a fault occurs. Do not

operate the vehicle if this warning appears.

Serious engine damage could result. Your

authorized POLARIS dealer can assist.

Check Battery This warning usually indicates that the vehicle

is operating at an RPM too low to keep the

battery charged. It may also occur when the

engine is at idle and high electrical load (lights,

cooling fan, accessories) is applied. Drive at a

higher RPM or recharge the battery to clear the

warning.

FEATURES AND CONTROLS

INDICATOR ICON FUNCTION

EPS Warning (if

equipped)

This indicator illuminates briefly when the key

is turned to the ON position. If the light remains

on, the EPS system is inoperative. See your

POLARIS dealer, or other qualified person, as

soon as possible for repair. Continued

operation could result in permanent damage to

the EPS unit and increased steering effort.

Engine Hot This lamp illuminates to indicate an overheated

engine. If the indicator flashes, the overheating

condition remains, and the system will

automatically reduce engine power.

Neutral This lamp illuminates when the transmission is

in neutral and the ignition key is in the ON

position.

Helmet/Seat Belt This lamp is a reminder to the operator to

ensure all riders are wearing helmets and seat

belts before operating. The driver’s seat belt is

equipped with a seat belt interlock. Vehicle

speed will be limited to 15 MPH (24 km/h) if the

seat belt is not secured.

High Beam This lamp illuminates when the headlamp

switch is set to high beam.

Park Brake (if

equipped)

Lamp illuminates when the Park Brake is

applied (if equipped).

FEATURES AND CONTROLS

INDICATOR ICON FUNCTION

Low Fuel This lamp illuminates when fuel level in the fuel

tank is low.

Speed Key

(optional

accessory)

Information about the speed key is provided in

the accessory kit.

Trailer Indicator This lamp illuminates when trailer turn signals

are active.

Brake Failure

Alarm

Lamp illuminates when Brake System (if Brake

Failure Alarm is equipped) detects low

pressure in brake hydraulic system.

ABS System The ABS System symbol (if equipped with ABS

System) is flashing when ABS is disabled by

driver. Whenever ABS failure is detected, the

ABS symbol illuminates. If this happens,

inspect the ABS system.

Overspeed

Indicator

The Overspeed symbol is illuminated when

speed exceeds the Speed Limitation function

(if equipped).

FEATURES AND CONTROLS

RIDER INFORMATION CENTER

qGear Indicator This indicator displays gear shifter position.

H = High Gear

L = Low Gear

N = Neutral

R = Reverse Gear

P = Park

– = Gear Signal Error (or shifter between gears)

wAWD Indicator This indicator shows whether 2X4, AWD, or TURF Mode is

active.

eService

Indicator

A flashing wrench symbol alerts the operator that the preset

service interval has been reached. Your POLARIS dealer, or

other qualified person, can provide scheduled maintenance.

See page 61 for resetting instructions.

rFuel Gauge The segments of the fuel gauge show the level of fuel in the

fuel tank. When the last segment clears, a low fuel warning is

activated. The outline of the fuel display will flash. Refuel

immediately.

tSpeed

Limitation (if

equipped)

This vehicle may be equipped with a maximum speed

limitation function. This would be displayed on the screen as

“LIM” followed by the speed. “LIM 30” for example.

The rider information center is located

in the instrument cluster. All segments

will light up for one second at start-up.

If the instrument cluster fails to

illuminate, a battery over-voltage may

have occurred and the instrument

cluster may have shut off to protect the

electronic speedometer. If this occurs,

your POLARIS dealer, or other qualified

person, can provide proper diagnosis.

The information center is set to display

standard units of measurement and a

12-hour clock at the factory. To change

to metric and/or a 24-hour clock hold

the mode button and cycle to the clock

menu. Use the directional arrows to

change the clock settings.

FEATURES AND CONTROLS

MODE INFORMATION DISPLAYS

The rider information center contains

three areas that display mode

information.

q Area 1 Modes Description

Engine Temperature Temperature of engine coolant

Vehicle Speed Speed of vehicle

Tachometer Engine speed (RPM)

w Area 2 Modes Description

Odometer The odometer records and displays

the distance traveled by the vehicle.

Trip Meters (T1/T2) A trip meter records the distance

traveled by the vehicle if reset before

each trip. To reset, see page 60.

Engine Hours Total hours of engine operation since

manufacture

Service Hours A flashing wrench symbol indicates

that the preset service interval has

been reached. To reset, see page 61.

Trip Time Time length of vehicle operation

since mode was last reset

e Area 3 Modes Description

Clock The clock displays time in a 12-hour

or 24-hour format. To reset, see page

59.

FEATURES AND CONTROLS

ACCESSING MENUS AND OPTIONS

GAUGE SETTINGS MENU

Press and release the MODE button to cycle through the Area 1 modes until the

desired default mode displays. See the Mode Information Displays section for

details.

Press and hold the MODE button to enter the settings menu.

The OPTIONS screen will display for a few seconds.

1. Press and release either toggle

button to cycle to the desired option.

2. Press MODE to select the option.

3. Press either toggle button to cycle to

the desired setting.

4. Press MODE to save and exit to the

settings menu.

5. Press and hold the MODE button to

exit the settings menu.

BACKLIGHT COLOR

The information center backlight can be

set to either blue or red.

1. Press and hold the MODE button to

enter the settings menu.

2. Press either toggle button to cycle to

the “BL COLOR” option. Press

MODE to select.

3. Press either toggle button to cycle to

the desired setting.

4. Press MODE to save and exit to the

settings menu,

FEATURES AND CONTROLS

BACKLIGHT BRIGHTNESS

The information center backlight can be set to either blue or red.

1. Press and hold the MODE button to

enter the settings menu.

2. Press either toggle button to cycle to

the “BL LEVEL” option. Press

MODE to select.

3. Press “UP” button to increase

brightness. Press “DOWN” button to

decrease brightness.

4. Press MODE to select and exit to

the settings menu.

CLOCK

The clock must be reset any time the battery has been disconnected or

discharged.

1. Press and hold the MODE button to

enter the settings menu.

2. Press either toggle button to cycle to

the “CLOCK” option. Press MODE to

select.

3. Press either toggle button to cycle to

the desired setting (12H or 24H).

Press MODE to select.

4. Press either toggle button to change

each segment of the clock. Press

MODE to accept a change and

advance to the next segment.

FEATURES AND CONTROLS

DISPLAY UNITS (STANDARD/METRIC)

1. Press and hold the MODE button to enter the settings menu.

2. Press either toggle button to cycle to the desired “UNITS” option (distance,

temperature or volume). Press MODE to select.

3. Press either toggle button to cycle to the desired setting.

4. Press MODE to save and exit to the settings menu.

TRIP METER

Use a trip meter to track the distance

traveled during a specific trip or period

of time. Reset the meter to zero before

traveling.

1. Press either toggle button to cycle to

the desired trip meter option (T1 or

T2).

2. Press and hold either toggle button

until the meter resets to zero.

TRIP TIME

Use a trip time meter to track the travel

time during a specific trip. Reset the

meter to zero before traveling.

1. Press either toggle button to cycle to

the trip time option (TT).

2. Press and hold either toggle button

until the meter resets to zero.

FEATURES AND CONTROLS

PROGRAMMABLE SERVICE INTERVAL

The service interval counter is programmed to 25 hours at the factory. As hours

of engine operation increase, the counter decreases. The wrench icon will flash

for about 10 seconds when the counter reaches zero (0), and each time the key

is turned on thereafter, until the counter is reset.

When this feature is enabled, it provides a convenient reminder to perform

routine maintenance. Refer to the Periodic Maintenance Chart for recommended

service intervals.

Use the following procedure to reset or change the service interval.

1. Press and hold the MODE button to

enter the settings menu.

2. Press either toggle button to cycle to

the “Service Hours” option. Press

MODE to select.

3. Press MODE to reset the existing

value and exit, or press either toggle

button to change the value. Press

MODE to save and exit to the

settings menu.

FEATURES AND CONTROLS

ENGINE ERROR CODES

The error screen displays only when the CHECK ENGINE indicator is on or

when it goes on and off during one ignition cycle. Error codes are not stored.

When the key is turned OFF, the code and message is lost, but will reappear if

the fault reoccurs after restarting the engine.

If the CHECK ENGINE lamp or the EPS lamp illuminates, retrieve the active

error codes from the display.

Failure Mode Indicator (FMI)

Suspect Parameter Number (SPN)

Code Count

1. Press and hold the MODE button to enter the settings menu.

2. Press either toggle button to cycle to the “DIAGCODE” option. Press MODE

to select.

3. More than one diagnostic code may be present. Press the toggle UP button

to see if more codes are present. Press MODE to select a code.

NOTICE

If the displayed code is an engine fault code, the CHECK ENGINE lamp will

blink. If the displayed code is an EPS fault code, the EPS lamp will blink.

4. Record the three (3) numbers displayed.

5. Press MODE to exit to the settings menu.

FEATURES AND CONTROLS

INSTRUMENT CLUSTER (ISRAEL MODELS)

OVERVIEW

NOTICE

The use of a high pressure washer may damage the instrument cluster. Wash

the vehicle by hand or with a garden hose using mild soap. Do not use alcohol

to clean the instrument cluster. Do not allow insect sprays to contact the lens.

Immediately clean off any gasoline that splashes on the instrument cluster.

Gear Indicator

H = High Gear

L = Low Gear

N = Neutral

R = Reverse Gear

P = Park

– = Gear Signal Error (or shifter between gears)

Display Area 2

This area displays odometer, trip meter, trip meter 2, voltage, engine

temperature, engine hour meter, programmable service hour interval,

ground speed, or engine RPM.

Display Area 1 This area displays engine RPM, ground speed, or coolant temperature.

Fuel Gauge

The segments of the fuel gauge show the level of fuel in the fuel tank.

When the last segment clears, a low fuel warning is activated. All

segments including the fuel icon will flash. Refuel immediately.

Service Indicator

A flashing wrench symbol alerts the operator that the preset service

interval has been reached. Your POLARIS dealer can provide scheduled

maintenance. See page 76 for more information.

Clock The clock displays time in a 12-hour or 24-hour format.

AWD Indicator Segments of the indicator illuminate based on drive mode engaged.

FEATURES AND CONTROLS

INDICATOR LAMPS

INDICATOR ICON FUNCTION

Vehicle Speed When standard mode is selected, speed

displays in miles per hour.

When metric mode is selected, speed displays

in kilometers per hour.

Turn Signals One arrow flashes when the corresponding

turn signal is activated. Both arrows flash when

the hazard signal is activated. If there is a

problem in the signal system, the lamps will

flash at twice the normal rate.

Check Engine This indicator appears if a fault occurs. Do not

operate the vehicle if this warning appears.

Serious engine damage could result. Your

authorized POLARIS dealer can assist.

Check Battery This warning usually indicates that the vehicle

is operating at an RPM too low to keep the

battery charged. It may also occur when the

engine is at idle and high electrical load (lights,

cooling fan, accessories) is applied. Drive at a

higher RPM or recharge the battery to clear the

warning.

EPS Warning (if

equipped)

This indicator illuminates briefly when the key

is turned to the ON position. If the light remains

on, the EPS system is inoperative. See your

POLARIS dealer, or other qualified person, as

soon as possible for repair. Continued

operation could result in permanent damage to

the EPS unit and increased steering effort.

Engine Hot This lamp illuminates to indicate an overheated

engine. If the indicator flashes, the overheating

condition remains, and the system will

automatically reduce engine power.

FEATURES AND CONTROLS

INDICATOR ICON FUNCTION

Neutral This lamp illuminates when the transmission is

in neutral and the ignition key is in the ON

position.

Helmet/Seat Belt This lamp is a reminder to the operator to

ensure all riders are wearing helmets and seat

belts before operating. The driver’s seat belt is

equipped with a seat belt interlock. Vehicle

speed will be limited to 15 MPH (24 km/h) if the

seat belt is not secured.

High Beam This lamp illuminates when the headlamp

switch is set to high beam.

Park Brake (if

equipped)

Lamp illuminates when the Park Brake is

applied (if equipped).

Low Fuel This lamp illuminates when fuel level in the fuel

tank is low.

Speed Key

(optional

accessory)

Information about the speed key is provided in

the accessory kit.

FEATURES AND CONTROLS

INDICATOR ICON FUNCTION

Trailer Indicator This lamp illuminates when trailer turn signals

are active.

Brake Failure

Alarm

Lamp illuminates when Brake System (if Brake

Failure Alarm is equipped) detects low

pressure in brake hydraulic system.

ABS System The ABS System symbol (if equipped with ABS

System) is flashing when ABS is disabled by

driver. Whenever ABS failure is detected, the

ABS symbol illuminates. If this happens,

inspect the ABS system.

Overspeed

Indicator

The Overspeed symbol is illuminated when

speed exceeds the Speed Limitation function

(if equipped).

FEATURES AND CONTROLS

DISPLAY AREA 1

Pressing the MODE button

will change the information

displayed in Area 1

DISPLAY AREA 1 FUNCTION

Speed The vehicle’s speed will be displayed in mph, or km/h.

Engine

Temperature

The vehicle’s current engine temperature will be

displayed.

RPM The vehicle’s RPM will be displayed.

Ambient

Temperature

(if equipped)

The current ambient temperature will be displayed.

FEATURES AND CONTROLS

DISPLAY AREA 2

Toggle the Up/Down

buttons to change the

information displayed in

Area 2 w.

DISPLAY AREA 2 FUNCTION

Odometer The vehicle’s odometer reading will be displayed.

Engine

Temperature

The vehicle Engine Temperature will be displayed.

Trip 1 The vehicle Trip 1 mileage will be displayed.

Trip 2 The vehicle Trip 2 mileage will be displayed.

RPM The vehicle RPM will be displayed.

Voltage The vehicle’s current battery voltage will be displayed.

Speed The vehicle’s current speed will be displayed.

Engine Hours The vehicle’s engine hours will be displayed.

Service Hours The vehicle’s service hours will be displayed.

FEATURES AND CONTROLS

OPTIONS MENU

From the options menu you

can view diagnostic codes,

access the advanced menu,

set the clock, and much more.

For a full list of available

options see below.

To enter the Options Menu,

press and hold the MODE

button.

OPTIONS MENU NOTES

Diagnostic Codes Only displays if fault codes are

present or stored

Advanced Menu (if equipped) Set maximum speed, and geofencing

settings.

Units - Distance Select MPH or KPH

Units - Temp Select between °F and °C

Clock (if equipped) Select between 12H or 24H, and set

time

Backlight Color Select between Blue or Red

Backlight Level Set backlight brightness level

Service Hours View/Set Service hours

Exit Menu Exit

FEATURES AND CONTROLS

UNIT SELECTION DISTANCE

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

2. Select “Units-Distance” from the Options Menu by pressing the MODE

button.

Reference the image shown above:

Press the MODE button.

Toggle the Up/Down Buttons to change the units (MPH or KPH)

With the correct unit displayed, Press the mode button which will set

the unit and return to the Options Menu.

3. To exit the Options Menu the user can select Exit Menu function from

Options Menu, can hold Mode Button and exit out of Options Menu, or not

press any button for 10 seconds, which will exit out of the Options Menu.

FEATURES AND CONTROLS

UNIT SELECTION TEMPERATURE

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

2. Select “Units - Temp” from the Options Menu by pressing the MODE button.

Reference the image shown above:

Press the MODE button.

Toggle the Up/Down Buttons to change the units (°F or °C)

With the correct unit displayed, Press the mode button which will set

the unit and return to the Options Menu.

3. To exit the Options Menu the user can select Exit Menu function from

Options Menu, can hold Mode Button and exit out of Options Menu, or not

press any button for 10 seconds, which will exit out of the Options Menu.

FEATURES AND CONTROLS

CLOCK

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

FEATURES AND CONTROLS

2. Select “Clock” from the Options Menu by pressing the MODE button.

Reference the image shown above:

Press the MODE button.

Toggle the Up/Down Buttons to change the units (12H or 24H)

With the correct unit displayed, Press the mode button which will set

the unit.

Toggle the Up/Down Buttons to change the units (Cycles Hours)

With the correct unit displayed, Press the mode button which will set

the unit.

Toggle the Up/Down Buttons to change the units (Cycles 10s of

Minutes)

With the correct unit displayed, Press the mode button which will set

the unit.

Toggle the Up/Down Buttons to change the units (Cycles 1s of

Minutes)

With the correct unit displayed, Press the mode button which will set

the unit and return to the Options Menu.

3. To exit the Options Menu the user can select Exit Menu function from

Options Menu, can hold Mode Button and exit out of Options Menu, or not

press any button for 10 seconds, which will exit out of the Options Menu.

FEATURES AND CONTROLS

BACK LIGHT COLOR

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

2. Select “Backlight Color” from the Options Menu by pressing the MODE

button.

Reference the image shown above:

Press the MODE button.

Toggle the Up/Down Buttons to change the units (Blue or Red)

With the correct unit displayed, Press the mode button which will set

the unit and return to the Options Menu.

3. To exit the Options Menu the user can select Exit Menu function from

Options Menu, can hold Mode Button and exit out of Options Menu, or not

press any button for 10 seconds, which will exit out of the Options Menu.

FEATURES AND CONTROLS

BACK LIGHT LEVEL

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

2. Select “Backlight Level” from the Options Menu by pressing the MODE

button.

Reference the image shown above:

Press the MODE button.

Toggle the Up/Down Buttons to change the units (Increase or De-

crease Level)

With the correct unit displayed, Press the mode button which will set

the unit and return to the Options Menu.

3. To exit the Options Menu the user can select Exit Menu function from

Options Menu, can hold Mode Button and exit out of Options Menu, or not

press any button for 10 seconds, which will exit out of the Options Menu.

FEATURES AND CONTROLS

SERVICE HOURS

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

2. Select “Service Hours” from the Options Menu by pressing the MODE button.

Reference the image shown above:

Press the MODE button.

Toggle the Up/Down Buttons to change the units (0, 5, 10 - 95, 100)

With the correct unit displayed, press the MODE button, which will set

the unit and return you to the Options Menu.

NOTICE

To reset service hours after they have counted down to "0.0", reselect the

existing setpoint or select a new service hour value.

3. To exit the Options Menu the user can select Exit Menu function from

Options Menu, can hold Mode Button and exit out of Options Menu, or not

press any button for 10 seconds, which will exit out of the Options Menu.

FEATURES AND CONTROLS

DIAGNOSTIC CODE

NOTICE

Diagnostic Code Screen will show available MIL that has come on during that

ignition cycle.

1. Press and hold the MODE button to enter the Options Menu.

NOTICE

“OPTIONS” will display on the screen for 3 seconds before showing first menu

item.

2. Select “Diagnostic Codes” from the Options Menu by pressing the MODE

button.

Toggle the Up/Down Buttons to cycle through Code(s).

NOTICE

This option will only be available if a fault code was set or is active during the

current ignition key 'on' cycle. Turning off the ignition will clear any save fault

codes from the gauge.

Reference the image shown above:

Area A will Display FMI (XX)

Area B will Display SPN (XXXXXX)

Clock Area will Display Count (XXX)

3. To exit the Options Menu the user can select Exit Menu function from

Options Menu, can hold Mode Button and exit out of Options Menu, or not

press any button for 10 seconds, which will exit out of the Options Menu.

FEATURES AND CONTROLS

DIAGNOSTIC DISPLAY CODE DEFINITIONS

Open Load:There is a break in the wires that lead to the item listed in the chart

(injector, fuel pump, etc.), or the item has failed.

Short-to-Ground:The wire is shorted to ground between the electronic control

unit and the item listed in the chart.

Shorted Load:The wires leading to the item listed in the chart are shorted

together, or the item has shorted internally.

Short-to-Battery:The wire leading from the item listed in the chart to the

electronic control unit is shorted to a wire at battery voltage.

DIAGNOSTIC CODES

COMPONENT CONDITION SPN FMI

Throttle Position

Sensor

Voltage Too High 51 3

Voltage Too Low 51 4

Engine Temperature

Sensor

Voltage Too High 110 3

Voltage Too Low 110 4

Temperature Too High 110 16

Engine Overheat

Shutdown 110 0

Intake Air

Temperature Sensor

Voltage Too High 105 3

Voltage Too Low 105 4

Manifold Absolute

Pressure Sensor

Voltage Too High 102 3

Voltage Too Low 102 4

Signal Out of Range 102 2

Crankshaft Position

Sensor

Circuit Fault 636 8

Plausibility Fault 636 2

Vehicle Speed Signal Speed Too High 84 8

Plausibility Fault 84 2

Gear Sensor Signal Voltage Too Low 523 4

Voltage Too Low 523 3

Signal Fault 523 2

FEATURES AND CONTROLS

DIAGNOSTIC CODES

COMPONENT CONDITION SPN FMI

Injector 1 (MAG) (SDI

Part Load)

Driver Circuit Open/

Grounded 651 5

Driver Circuit Short to

B+ 651 3

Driver Circuit

Grounded 651 4

Injector 2 (PTO) (SDI

Part Load)

Driver Circuit Open/

Grounded 652 5

Driver Circuit Short to

B+ 652 3

Driver Circuit

Grounded 652 4

Ignition Coil Primary

Driver 1 (MAG)

Driver Circuit Short to

B+ 1268 3

Ignition Coil Primary

Driver 2 (PTO)

Driver Circuit Short to

B+ 1269 3

Fuel Pump Driver

Circuit

Driver Circuit Open/

Grounded 1347 5

Driver Circuit Short to

B+ 1347 3

Driver Circuit

Grounded 1347 4

Fan Relay Driver

Circuit

Driver Circuit Open/

Grounded 1071 5

Driver Circuit Short to

B+ 1071 3

Driver Circuit

Grounded 1071 4

Idle Air Control Driver Circuit Open/

Grounded 634 5

Driver Circuit Short to

B+ 634 3

Driver Circuit

Grounded 634 4

Position Out of Range 634 7

Starter Enable Circuit Driver Circuit Open/

Grounded 1321 5

FEATURES AND CONTROLS

DIAGNOSTIC CODES

COMPONENT CONDITION SPN FMI

Driver Circuit Short to

B+ 1321 3

Driver Circuit

Grounded 1321 4

Chassis Relay Driver Circuit Open/

Grounded 520208 5

Driver Circuit Short to

B+ 520208 3

Driver Circuit

Grounded 520208 4

All Wheel Drive

Control

Driver Circuit Open/

Grounded 520207 5

Driver Circuit Short to

B+ 520207 3

Driver Circuit

Grounded 520207 4

System Power Voltage Too High 168 3

Voltage Too Low 168 4

Throttle Safety Signal Voltage Too High 520194 3

Voltage Too Low 520194 4

Signal Out of Range 520194 2

Throttle Stuck 520194 7

Active Descent

Control System

Driver Circuit Open/

Grounded 520203 5

Driver Circuit Short to

B+ 520203 3

Driver Circuit

Grounded 520203 4

Idle Speed Speed Too High 520211 3

Speed Too Low 520211 4

Right Hand Control Momentary Driveline

Mode Switch Press 520468 31

FEATURES AND CONTROLS

DIAGNOSTIC CODES

COMPONENT CONDITION SPN FMI

EPS MODELS ONLY

Vehicle Speed Sensor Data Valid But Above

Normal Operational

Range - Most Severe

Level

84 0

Data Erratic,

Intermittent Or

Incorrect

84 2

Abnormal Rate Of

Change 84 10

Received Network

Data In Error 84 19

System Power Data Valid But Above

Normal Operational

Range - Most Severe

Level

168 0

Voltage Above

Normal, Or Shorted To

High Source

168 3

Voltage Below

Normal, Or Shorted To

Low Source

168 4

Engine Speed Data Valid But Above

Normal Operational

Range - Most Severe

Level

190 0

Data Erratic,

Intermittent Or

Incorrect

190 2

Received Network

Data In Error 190 19

ECU Memory Bad Intelligent Device

Or Component 628 12

Out Of Calibration 628 13

Calibration Out Of Calibration 630 13

Steering Over Current

Shut Down

Current Above Normal

Or Grounded Circuit 520221 6

Steering Excessive

Current Error

Current Above Normal

Or Grounded Circuit 520222 6

FEATURES AND CONTROLS

DIAGNOSTIC CODES

COMPONENT CONDITION SPN FMI

EPS MODELS ONLY

Steering Torque

Partial Failure

Condition Exists 520223 31

Steering Torque Full

Failure

Condition Exists 520224 31

EPAS Inverter

Temperature

Data Valid But Above

Normal Operational

Range - Most Severe

Level

520225 0

Data Valid But Above

Normal Operating

Range - Moderately

Severe Level

520225 16

EPAS

Communications

Receive Data Error

Data Erratic,

Intermittent Or

Incorrect

520226 2

Condition Exists 520226 31

Position Encoder

Error

Root Cause Not

Known 520228 11

Bad Intelligent Device

Or Component 520228 12

Condition Exists 520228 31

EPAS Software Error Bad Intelligent Device

Or Component 520229 12

Condition Exists 520229 31

EPAS Power Save

Condition

Condition Exists 520231 31

EPS SEPIC Voltage

Error

Voltage Above

Normal, Or Shorted To

High Source 524086 3

Voltage Below

Normal, Or Shorted To

Low Source

524086 4

FEATURES AND CONTROLS

OPERATION

IMPORTANT INFORMATION

WARNING

Failure to operate the vehicle properly can result in a collision, loss of control,

accident or rollover, which may result in serious injury or death. Read and

understand all safety warnings outlined in the safety section of this owner’s

manual.

VEHICLE BREAK-IN PERIOD

The break-in period for your new vehicle is the first 25 hours of operation, or the

time it takes to use the first 2 full tanks of gasoline. No single action on your part

is as important as a proper break-in period. Careful treatment of a new engine

will result in more efficient performance and longer life for the engine. Perform

the following procedures carefully.

NOTICE

Excessive heat build-up during the first 3 hours of operation will damage close-

fitted engine parts and drive components. Do not operate at full throttle or high

speeds during the first 3 hours of use.

ENGINE AND DRIVETRAIN BREAK-IN

1. Fill the fuel tank with gasoline. Always exercise extreme caution whenever

handling gasoline.

2. Check the oil level. Add the recommended oil as needed to maintain the oil

level in the safe operating range.

3. Complete the New Operator Driving Procedures.

4. Avoid aggressive use of the brakes.

5. Vary throttle positions. Do not operate at sustained idle.

6. Pull only light loads.

7. Perform regular checks on fluid levels, controls and areas outlined on the

daily pre-ride inspection checklist.

8. During the break-in period, change both the oil and the filter at 25 hours or

one month.

9. Check fluid levels of transmission and all gearcases after the first 25 hours of

operation and every 100 hours thereafter.

OPERATION

BRAKE SYSTEM BREAK-IN

Apply only moderate braking force for the first 50 stops. Aggressive or overly

forceful braking when the brake system is new could damage brake pads and

rotors.

PVT BREAK-IN (CLUTCHES/BELT)

A proper break-in of the clutches and drive belt will ensure a longer life and

better performance. Break in the clutches and belt by operating at slower

speeds during the break-in period as recommended. Pull only light loads. Avoid

aggressive acceleration and high speed operation during the break-in period.

If a belt fails, always clean any debris from the PVT intake and outlet duct and

from the clutch and engine compartments when replacing the belt.

KNOW YOUR RIDING AREA/TREAD LIGHTLY®

Familiarize yourself with all laws and regulations concerning the operation of this

vehicle in your area. Respect the environment in which you ride your vehicle.

Find out where the designated riding areas are by contacting your POLARIS

dealer, a local riding club, or local officials.

Help keep our trails open for recreational vehicle use. As an off-road enthusiast,

you represent the sport and can set a good example (or a poor example) for

others to follow. Tread lightly® Operate with respect for the terrain, avoid

littering, and always stay on the designated trails.

TRAIL ETIQUETTE

Always practice good etiquette when riding. Allow a safe distance between your

vehicle and other vehicles operating in the same area. Communicate to

oncoming operators by signaling the number of vehicles in your group. When

stopping, move your vehicle to the edge of the trail as far as possible to allow

others to pass safely.

OPERATION

SAFE OPERATION PRACTICES

1. Visit the Recreational Off-Highway Vehicle Association® web site and take

the free on-line training course. Complete the recommended safety training

before operating this vehicle. Visit www.rohva.org or call 866-267-2751.

2. Do not allow anyone under 16 years of age or without a valid driver’s license

to operate this vehicle.

3. Engine exhaust fumes are poisonous and can cause loss of consciousness

or death in a short time. Never start the engine or let it run in an enclosed

area.

4. Never operate with accessories not approved by POLARIS for use on this

vehicle.

5. Operate this vehicle off-road only. Never operate this vehicle on any public

street, road or highway, including dirt and gravel roads (unless designated for

off-highway use).

6. Use caution and drive at reduced speeds in conditions of reduced visibility

such as fog, rain and darkness. Clean headlights frequently and replace

burned out headlamps promptly.

7. Always operate at a speed that's appropriate for the terrain, the visibility and

operating conditions and your skills and experience. Never operate at

excessive speeds. Never attempt wheelies, jumps, or other stunts. Keep

both hands on the steering wheel during operation.

8. Never consume alcohol or drugs before or while operating this vehicle.

9. Always use the size and type of tires specified for your vehicle. Always

maintain proper tire pressure.

10. Never operate a damaged vehicle. After any rollover or accident, have a

qualified service dealer inspect the entire machine for possible damage.

11. Never operate the vehicle on a frozen body of water unless you have first

verified that the ice is sufficiently thick to support the weight and moving force

of the vehicle, you and your cargo, together with any other vehicles in your

party.

12. Do not touch hot exhaust system components. Always keep combustible

materials away from the exhaust system.

13. Always remove the ignition key when the vehicle is not in use to prevent

unauthorized use.

OPERATION

PRE-RIDE INSPECTION

WARNING

Failure to inspect and verify that the vehicle is in safe operating condition

before operating increases the risk of an accident. Always inspect the vehicle

before each use to make sure it's in safe operating condition.

ITEM REMARKS PAGE

Brake system/pedal travel Ensure proper operation page 142

Brake fluid Ensure proper level page 142

Front suspension Inspect, lubricate if necessary page 121

Rear suspension Inspect, lubricate if necessary page 121

Steering Ensure free operation -

Tires Inspect condition and pressure page 145

Wheels/fasteners Inspect, ensure fastener tightness page 145

Frame nuts, bolts, fasteners Inspect, ensure tightness -

Drive Belt Inspect, ensure installed correctly -

Fuel and oil Ensure proper levels page 122

Coolant level Ensure proper level page 130

Coolant hoses Inspect for leaks -

Throttle Ensure proper operation page 43

Indicator lights/switches Ensure proper operation page

page 38

Intake pre-filters Inspect, clean -

Headlamps Check operation, apply POLARIS dielectric

grease when lamp is replaced

page 148

Brake light/tail lamps Check operation -

Seat Latch Push down on the seat back to ensure the latch

is secure

Seat Belt Check length of belt for damage, check latches

for proper operation

page 45

OPERATION

ITEM REMARKS PAGE

Cab Doors (if equipped) Check doors and latches for wear or damage. -

Grass and leaves Remove grass, leaves, foreign matter, and other

flammable material or debris, especially near

the exhaust system.

STARTING THE ENGINE

OFF / Battery Isolator Function

LIGHTS ON

POSITION LIGHTS ON

START

1. Position the vehicle on a level surface outdoors or in a well-ventilated area.

2. Sit in the driver's seat and fasten the seat belt. Always make sure all cab

doors are closed and latched when riding in this vehicle.

3. Place the transmission in PARK or NEUTRAL.

4. Disengage the park brake.

5. Apply the brakes. Do not press the throttle pedal while starting the engine.

6. Turn the ignition key to the START position. Engage the starter for a

maximum of five seconds. Release the key when the engine starts. Turn the

key to either LIGHTS ON or POSITION LIGHTS ON.

If the engine does not start within five seconds, return the ignition switch to

the OFF position and wait five seconds. Repeat steps 6 and 7 until the

engine starts.

7. Vary the engine RPM slightly with the throttle to aid in warm up until the

engine idles smoothly.

NOTICE

Operating the vehicle immediately after starting could cause engine damage.

Allow the engine to warm up for several minutes before operating the vehicle.

OPERATION

USING LOW GEAR

Low gear is the primary driving range for the RANGER. High gear is intended for

use on hard-packed surfaces with light loads. Whenever the vehicle is left

unattended, always place the transmission in PARK.

Always shift into low gear for any of the following conditions.

• Operating in rough terrain or over obstacles

• Loading the vehicle onto a trailer

• Towing heavy loads

• Driving slowly - under 10 MPH (16 km/h)

• Climbing hills

STOPPING THE ENGINE

1. Release the throttle pedal completely and brake to a complete stop.

2. Place the transmission in PARK.

3. Turn the key to the OFF position.

4. Slowly release the brake pedal and make sure the transmission is in PARK

before exiting the vehicle.

WARNING

A rolling vehicle can cause serious injury. Always place the transmission in

PARK before stopping the engine.

COLD WEATHER OPERATION

If the vehicle is used year-round, check the oil level frequently. A rising oil level

could indicate the accumulation of contaminates such as water or excess fuel in

the bottom of the crankcase. Water in the bottom of the crankcase can lead to

engine damage and must be drained. Water accumulation increases as outside

temperature decreases.

OPERATION

BRAKING

1. Release the throttle pedal completely.

NOTICE

When the throttle pedal is released completely and engine speed slows to near

idle, the vehicle has no engine braking.

2. Press on the brake pedal evenly and firmly. Practice starting and stopping

(using the brakes) until you're familiar with the controls.

PARKING THE VEHICLE

1. Stop the vehicle on a level surface. When parking inside a garage or other

structure, be sure that the structure is well ventilated and that the vehicle is

not close to any source of flame or sparks, including any appliance with pilot

lights.

2. Place the transmission in PARK.

3. Turn the engine off.

4. Engage the parking brake (if equipped).

5. Slowly release the brake pedal and make sure the transmission is in PARK

before exiting the vehicle.

6. Remove the ignition key to prevent unauthorized use.

OPERATION

HAULING CARGO

WARNING

Overloading the vehicle or carrying or towing cargo improperly can alter

vehicle handling and may cause loss of control or brake instability. Always

follow these precautions when hauling cargo:

Never exceed the stated load capacity for this vehicle.

REDUCE SPEED AND ALLOW GREATER DISTANCES FOR BRAKING

WHEN HAULING CARGO.

NEVER EXCEED THE MAXIMUM WEIGHT CAPACITY of the vehicle. When

determining the weight you are adding to the vehicle, include the weight of the

operator, passenger, accessories, loads in the rack or box and the load on the

trailer tongue. The combined weight of these items must not exceed the

maximum weight capacity.

Always load the cargo box with the load as far forward and as low as possible.

When operating over rough or hilly terrain, reduce speed and cargo to maintain

stable driving conditions.

Always operate the vehicle with extreme care when hauling or towing loads.

Slow down and drive in the lowest gear available.

SECURE ALL LOADS BEFORE OPERATING. Unsecured loads can create

unstable operating conditions, which could result in loss of control of the

vehicle.

OPERATE ONLY WITH STABLE AND SAFELY ARRANGED LOADS. When

handling off-centered loads that cannot be centered, securely fasten the load

and operate with extra caution.

Always attach the tow load to the hitch point designated for your vehicle.

HEAVY LOADS CAN CAUSE BRAKING AND CONTROL PROBLEMS. Use

extreme caution when applying brakes with a loaded vehicle. Avoid terrain or

situations that may require backing downhill.

USE EXTREME CAUTION when operating with loads that extend over the

rack sides. Stability and maneuverability may be adversely affected, causing

vehicle rollover.

DO NOT TRAVEL FASTER THAN THE RECOMMENDED SPEEDS. Vehicle

should never exceed 10 MPH (16 km/h) while towing a load on a level grass

surface. Vehicle speed should never exceed 5 MPH (8 km/h) when towing

loads in rough terrain, while cornering, or while ascending or descending a hill.

If the vehicle is capable, never exceed 43 MPH (70 km/h) if total payload

exceeds 335 lbs. (152 kg).

Carrying a passenger in the cargo box could result in a fall from the vehicle or

contact with moving components. Never allow a passenger to ride in the cargo

box.

Your vehicle has been designed to carry or tow specific capacities. Reduce

speed and allow a greater distance for braking when carrying cargo.

OPERATION

Loads should be centered on the vehicle and carried as low as possible in the

box. For stability on rough or hilly terrain, reduce both speed and cargo.

Exercise caution if the cargo load extends over the side of the box.

Always read and understand the load distribution warnings listed on warning

labels and in this manual. Never exceed the maximum capacities specified for

your vehicle.

BELT LIFE

To extend belt life, use low gear when hauling or towing heavy cargo.

TOWING LOADS

WARNING

Towing improperly can alter vehicle handling and may cause loss of control or

brake instability.

Always follow these precautions when towing:

1. Never load more than 68 kg (150 lbs.) tongue weight on the towing bracket.

2. When towing a disabled vehicle, place the disabled vehicle’s transmission in

neutral. Do not operate the vehicle faster than 16 km/h (10 MPH) when

towing.

3. Towing a trailer increases braking distance. Do not operate the vehicle faster

than 16 km/h (10 MPH) when towing.

4. Do not tow more than the recommended weight for the vehicle.

5. Attach a trailer to the trailer hitch bracket only. Do not attach a trailer to any

other location, which could result in loss of control of the vehicle.

6. The total load (operator, accessories, cargo and weight on hitch) must not

exceed the maximum weight capacity of the vehicle.

MAXIMUM

UNBRAKED

TRAILER

MASS

MAXIMUM

BRAKED

TRAILER

MASS

TOTAL

TOWED

LOAD

WEIGHT

(15° GRADE)

TOTAL HITCH

VERTICAL

WEIGHT

MAXIMUM

TOWING

SPEED

730 kg

(1609 lbs.)

1000 kg

(2205 lbs.)

386 kg

(850 lbs.)

68 kg

(150 lbs)

16 km/h

(10 MPH)

OPERATION

DUMPING THE CARGO BOX

To dump the cargo box, do the following:

1. Select a level site to dump the cargo box. Do not attempt to dump or unload

the vehicle while parked on an incline.

2. Apply the brakes.

3. Shift the gear selector to the Park position.

4. Turn the key to the off position.

5. Dismount vehicle.

6. Ensure that the cargo is positioned evenly or toward the front of the cargo

box.

7. Open the tailgate.

8. Stand clear and pull up on the cargo box release lever.

9. Lift the front of the cargo box to dump the cargo.

10. Lower the cargo box and push down securely to latch.

11. Close the tailgate.

WARNING

Operating the vehicle while the cargo box is raised could result in severe injury.

The box could close unexpectedly and cause injury to the driver or passenger.

The rear tires will also catch the rear of a raised box, damaging the vehicle and

creating hazardous driving conditions. Never operate this vehicle with the

cargo box in the raised position.

OPERATION

ALL WHEEL DRIVE/REAR DIFFERENTIAL

SYSTEM

If your model is equipped with a lockable differential, you can choose to operate

with an open differential or a closed differential.

ENGAGING AWD

NOTICE

Switching to AWD while the rear wheels are spinning may cause severe drive

shaft and clutch damage. Always switch to AWD while the rear wheels have

traction or are at rest.

All-Wheel Drive (AWD)

Differential Lock (2WD)

Differential Unlock (TURF Mode)

Press the top of the driveline mode switch to engage All Wheel Drive (AWD).

The 4X4 indicator illuminates in the rider information center to indicate that the

vehicle is in AWD. When the AWD switch is on, the front gearcase will

automatically engage any time the rear wheels lose traction. When the rear

wheels regain traction, the front gearcase will automatically disengage. There is

no limit to the length of time the vehicle may remain in AWD. Initially, the

vehicle's electronic system will not enable the AWD until the engine RPM is

below 3100. Once enabled, the AWD remains enabled until the switch is turned

off. If the switch is turned off while the front gearcase is moving, it will not

disengage until the rear wheels regain traction.

Engage the AWD before getting into conditions where front wheel drive may be

needed. If the rear wheels are spinning, release the throttle before switching to

AWD.

OPERATION

DISENGAGING AWD

Move the driveline mode switch to the center or bottom position to disengage

AWD. If the switch is turned off while the front hubs are driving, they will not

release until the rear wheels regain traction.

In some situations, the front gearcase may remain locked after turning the AWD

switch off. If this occurs, you may notice increased steering effort and some

vehicle speed restriction. Perform the following procedure to unlock the front

gearcase.

To disengage AWD, do the following:

1. Stop the vehicle.

2. Operate in reverse for at least 3 m.

3. Stop completely.

4. Shift into low gear and drive forward.

5. If the front gearcase remains locked after following these instructions, see

your dealer or other qualified service person for service.

LOCKING THE DIFFERENTIAL

Move the switch to the center position to lock the differential and operate in two

wheel drive (2WD). Locking the differential in slippery or low traction conditions

helps improve traction. When the rear differential is locked, both rear wheels

rotate at the same speed.

UNLOCKING THE DIFFERENTIAL (TURF MODE)

When operating in TURF mode, the inside rear wheel will rotate independently

from the outside wheel during turns. Operate in TURF mode only as needed to

protect smooth, level surfaces from tire damage. DO NOT operate in TURF

mode when climbing or descending hills, when sidehilling, or when operating on

uneven, loose, or slippery terrain such as sand, gravel, ice, snow, obstacles, and

water crossings. Always operate in AWD on these types of terrain.

WARNING

Operating in TURF mode (if equipped) when on sloped, uneven, or loose

terrain could cause loss of control and result in serious injury or death. One

rear wheel may slip and lose traction or may lift up and grab when it touches

the ground again.

Press the bottom of the switch to unlock the differential and allow the rear drive

wheels to operate independently (1WD). When the rear differential is unlocked,

the rear wheels can rotate at different speeds. Unlock the differential to make

maneuvering easier and minimize damage to turf.

OPERATION

NOTICE

Damage to the differential can occur if it is engaged while the vehicle is

traveling at high speeds or while the rear wheels are spinning. Slow the vehicle

to nearly stopped before engaging the differential.

WARNING

Never operate in TURF mode (if equipped) while operating on a hill or other

irregular terrain. Always move the switch to AWD before ascending or

descending a hill.

DRIVING PROCEDURES

NEW OPERATOR DRIVING PROCEDURES

1. Read and understand the owner's manual and all warning and instruction

labels before operating this vehicle.

2. Visit the Recreational Off-Highway Vehicle Association® web site and take

the free on-line training course. Visit www.rohva.org or call 866-267-2751.

Hands-on training is also available through ROHVA®.

3. Perform the pre-ride inspection.

4. Do not tow or carry cargo during this period.

5. Select an open area that allows room to familiarize yourself with vehicle

operation and handling.

6. The driver must wear helmet, eye protection, gloves, long-sleeve shirt, long

pants, over-the-ankle boots and seat belt at all times.

7. Sit in the driver's seat and fasten the seat belt.

8. Always make sure all cab doors are closed and latched when riding in this

vehicle.

9. Place the transmission in PARK.

10. Start the engine.

11. Apply the brakes and shift into low gear.

12. Check your surroundings and determine your path of travel.

13. Keeping both hands on the steering wheel, slowly release the brakes and

depress the throttle with your right foot to begin driving.

OPERATION

14. Drive slowly at first. On level surfaces, practice starting, stopping, turning,

maneuvering, using the throttle and brakes and driving in reverse. Learn how

the vehicle handles when making both left and right turns at a slow speed.

WARNING

Operating in TURF mode (if equipped) when on sloped, uneven, or loose

terrain could cause loss of control and result in serious injury or death. One

rear wheel may slip and lose traction or may lift up and grab when it touches

the ground again.

15. Increase speed only after mastering all maneuvers at a slow speed.

16. After you become skilled at making turns and begin to operate at faster

speeds, follow these precautions:

• Avoid sharp turns.

• Never turn while applying heavy throttle.

• Never make abrupt steering maneuvers.

• Operate at speeds appropriate for your skills, the conditions and the

terrain.

• DO NOT do power slides, “donuts”, jumps or other driving stunts.

DRIVING WITH A PASSENGER

• Perform the pre-ride inspection.

• Make sure all passengers are at least 12 years of age and tall enough to

comfortably and safely sit in a passenger seat with the seat belt secured, put

both feet on the floor and grasp the hand hold.

• Make sure all passengers are wearing helmets, eye protection, gloves, long-

sleeve shirt, long pants and over-the-ankle boots.

• Make sure all cab nets or doors (if equipped) are properly secured.

• Do not carry more than the recommended number of passengers for your

vehicle.

• Allow a passenger to ride only in a passenger seat.

• Slow down. Always travel at a speed appropriate for your skills, your

passengers’ skills, and operating conditions. Avoid unexpected or aggressive

maneuvers that could cause discomfort or injury to a passenger.

• Vehicle handling may change with a passenger and/or cargo on board. Allow

more time and distance for braking.

• Always follow all operating guidelines as outlined on safety labels and in this

manual.

OPERATION

DRIVING ON SLIPPERY SURFACES

WARNING

Skidding or sliding can cause loss of control or rollover (if tires regain traction

unexpectedly). When operating on slippery surfaces such as ice or loose

gravel, reduce speed and use extra caution to reduce the chance of skidding or

sliding out of control. Do not operate on excessively slippery surfaces.

When driving on slippery surfaces such as wet trails, loose gravel, or ice, be

alert for the possibility of skidding and sliding. Follow these precautions when

encountering slippery conditions:

• Do not operate on excessively rough, slippery or loose terrain.

• Slow down before entering slippery areas.

• Maintain a high level of alertness, reading the trail and avoiding quick, sharp

turns, which can cause skids.

• Engage all-wheel drive before wheels begin to lose traction.

NOTICE

Severe damage to the drive train may occur if the AWD is engaged while the

wheels are spinning. Always allow the wheels to stop spinning before engaging

AWD.

• Correct a skid by turning the steering wheel in the direction of the skid. Never

apply the brakes during a skid.

OPERATION

DRIVING OVER OBSTACLES

Follow these precautions when operating over obstacles:

• Always check for obstacles before operating in a new area.

• Look ahead and learn to read the terrain. Be constantly alert for hazards such

as logs, rocks and low hanging branches.

• Travel slowly and use extra caution when operating on unfamiliar terrain. Not

all obstacles are immediately visible.

• Move the gear selector to Low Gear, if needed.

• Avoid operating over large obstacles such as large rocks and fallen trees. If

unavoidable, use extreme caution and operate slowly.

• Always have all passengers dismount and move away from the vehicle before

operating over an obstacle that could cause a rollover.

DRIVING UPHILL

Whenever traveling uphill, follow these precautions:

• Avoid excessively steep hills.

• ADC Models: Always operate in low gear and engage ADC 4X4 before

ascending or descending a hill.

• Always travel straight uphill.

• Keep both feet on the floor.

• Always check the terrain carefully before ascending any hill. Never climb hills

with excessively slippery or loose surfaces.

• Proceed at a steady rate of speed and throttle opening. Never open the

throttle suddenly.

• Never go over the crest of a hill at high speed. An obstacle, a sharp drop, or

another vehicle or person could be on the other side of the hill.

DRIVING DOWNHILL

When driving downhill, follow these precautions:

• Avoid excessively steep hills.

• ADC Models: Always operate in low gear and engage ADC 4X4 before

ascending or descending a hill.

• Drive straight downhill. Avoid descending a hill at an angle, which would

cause the vehicle to lean sharply to one side. Travel straight downhill when

possible.

• Slow down.

• Apply the brakes slightly to aid in slowing.

OPERATION

ACTIVE DESCENT CONTROL (ADC) SYSTEM (IF

EQUIPPED)

The ADC system allows engine braking to all four wheels when the vehicle

descends a hill or incline. The ADC system is automatically engaged when the

transmission is in gear (high, low or reverse). The ADC system automatically

disengages when the transmission is shifted to neutral or park.

DRIVING ON A SIDEHILL (SIDEHILLING)

Driving on a sidehill is not recommended. Improper procedure could cause loss

of control or rollover. Avoid crossing the side of any hill unless absolutely

necessary.

If crossing a sidehill is unavoidable, follow these precautions:

• Slow down.

• Exercise extreme caution.

• Avoid crossing the side of a steep hill.

• ADC Models: Always operate in low gear and engage ADC 4X4 before

ascending or descending a hill.

DRIVING THROUGH WATER

Your vehicle can operate through water up to a maximum recommended depth

equal to the floorboards.

NOTE

If your vehicle becomes immersed or is operated in water that exceeds the

floor level, service is required before starting the engine. Your dealer can

provide this service. If it's impossible to bring the vehicle in before starting the

engine, perform the service outlined in the Spark Arrester section, and take the

vehicle in for service at the first opportunity.

Follow these procedures when operating through water:

1. Determine water depths and current before entering water.

2. Choose a crossing where both banks have gradual inclines.

3. Proceed slowly, avoiding rocks and obstacles.

OPERATION

4. Avoid operating through deep or fast-flowing water.

WARNING

The large tires on your vehicle may cause the vehicle to float in deep or fast-

flowing water, which could result in loss of control and lead to serious injury or

death. Never cross deep or fast-flowing water with your vehicle

5. After leaving water, always dry the brakes by applying light pressure to the

pedal repeatedly until braking action is normal.

NOTE

After running your vehicle in water, it's critical that you perform the services

outlined in the Periodic Maintenance Chart. Give special attention to engine oil,

transmission oil, front and rear gearcases (if equipped), and all grease fittings.

DRIVING IN REVERSE

Follow these precautions when operating in reverse:

• Always check for obstacles or people behind the vehicle. Always inspect left

and right fields of vision before backing.

• Always avoid backing downhill.

• Back slowly.

• Apply the brakes lightly for stopping.

• Avoid turning at sharp angles.

• Never open the throttle suddenly.

• Do not drive in reverse while the cargo box is raised.

PARKING THE VEHICLE

To park the vehicle, do the following:

1. Apply the brakes. Stop the vehicle on a level surface.

2. When parking inside a garage or other structure, be sure that the structure is

well ventilated and that the vehicle is not close to any source of flame or

sparks, including any appliance with pilot lights.

3. Place the transmission in PARK.

4. Engage the park brake.

5. Turn the engine off.

100

OPERATION

6. Slowly release the brake pedal and make sure the transmission is in PARK

before exiting the vehicle

7. Remove the ignition key to prevent unauthorized use.

PARKING ON AN INCLINE

Avoid parking on an incline if possible. If it's unavoidable, follow these

precautions:

1. Apply the brakes.

2. Place the transmission in PARK.

3. Engage the parking brake (if equipped).

4. Turn the engine off.

5. Slowly release the brake pedal and make sure the transmission is in PARK

before exiting the vehicle.

6. Block the rear wheels on the downhill side.

BOARDING AND EXITING THE VEHICLE

• Never try to climb onto or exit the vehicle while it is moving.

• Do not exit the vehicle by jumping off.

• Always face the vehicle when boarding or exiting.

• Do not grab controls as hand supports. This may cause inadvertent machine

movements.

• Always keep vehicle steps and flooring clean to prevent slippery conditions.

101

OPERATION

102

WINCH GUIDE

WINCH SAFETY

These safety warnings and instructions apply if your vehicle came equipped with

a winch or if you choose to add an accessory winch to your vehicle.

WARNING

Improper winch use can result in SEVERE INJURY or DEATH. Always follow

all winch instructions and warnings in this manual.

Your winch may have a cable made of either wire rope or specially designed

synthetic rope. The term “winch cable” will be used for either unless noted

otherwise.

WINCH SAFETY PRECAUTIONS

1. Read all sections of this manual.

2. Never use alcohol or drugs before or while operating the winch.

3. Never allow children under 16 years of age to operate the winch.

4. Always wear eye protection and heavy gloves when operating the winch.

5. Always keep body, hair, clothing and jewelry clear of the winch cable, fairlead

and hook when operating winch.

6. Never attempt to “jerk” a load attached to the winch with a moving vehicle.

See the Shock Loading section on page 111.

7. Always keep the area around the vehicle, winch, winch cable, and load clear

of people (especially children) and distractions while operating the winch.

8. Always turn the vehicle ignition power OFF when it and the winch are not

being used.

9. Always be sure that at least five (5) full turns of winch cable are wrapped

around the winch drum at all times. The friction provided by this wrapped

cable allows the drum to pull on the winch cable and move the load.

10. Always apply your vehicle’s park brake and/or park mechanism to hold the

vehicle in place during winching. Use wheel chocks if needed.

11. Always align the vehicle and winch with the load directly in front of the

vehicle as much as possible. Avoid winching with the winch cable at an angle

to the winching vehicle’s centerline whenever possible.

103

WINCH GUIDE

12. If winching at an angle is unavoidable, follow these precautions:

a. Look at the winch drum occasionally. Never let the winch cable “stack” or

accumulate at one end of the winch drum. Too much winch cable at one

end of the winch drum can damage the winch and the winch cable.

b. If stacking occurs, stop winching. Follow step 15 of Winch Operation to

feed and rewind the cable evenly before continuing the winch operation.

13. Never winch up or down at sharp angles. This can destabilize the winching

vehicle and possibly cause it to move without warning.

14. Never attempt to winch loads that weigh more than the winch’s rated

capacity.

15. The winch motor may become hot during winch use. If you winch for more

than 45 seconds, or if the winch stalls during operation, stop winching and

permit the winch to cool down for 10 minutes before using it again.

16. Never touch, push, pull or straddle the

winch cable while winching a load.

17. Never let the winch cable run through

your hands, even if wearing heavy gloves.

18. Never release the clutch on the winch

when the winch cable is under load.

19. Never use the winch for lifting or

transporting people.

20. Never use the winch to hoist or suspend a

vertical load.

21. Always inspect your winch and winch cable before each use.

22. Never winch the hook fully into the winch. This can cause damage to winch

components.

23. Unplug the remote control from the vehicle when the winch is not in use to

prevent inadvertent activation and use by unauthorized persons.

24. Never grease or oil the winch cable. This will cause the winch cable to collect

debris that will shorten the life of the cable.

104

WINCH GUIDE

WINCH OPERATION

Read the Winch Safety Precautions in the preceding pages before using your

winch.

TIP

Consider practicing the operation and use of your winch before you actually

need to use it in the field.

WARNING

Improper winch use can result in SEVERE INJURY or DEATH. Always follow

all winch instructions and warnings in this manual.

Each winching situation is unique.

• Take your time to think through the winching you are about to do.

• Proceed slowly and deliberately.

• Never hurry or rush during winching.

• Always pay attention to your surroundings.

• You may need to change your winching strategy if it is not working.

• Always remember that your winch is very powerful.

• There are simply some situations that you and your winch will not be able to

deal with. Do not be afraid to ask others to help when this happens.

1. Always inspect the vehicle, winch, winch cable and winch controls for any

signs of damage or parts in need of repair or replacement before each use.

Pay particular attention to the first 3 feet (1 meter) of winch cable if the winch

is being used (or has been used) for lifting an accessory plow assembly.

Promptly replace any worn or damaged cable.

2. Never operate a winch or a vehicle in

need of repair or service.

3. Always apply your vehicle’s park brake

and/ or park mechanism to hold the

vehicle in place during winching. Use

wheel chocks if needed.

4. Always use the hook strap when handling

the hook.

105

WINCH GUIDE

WARNING

Never put your fingers into the hook. This could lead to SEVERE INJURY.

• Attach the hook itself onto the load or use a tow strap or chain to secure the

load to the winch cable.

TIP

A “tow strap” is NOT intended to stretch. A “recovery strap” is designed to

stretch.

WARNING

Never use a recovery strap when winching due to the excessive energy that

can be released if the winch cable breaks. This can result in SEVERE INJURY

or DEATH. See the Shock Loading section on page 111.

• Never hook the winch cable back onto itself. This will damage the winch cable

and may result in winch cable failure.

WARNING

Replace the winch cable at the first sign of damage to prevent SEVERE

INJURY or DEATH in the event of failure. For your safety, always replace

POLARIS winch parts (including the cable) with genuine POLARIS

replacement parts available at your authorized POLARIS dealer, or other

qualified dealer.

106

WINCH GUIDE

c. On a long pull, it may be necessary to stop winching so that the damper

can be repositioned to the new mid-point of the winch cable. Always

release the tension on the winch cable before repositioning the damper.

d. Avoid being directly in line with the winch cable whenever possible. Also,

never permit others to stand near or in line with the winch cable during

winch operation.

9. Never hook the winch cable back onto itself. This will damage the winch

cable and may result in winch cable failure.

10. Never use straps, chains or other rigging items that are damaged or worn.

11. The ONLY time a winch-equipped vehicle should be moving when using the

winch is when that vehicle itself is stuck. The winch equipped vehicle should

NEVER be in motion to “shock” load the winch cable in an attempt to move a

second stuck vehicle. See the Shock Loading section on page 111. For your

safety, always follow these guidelines when winching a vehicle free:

a. Release the winch clutch and spool out the necessary length of winch

cable.

b. Align the winch cable as close as possible to the winching vehicle’s

centerline.

c. Attach the winch cable hook to the anchor point or the stuck vehicle’s

frame following instructions in this manual.

d. Re-engage the clutch on the winch.

e. Slowly winch in the slack in the winch cable.

f. Select the proper vehicle gear to propel the stuck vehicle in the direction

of winching.

g. Shift to the lowest gear available on the stuck vehicle.

h. Slowly and carefully apply vehicle throttle and winch together to free the

vehicle.

i. Stop winching as soon as the stuck vehicle is able to propel itself without

the help of the winch.

j. Detach the winch cable hook.

k. Rewind the winch cable evenly back onto the winch drum following the

instructions in this manual.

12. Never attempt to winch another stuck vehicle by attaching the winch cable to

a suspension component, brush guard, bumper or cargo rack. Vehicle

damage may result. Instead, attach the winch to a strong portion of the

vehicle frame or hitch.

108

WINCH GUIDE

WINCH CABLE CARE

WARNING

Use of worn or damaged cable could lead to sudden failure and SEVERE

INJURY.

For your safety, always replace POLARIS winch parts (including the cable) with

genuine POLARIS replacement parts available at your authorized POLARIS

dealer, or other qualified person.

1. Always inspect your winch before each use. Inspect for worn or loose parts

including mounting hardware. Never use the winch if any part needs repair or

replacement.

2. Always inspect your winch cable before each use. Inspect for worn or kinked

winch cable.

A kinked winch cable made of wire rope

is shown at right. Even after being

“straightened out,” this cable has

already been permanently and severely

damaged. Promptly discontinue use of

a winch cable in this condition.

A kinked winch cable made of wire rope

that has been “straightened out” is

shown at right. Even though it may look

usable, the cable has been permanently

and severely damaged. It can no longer

transmit the load that it could prior to

kinking. Promptly discontinue use of a

winch cable in this condition.

A winch cable made of synthetic rope

should be inspected for signs of fraying.

Replace the cable if fraying is observed

(shown below). Promptly discontinue

use of a winch cable in this condition.

Also replace the winch cable if there are

fused or melted fibers. Such an area of

the synthetic rope will be stiff and

appear smooth or glazed. Promptly

discontinue use of a winch cable in this

condition.

110

WINCH GUIDE

SHOCK LOADING

WARNING

Your winch cable is very strong but it is NOT designed for dynamic, or “shock”

loading. Shock loading may tension a winch cable beyond its strength and

cause the cable to break. The end of a broken winch cable under such high

loading can cause SEVERE INJURY or DEATH to you and other bystanders.

Winch cables are designed to NOT absorb energy. This is true of both wire-rope

and synthetic-rope winch cables.

1. Never attempt to “jerk” a load with the winch. For example, never take up

slack in the winch cable by moving the winching vehicle in an attempt to

move an object. This is a dangerous practice. It generates high winch cable

loads that may exceed the strength of the cable. Even a slowly moving

vehicle can create large shock loads in a winch cable.

WARNING

SEVERE INJURY or DEATH can result from a broken winch cable.

2. Never quickly turn the winch ON and OFF repeatedly (“jogging”). This puts

extra load on the winch, winch cable, and generates excessive heat from the

motor. This is a form of shock loading.

3. Never tow a vehicle or other object with your winch. Towing an object with a

winch produces shock loading of the cable even when towing at slow

speeds. Towing from a winch also positions the towing force high on the

vehicle. This can cause instability of the vehicle and possibly lead to an

accident.

4. Never use recovery straps with your winch. Recovery straps are designed to

stretch and can store energy. This stored energy in the recovery strap is

released if a winch cable fails making the event even more hazardous.

Similarly, never use elastic “bungie” cords for winching.

5. Never use the winch to tie down a vehicle to a trailer or other transportation

vehicle. This type of use also causes shock loading that can cause damage

to the winch, winch cable, or vehicles used.

Your winch cable is designed and tested to withstand the loads produced

by the winch motor when operated from a stationary vehicle. Always

remember that the winch and winch cable are NOT designed for shock

111

WINCH GUIDE

114

MAINTENANCE

ELEVATING THE VEHICLE FOR SERVICE

Some service procedures require that the vehicle be elevated. Before

proceeding, remember to:

• Always position the vehicle on a firm, level surface before elevating.

• Only use an appropriate sized lift or jack.

• Refrain from positioning a jack or jack stand under any components other

than the vehicle frame.

• Refrain from allowing the vehicle to remain elevated on a floor jack for an

extended period of time.

PLACING ONTO JACK STANDS

1. Place the floor jack directly beneath the center of the vehicle (either front or

rear).

2. This vehicle is not equipped with dedicated jacking points. Make sure that

the floor jack only makes contact with the vehicle frame only while lifting.

3. After vehicle is elevated to desired height, place jack stands under the

vehicle frame on both sides of the floor jack, then lower the vehicle until the

jack stands come into contact with the vehicle frame.

115
