Sida 1/10
INSTRUCTIONS FOR USE
Pro-Ject DAC Box DS2 Ultra
© Pro-Ject Audio Systems · Pro-Ject DAC Box DS2 Ultra · Revision 2016.11.9
2
Dear music lover,
thank you for purchasing a Pro-Ject Audio DAC Box DS2 Ultra.
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse
Important notice
Safety instructions
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply. The power cord is
used to disconnect the unit from the mains. Make sure that the power cord is easily accessible at all
times.
Never handle the device, the power cord/power supply while your hands are wet or damp.
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid,
such as a flower vase on or near the device. Never spill any liquid on the device or the power supply.
Never place any naked flame sources, such as lighted candles on or near the device. The product shall not
be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.
Connectors
Make all connections, except the connection to the
except the connection to the
except the connection to the
except the connection to theexcept the connection to the computer
computer
computer
computer computer, whilst the unit is disconnected from the
power supply. Connect the unit to
to
to
to to the mains and switch it on before connecting it to the computer
the mains and switch it on before connecting it to the computer
the mains and switch it on before connecting it to the computer
the mains and switch it on before connecting it to the computerthe mains and switch it on before connecting it to the computer.
Take care to connect the left and right channels correctly. The right channel is usually marked red,
the left channel black or white.
Never use any other power supply than the one supplied with the unit.
Connection to the amplifier
Connect the Output
Output
Output
Output Output RCA socket to a line input (such as AUX
AUX
AUX
AUXAUX) on your amplifier. Pressing the Gain
Gain
Gain
GainGain button on
the back panel raises gain by 6dB.
Digital inputs
Sources with a digital output such as a CD player can be connected to the digital inputs (coaxial and optical). A
computer can be connected to the USB input.
The DAC supports PCM (LPCM) and DSD format only. The DAC does not work with audio formats
like DTS
™
or Dolby
®
Digital. If the DAC is used with a TV satellite/cable receiver or a TV set with an
integrated satellite/cable receiver. Make sure that in the set-up menu of your receiver/TV, the format
of the digital signal, relayed to the digital output used, is set to PCM.
!
!
!
!
© Pro-Ject Audio Systems · Pro-Ject DAC Box DS2 Ultra · Revision 2016.11.9
3
Connecting to a computer
Connect the USB-input of the DAC (unit must be switched on) to a free USB-socket on your computer and
turn it on/make sure it is powered on.
* For Windows
®
operating systems an USB driver (supplied on CD) has to be installed. Mac OS
®
operating
systems do not need an additional driver.
Please note: Connection should be made to an USB-socket of your computer directly. Connecting to
USB-hubs can cause problems.
Mains power connection
Connect the low voltage plug from the power supply to the socket before connecting the
Power 18V DC
Power 18V DC
Power 18V DC
Power 18V DC Power 18V DC
power supply to the mains.
Remote power on - triggers
The unit can be switched on & off via a special connection from other Pro-Ject products equipped with
trigger connections via the 2,5mm socket marked Trigger Input
Trigger Input
Trigger Input
Trigger InputTrigger Input.
A 45cm long power-on cable (polarity ) is supplied for this purpose. Longer cables are available as
accessories. The remote power-on signal can be relayed to further units via the socket.
Trigger OUT
Trigger OUT
Trigger OUT
Trigger OUTTrigger OUT
Front panel controls
Switching on and into standby
The push button on the left hand side on the front panel turns the unit on and into standby. The blue LED above
the button shows that the unit is switched on.
Input selector
Operating ◄ ►/repeatedly selects the inputs in turns. The selected input, the sampling frequency or the
DSD mode of the digital input signal will be indicated by the corresponding LED.
+
