INSTRUCTIONS FOR USE

Pro-Ject DAC Box RS

Dear music lover,

thank you for purchasing a P -Ject Audio DAC Box ro RS.

In order to achieve maximum performance and reliability you should study these instructions for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

Safety instructions

AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the

voltage in your area meets the voltage requirements printed on the power supply. The power cord is

used to disconnect the unit from the mains. Make sure that the power cord is easily accessible at all

times. Never handle the device, the power cord/power supply while your hands are wet or damp.

Avoid letting liquids enter the device or the power supply. Never place any item containing liquid,

such as a flower vase on or near the device. Never spill any liquid on the device or the power supply.

Never place any naked flame sources, such as lighted candles on or near the device. The product shall not

be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.

Tubes produce heat. Proper ventilation has to be guaranteed all the time. The unit must not be stacked.

Connectors

PUSH

Make all connections, ex

exexcept the co

cept the co

cept the cocept the connection to the comput

nnection to the comput

nnection to the computnnection to the computer

erer, whilst the unit is disconnected from the

power supply. Connect the unit to

toto

the mains

the mains the mains and switch it o

and switch it o

and switch it oand switch it on before connect

n before connect

n before connectn before connecting it to

ing it to

ing it toing it to

the computer

the computerthe computer.

Take care to connect the left and right channels correctly. The right channel is usually marked red,

the left channel black or white.

Do not

not

notnot c

c connect

onnect

onnectonnect RCA and XLR outputs simult

simult

simultsimultane

ane

aneaneousl

ousl

ouslously.

y. y.

Wiring XLR sockets: 1 ground, 2 “hot” and 3 “cold”.

Never use any other power supply than the one supplied with the unit.

Connection to the amplifier

Connect the socket to a line input (such as ) on your amplifier.

Analog Out

Analog OutAnalog Out AUX

AUX

AUXAUX

Connecting the Pro-Ject CD Box RS

To be able to use the playback mode, the input

Sonic2

Sonic2Sonic2 In 2 Sonic

In 2 Sonic

In 2 SonicIn 2 Sonic AN

ANAND

DD the input have to be

Clock Out

Clock OutClock Out

connected to the corresponding connectors on the Pro-Ject CD Box RS.

In 2 Sonic

In 2 SonicIn 2 Sonic (I

S) and Clock O

Clock O

Clock OClock Out

utut can be used with Pro-Ject CD Box RS only.

The cable length for So

SoSonic

nic

nic nic and Cl

ClClock

ock

ock ock connection must not be longer than 29,5 inch (75cm).

Digital inputs

Sources with an digital output such as a CD player can be connected to the digital inputs (coaxial, optical and

symmetrical A computer can be connected to the USB input.).

The DAC supports PCM (LPCM) and DSD format only. The DAC does not work with audio formats

like DTS

™

or Dolby

Digital. If the DAC is used with a TV satellite/cable receiver or a TV sets with an

integrated satellite/cable receiver, make sure that in the set-up menu of your receiver/TV set, the

format of the digital signal, relayed to the digital output used is set to PCM.

Connecting to a Computer

Connect the USB-input of the DAC (unit must be switched on) to a free USB-socket on your computer and

turn it on/make sure it is powered on.

* For Windows

operating systems an USB driver (supplied on CD) has to be installed. Mac OS

operating

systems do not need an additional driver.

Please note: Connection should be made to an USB-socket of your computer directly. Connecting to

USB-hubs can cause problems.

Mains power connection

Connect the low voltage plug from the power supply to the Power

Power

Power Power 20

2020V

V V socket before connecting the power

supply to the mains.

Remote control

To switch on from standby or to standby

POWER turns the unit on or back into standby

Mute

MUTE

MUTEMUTE activates and deactivates mute. If mute is engaged, the blue LED above

the ON/OFF switch will flash.

Selecting inputs in turns

CHCH- select the inputs in turn or CH+

CH+

CH+CH+

Direct access to inputs

11 9

99 - access a specific input directly

Blanked out buttons do not carry a function.
