INSTRUCTIONS FOR USE
Pro-Ject DAC Box RS2
© Pro-Ject Audio Systems · Pro-Ject DAC Box RS2 · Revision .02. 2020 05
2
Dear music lover,
thank you for purchasing a P -Ject Audio Systems D/A converter. ro
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse
Important notice
Safety instructions
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply.
The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily
accessible at all times. Never handle the device the power supply while your hands are wet or damp. or
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid, such
as a flower vase on or near the device. Never spill any liquid on the device or the power supply. Never
place any naked flame sources, such as lighted candles on or near the device. The product shall not be used
in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.
Connectors
Make all connections whilst the preamplifier is .
disc
disc
disc
discdisconnected from the pow
onnected from the pow
onnected from the pow
onnected from the powonnected from the power supply
er supply
er supply
er supplyer supply
Take care to connect the left and right channels correctly. The right channel is usually marked red,
the left channel black or white.
Never use any other power supply than the one supplied with the unit except of Pro-Ject Power Boxes
which can replace original power supplies.
Analog o puts ue ut
The unit offers following analogue output sockets:
1 pair of XLR connectors for balanced output
1 pair of RCA connectors for unbalanced output
Inputs
USB
USB
USB
USB USB
is dedicated to connection to a Computer Connect the USB-input of the unit (unit must be switched on) to a .
free USB-socket on your computer and turn it on/make sure it is powered on.
© Pro-Ject Audio Systems · Pro-Ject DAC Box RS2 · Revision .02.2020 05
3
Driver installation (Windows® operating systems only)
Windows 10 operating system supports 24/192 playback (wasapi), installation of a supplied driver
(ASIO) is not necessary. Driver is however required for playing DSD files.
For Windows
®
operating systems a USB driver (supplied on CD) has to be installed. Insert the included CD
into the drive of you PC and follow the instructions.
Complete the installation by restarting the computer.
After installin
After installin
After installin
After installinAfter installing the driver, some s
g the driver, some s
g the driver, some s
g the driver, some sg the driver, some settings
ettings
ettings
ettingsettings have to be chec
have to be chec
have to be chec
have to be chec have to be checked
ked
ked
kedked done.
done.
done.
done. done. /
For example - Windows 7
®
and newer operating system:
→ → → → Control Panel Hardware and Sound Sound Playback:
select /
Speake
Speake
Speake
SpeakeSpeaker
r
r
rr Project DA
Project DA
Project DA
Project DAProject DAC Box RS2 U
C Box RS2 U
C Box RS2 U
C Box RS2 UC Box RS2 USB 2.0 Audio Out
SB 2.0 Audio Out
SB 2.0 Audio Out
SB 2.0 Audio Out SB 2.0 Audio Out
→ → Properties Supported formats:
make sure n
make sure n
make sure n
make sure nmake sure nothing is assigned
othing is assigned
othing is assigned
othing is assignedothing is assigned
→ → Level Sound: setting must be
100
100
100
100100
→ → → Enhancements: disable all
disable all
disable all
disable all disable all enhancements
enhancements
enhancements
enhancements enhancements Advanced Default Format: set to
studio qualit
studio qualit
studio qualit
studio qualitstudio quality 24/192
y 24/192
y 24/192
y 24/192y 24/192
Please note: Connection should be made to an USB-socket of your computer directly. Connecting to
USB-hubs or switches can cause problems.
S/PDIF input
S/PDIF input
S/PDIF input
S/PDIF inputS/PDIF inputs
s
s
ss
:
:
:
: :
DAC Box RS2 offers 4 digital S/PDIF inputs: and are optical inputs, is coaxial input and
Opto1
Opto1
Opto1
Opto1 Opto1 Opto2
Opto2
Opto2
Opto2 Opto2 C
C
C
CCoax
oax
oax
oax oax
AES/EBU
AES/EBU
AES/EBU
AES/EBUAES/EBU is balanced input .
I2S
I2S
I2S
I2S I2S
This input is dedicated for connection with Pro-Ject CD Box RS2 using HDMI cable. This connection also
provides Masterclock for CD player
Mains power connection and methods to switch the unit on and off
Connect the low voltage plug from the power supply to the socket of the preamplifier
Power
Power
Power
Power Power V D
V D
V D
V DV DC
C
C
CC
20
20
20
2020 b
b
b
bbefore
efore
efore
efore efore
connecting the power supply to the mains. The unit can be switched on and off by using 2 different methods
which are equal in priorities.
We recommend to set the volume control to minimum, prior to switch on.
1. Using front pushbutton to switch on to standby or in
The pushbutton on the front panel of the unit alternately turns the power on or returns it to standby mode. The
blue LED on the front panel shows that the unit is powered on. If a trigger signal is present the unit can’t be
switched off by the pushbutton.
2. Remote power on - triggers
The unit can be switched on via other Box Design components when a 12V trigger voltage is present at the
2.5mm socket marked Trigger Input.
Trigger Input.
Trigger Input.
Trigger Input.Trigger Input. Special power- cables (polarity ) in diverse lengths are available on
as accessories. The remote power-on signal can be relayed to further units via the Trigger
Trigger
Trigger
Trigger Trigger Out
Out
Out
OutOutput
put
put
putput socket. When
the 12V trigger signal is switched off, the unit will also switch off.
Trigger cables may only be plugged into the sockets when the is disconnected from the power unit
supply and from the mains. Failure to do so may result in damage of the unit.
