INSTRUCTIONS FOR USE

Pro-Ject MaiA

Pro-Ject MaiA Pre

Dear music lover,

thank you for purchasing a P -Ject Audio Systems´ amplifier. ro

In order to achieve maximum performance and reliability you should study these instructions for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

Safety instructions

AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the

voltage in your area meets the voltage requirements printed on the power supply.

The power supply is used to connect/disconnect the unit from the mains. Make sure that the power

supply is easily accessible at all times. Never handle the device, the power supply while your hands are

wet or damp. Avoid letting liquids enter the device or the power supply. Never place any item

containing liquid, such as a flower vase on or near the device. Never spill any liquid on the device or

the power supply. Never place any naked flame sources, such as lighted candles on or near the device.

The product shall not be used in damp or wet locations, next to a bathtub, sink, swimming pool or any

other similar conditions.

Connectors

M Aai

MaiA Pre

1. Make all connections except the connection the headphone and USB whilst the unit to is

disconnected from the mains.

2.Never connect or disconnect power supply to or from the unit whilst the power supply is connected to

the mains !Never use any other power supply than the one supplied with the unit with the exception of

dedicated Power Boxes which can replace original power supplies.

3. Take care to connect the left and right channels of In1

In1

In1In1, In

InIn2

22 In3

In3

In3In3, correctly. The right channel is usually

marked red, the left channel black or white.

4 Speaker connections for the left speaker are located on the right hand side of rear view

. . M

MMaia

aia

aia aia only:

only:

only: only:

above, connections to right speaker are located near the power socket. Speaker connectors marked red

represent according indicators on speaker terminal

++ .

Line o put ut

A power amplifier or active loudspeakers can be connected to the output sockets marked .

Out

OutOutput

put

putput

Connection to the speakers (Maia only)

The output terminals accept loudspeaker cables terminated with 4mm Banana plugs, spades connectors 

or naked wire.

Phono input

Connect the tonearm signal lead to the In

InIn

1 1 Phono

Phono

PhonoPhono of the amplifier. The earthing wire may be connected to

the screw terminal if you encounter hum problems when using the turntable.

Line inputs

Line level sources such as CD player, radio or TV can be connected to the input sockets marked In

In In In

InIn

2,2, 3

3 3 or

or or

In 4

In 4In 4.

Digital inputs

Sources with a digital output such as TV satellite/cable receiver or a game console can be connected to the

digital inputs. Coaxial to and optical to and

In 5

In 5In 5 I

IIn 6

n 6

n 6n 6 I

IIn 7

n 7

n 7n 7

. .

Connecting to a Computer

Connect the USB-input of the MaiA (unit must be switched on) to a free USB-socket on your

In 8 U

In 8 UIn 8 USB

SBSB

computer and turn it on/make sure it is powered on. Select input .

88USB

USB

USBUSB

* For Windows

operating systems an USB Class 2 driver (supplied on CD) has to be installed. For MaiA with

Windows

version 1.61.2 higher needed. or is

Mac OS

operating systems do not need an additional driver or setup.

Linux operating systems include an USB Audio Class 2 driver from Linux Kernel 2.6.35 and higher.

Please note: Connection should be made to an USB-socket of your computer directly. Connecting to

USB-hubs or switches can cause problems.

24Bit/192kHz playback with Windows® operating systems

* For Windows

operating systems a 24Bit/192kHzUSB driver (supplied on CD) has to be installed. Insert the

included CD into the drive of you PC and follow the instructions.

After installin

After installinAfter installing the driver, s

g the driver, s

g the driver, sg the driver, some sett

ome sett

ome settome settings ha

ings ha

ings haings have to be chec

ve to be chec

ve to be checve to be checked

ked

kedked done.

done.

done. done. /

For example - Windows 7

operating system:

    Control Panel Hardware and Sound Sound Playback:

select /

Speake

SpeakeSpeaker

rr MaiA

MaiA

MaiA MaiA USB 2.0 Audi

USB 2.0 Audi

USB 2.0 AudiUSB 2.0 Audio Out

o Out

o Out o Out

  Properties Supported formats:

make su

make sumake sure nothing is as

re nothing is as

re nothing is asre nothing is assigned

signed

signedsigned

  Level Sound: setting must be

100

100100

   Enhancements: disable a

disable a

disable adisable all enhanc

ll enhanc

ll enhancll enhancements

ements

ements ements Advanced Default Format: set to

studi

studi studio quality 24/192

o quality 24/192

o quality 24/192o quality 24/192

Mains power connection

Connect the low voltage plug from the power supply to the socket before connecting the power supply

PPower

ower

ower ower

to the mains.

Produktspecifikationer

Varumärke:	Pro-Ject
Kategori:	mottagare
Modell:	MaiA
Vikt:	1850 g
Bredd:	206 mm
Djup:	200 mm
Höjd:	36 mm
Hörlursutgångar:	1
Fjärrkontroll ingår:	Ja
Toppeffekt per kanal:	30 W
Produktens färg:	Svart
Hörlursanslutning:	6,3 mm
AC-inspänning:	100-240 V
Frekvensområde:	20 - 20000 hz
Anslutningsteknologi:	Kabel
Högtalare anslutning typ:	Banankontakt
Växelström Frekvens:	50 - 60 hz
Strömförbrukning i vänteläge:	1 W
Ändamål:	Hem
Signal/brusförhållande (SNR):	-90 dB
