INSTRUCTIONS FOR USE
Pro-Ject Phono Box S2
© Pro-Ject Audio Systems · Pro-Ject Phono Box S2 · Revision 7.8.18 201
2
Dear music lover,
thank you for purchasing a P -Ject Audio Systems phono amplifier. ro
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse.
Important notice.
Safety instructions
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply.
The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily
accessible at all times. Never handle the device, the power supply while your hands are wet or damp.
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid, such
as a flower vase on or near the device. Never spill any liquid on the device or the power supply. Never
place any naked flame sources, such as lighted candles on or near the device. The product shall not be used
in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.
Settings
Use the dip switches at the bottom of the unit to set input gain, input capacitance and input impedance.
Please set both channels equally.
To find out which type your cartridge is please consult the literature accompanying your cartridge.
The literature for cartridges should also specify the correct input impedance (low-output MC cartridges) and
the correct input capacitance (high-output MC and MM cartridges), into which the cartridge is designed to
work. If in doubt please consult your dealer.
To alter settings the unit must be disconnected from the power supply and the amplifier.
Examples of typical settings
Ortofon 2
Ortofon 2
Ortofon 2
Ortofon 2Ortofon 2M Red
M Red
M Red
M RedM Red M (M )
input gain 40dB, input capacitance 200pF, input impedance 47kohms
Ortofon X5
Ortofon X5
Ortofon X5
Ortofon X5Ortofon X5-
-
-
--MC
MC
MC
MCMC (High-Output MC )
input gain 43dB, input capacitance 420pF, input impedance 47kohms
Ortofon R
Ortofon R
Ortofon R
Ortofon ROrtofon Rondo Red
ondo Red
ondo Red
ondo Redondo Red (Low-Output MC )
input gain 60dB, input capacitance *, input impedance 10ohms.
* Input capacitance is irrelevant for low-output MC cartridges
© Pro-Ject Audio Systems · Pro-Ject Phono Box S2 · Revision .8.18 2017
3
Input impedance / input capacitance high-output MC and MM cartridges –
Input impedance low-output MC cartridges –
* Input capacitance is irrelevant for low-output MC cartridges
Input gain
Subsonic filter
A switch at the back of the phono amplifier activates and deactivates the subsonic filter.
