INSTRUCTIONS FOR USE

Pro-Ject Stereo Box S

Dear music lover,

thank you for purchasing a PRO-JECT AUDIO amplifier.

In order to achieve maximum performance and reliability you should study these instructions for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

Connectors

Record Out

Right

Left

Right

Left

Pro-Ject Audio Systems, Vienna, Austria

Make all connections whilst the amplifier is disconnected from the power supply.

Take care to connect the left and right channels correctly. The right channel is usually marked red,

the left channel black or white.

The red speaker terminals carry the positive sign terminals the negative al (+), the black speaker

signal (–). Make sure the polarity of the connection is correct at each end of the cables.

Only connect one loudspeaker with an impedance not less than 4 ohms per channel.

Never use any other power supply than the one supplied with the unit.

Inputs

Line level sources such as CD player radio or TV can be connected to the input sockets marked .

IN1

IN1IN1 or IN2

IN2

IN2IN2

Connection to the speakers

The output terminals accept loudspeaker cables terminated with 4mm  Banana plugs, spades connectors

or naked wire.

Record output, connecting a headphone amplifier

Record Out

Record OutRecord Out connects an analogue record device ore a Pro-Ject Head Box headphone amplifier.

Record Out

Record Out Record Out provides a fixed output level.

Mains power connection

The unit is supplied with a power supply suitable for your country's mains supply. Check the label before

connecting to ensure compliance with the mains rating in your house. Connect the low voltage plug from the

power supply to the Power 2

Power 2

Power 2Power 20V

0V 0V

socket before connecting the power supply to the mains.

Remote control

ON/OFF

turns the unit on or back into standby

VOL

and

VOL

adjust the sound volume

CH+

CH-

VOL+

VOL-

ON/OFF

and

select the inputs

Front panel controls

Stereo Box S

To switch on from standby or to standby

The push button (press and hold to switch into standby mode) on the left hand side of the front panel turns the

unit on or back into standby. The blue LED above the stand-by push button shows that the unit is switched on.

Input selector

After the unit is powered on, pressing the push button on the right, selects the In 1

In 1

In 1In 1 and In 2

In 2

In 2In 2 inputs in turn.

The optional input expander Pro-Ject Switch Box S provides three more inputs. For further details please see the

user guide of the Pro-Ject Switch Box S.

Volume

Adjust the volume to the desired level, using the large knob on the front panel.

Produktspecifikationer

Varumärke:	Pro-Ject
Kategori:	mottagare
Modell:	Stereo Box S
Vikt:	720 g
Bredd:	103 mm
Djup:	122 mm
Höjd:	36 mm
Hörlursutgångar:	1
Ljudutgångskanaler:	- kanaler
Total harmonisk distorsion (THD):	0.05 %
Toppeffekt per kanal:	30 W
Produktens färg:	Silver
Hörlursanslutning:	3,5 mm
AC-inspänning:	100-240 V
Frekvensområde:	5 - 20000 hz
Anslutningsteknologi:	Kabel
Högtalare anslutning typ:	RCA
Växelström Frekvens:	50 - 60 hz
Signal/brusförhållande (SNR):	100 dB
Synkroniserad ingångsimpedans:	20000 Ω
