INSTRUCTIONS FOR USE
Pro-Ject Phono Box DS2 USB
© Pro Systems-Ject Audio - · Pro Ject Phono Box DS2 USB · Revision 2017. . 03 31
2
Dear music lover,
thank you for purchasing this P -Jro ect A udio phono amplifier.
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse
Important notice
Safety instructions
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply.
The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily
accessible at all times.
Never handle the device, the power supply while your hands are wet or damp.
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid,
such as a flower vase on or near the device. Never spill any liquid on the device or the power supply.
Never place any naked flame sources, such as lighted candles on or near the device. The product shall not
be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.
Connectors
Make all connections whilst the phono amplifier is disconnected from the power supply.
Take care to connect the left and right channels correctly. The right channel is usually marked red, the
left channel black or white.
Do not connect the phono amplifiers output to a phono input (sometimes labelled
gram
gram
gram
gramgram
,
dis
dis
dis
disdisc
c
c
cc
or
RIAA
RIAA
RIAA
RIAARIAA
)
on the amplifier.
Never use any other power supply than the one supplied with the unit.
Connecting of record players
Connect left and right channels of the tonearm signal lead to the sockets marked
phono 1
phono 1
phono 1
phono 1phono 1
or
Phono 2
Phono 2
Phono 2
Phono 2Phono 2
of the
phono amplifier. It is possible to connect 2 record players at once or connect 2 tonearms from a turntable
equipped by 2 tonearms. The earthing wire(s) may be connected to the screw terminal if you encounter hum
problems when using the record player.
Line level input
Any line level source of signal can be connected to the preamplifier using
Line 3
Line 3
Line 3
Line 3Line 3
socket on the backpanel
and then converted to digital data using coaxial S/PDIF output or USB output.
!
!
!
© Pro Systems-Ject Audio -· Pro Ject Phono Box DS2 USB · Revision 2017. . 03 31
3
Connection to the amplifier
Connect the
Out
Out
Out
OutOutput
put
put
putput
of the phono amplifier to a line input (such as
AUX
AUX
AUX
AUXAUX
,
CD
CD
CD
CDCD
,
Tune
Tune
Tune
TuneTuner
r
r
rr
,
Tape
Tape
Tape
TapeTape
or
Video
Video
Video
VideoVideo
) on your
amplifier.
Alternatively connect the S/PDIF digital output to the corresponding digital input of the amplifier or
soundbar.
Mains power connection and methods to switch the unit on and off
Connect the low voltage plug from the power supply to the
Power 18V
Power 18V
Power 18V
Power 18VPower 18V
socket of the preamplifier
be
be
be
bebefore
fore
fore
fore fore
connecting the power supply to the mains. The unit can be switched on and off by using 2 different methods
which are equal in priorities.
1. Using front pushbutton to switch on or into standby
The pushbutton on the front panel of the unit alternately turns the power on or returns it to standby mode. The
blue LED on the front panel shows that the unit is powered on. If a trigger signal is present the unit can’t be
switched off by the pushbutton.
2. Remote power on - triggers
The unit can be switched on via other Box Design components when a 12V trigger voltage is present at the
2.5mm socket marked
Trigge
Trigge
Trigge
TriggeTrigger Inpu
r Inpu
r Inpu
r Inpur Input.
t.
t.
t.t.
- Special power on cables (polarity ) in diverse lengths are
available as accessories. The remote power-on signal can be relayed to further units via the
Trigger Output
Trigger Output
Trigger Output
Trigger OutputTrigger Output
socket. When the 12V trigger signal is switched off, the unit will also switch off.
Front panel
Settings
The three function keys
Loading
Loading
Loading
Loading Loading Ω
Ω
Ω
ΩΩ
,
Loading pF
Loading pF
Loading pF
Loading pFLoading pF
,
Gain dB
Gain dB
Gain dB
Gain dBGain dB
on the right hand side are used to set input impedance,
input capacitance and input gain. All settings are stored automatically.
To find out which type your cartridge is, please consult the literature accompanying your cartridge.
The literature for cartridges should also specify the correct input impedance (low-
output MC
cartridges) and the correct input capacitance (high output MC and MM cartr-
idges), into which the
cartridge is designed to work. If in doubt please consult your dealer.
Trigger cables may only be plugged into the sockets when the unit is disconnected from the power
supply and from the mains. Failure to do so may result in damage of the unit.
