INSTRUCTIONS FOR USE

Pro-Ject Pre Box SE

Dear music lover,

thank you for purchasing a PRO-JECT AUDIO preamplifier.

In order to achieve maximum performance and reliability you should study these instructions for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

Connectors

Pre Out

Sub

Out

Trigger

Make all connections whilst the preamplifier is disconnected from the power supply.

Take care to connect the left and right channels correctly. The right channel is usually marked red,

the left channel black or white.

Inputs

Line level sources such as CD player radio or TV can be connected to the input sockets marked . 1 - 4

Pre Out

A power amplifier or active loudspeakers can . be connected to the output sockets marked Pre Out

Subwoofer output

An active subwoofer can be connect . ed to the output sockets marked Sub

Record output, processor loop

Out connects an analogue record device. Together with on of the inputs, it can be used as processor loop,

to operate devices like a room compensation processor.

Remote power-on, switching voltage

The socket marked Trigger provides a 12V DC switched output voltage for remote power-on of units with this

facility (such as the Pro-Ject Amp Box SE or Pro-Ject Amp Box SE Mono), which corresponds to the position

(on/off) of the power switch (A) on the front panel.

A 45cm remote power-on cable (polarity

) is supplied with the Pro-Ject amplifiers for connecting the

remote-switched power socket to the Pro-Ject Pre Box SE. Longer cables are available from your Pro-Ject dealer.

Do not use this trigger output for any other connections for which it is not designed.

Mains power connection

The unit is supplied with a power supply suitable for your country's mains supply. Check the label before

connecting to ensure compliance with the mains rating in your house. Connect the low voltage plug from the

power supply to the Power ~16V socket before connecting the power supply to the mains.

Remote control

ON/OFF

short press turns the unit on, long press takes it back into standby.

Powered on, a short press activates and deactivates mute

VOL

and

VOL

adjust the sound volume

CH+

CH-

VOL+

VOL-

ON/OFF

and

select the inputs

Front panel controls

Pre Box SE

Stand-By

A on the front turns the unit on or back into standby. The display shows STANDBY when the unit is in standby.

While switching off, the unit saves the settings for input, volume and mute, to be set automatically after next

power on.

Dimming the display

Press and hold the buttons C and D will change the display brightness - full, half and one third.

Input selector

Pressing the Input Select buttons A and B selects the inputs 1 - 4 in turns. The selected input will be shown in

the display.

The optional input expander Pro-Ject Switch Box provides three more inputs. For further details please see the

user guide of the Pro-Ject Switch Box.

Volume

Adjust the volume (95 steps) to the desired level using the buttons C and D. The volume level will be shown in

the display. -95dB indicates min., 00dB max..

Mute

While the unit is powered on,

ON/OFF

activates and deactivates mute .
