© PureLink GmbH 2013

Innovation German Enterprises.

Know-How. Quality. Design.

PureLink GmbH | Von-Liebig-Straße 10 | 48432 Rheine | Germany | Tel.: 0049 (0)5971-800 299-0 | Fax: 0049 (0)5971-800 299-99 | E-mail: [email protected] | Internet: www.purelink.de

Transmitter - front view

Transmitter - rear view

Receiver - front view

Receiver - rear view

Thank you for purchasing the Luxi Electronics® Presenter product. Please read through this manual before using the product.

How the product functions: Think of the daisy chain as the ow of a river; each transmitter (Tx) connects to a source device and loads

the signal to the river ow; each receiver (Rx) unloads the signal from the river ow and sends it to the display it is connected to.

The front panel and the RS-232 controls determine which source signal goes to which display.

Power options:

This product can draw power from other Presenter products in the chain

or from an optional external power supply.

TXTXRXRX

CAT 5, 6, 7

TITEL 01

System diagram

PRESENTER™

Quick Start Guide

HDMI Input

Power

Power

RS232

HDMI Output

Daisy Chain

Input

Daisy Chain

Input

Daisy Chain

Output

Ethernet

Daisy Chain

Output

Ethernet

Show Me

RS-232Status LED

Status LED

SHOW ME

Button
