MX42

4 CHANNEL

STEREO

LINE MIXER

Owners Manual

LIMITED WARRANTY

This product is warranted to the original consumer purchaser to be free

from defects in materials and workmanship under normal installation, use and

service for a period of one (1) year from the date of purchase as shown on the

purchaser’s receipt.

The obligation of Rolls Corporation under this warranty shall be limited

to repair or replacement (at our option), during the warranty period of any part

which proves defective in material or workmanship under normal installation,

use and service, provided the product is returned to Rolls Corporation, TRANS-

PORTATION CHARGES PREPAID. Products returned to us or to an authorized

Service Center must be accompanied by a copy of the purchase receipt. In the

absence of such purchase receipt, the warranty period shall be one (1) year from

the date of manufacture.

This warranty shall be invalid if the product is damaged as a result of

defacement, misuse, abuse, neglect, accident, destruction or alteration of the

serial number, improper electrical voltages or currents, repair, alteration or

maintenance by any person or party other than our own service facility or an

authorized Service Center, or any use violative of instructions furnished by us.

This one-year warranty is in lieu of all expressed warranties, obligations

or liabilities. ANY IMPLIED WARRANTIES, OBLIGATIONS, OR LIABILI-

TIES, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES

OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,

SHALL BE LIMITED IN DURATION TO THE ONE YEAR DURATION OF

THIS WRITTEN LIMITED WARRANTY. Some states do not allow limitations

on how long an implied warranty lasts, so the above limitation may not apply to

you.

Salt Lake City, Utah

MX42 Mixer

• 4 Stereo RCA Inputs

• 1 Stereo RCA Output

•

100K Ohm Potentiometers

The MX42 is a stereo four channel

passive mixer for expanding a

console mixer, mixing instruments,

cd players, cassette players,

computers etc. It requires no

batteries or other power source.

The unit may also be used as a 1

In 4 Out stereo splitter box when

all controls are

turned clockwise.

IN NO EVENT SHALL

WE BE LIABLE FOR ANY

SPECIAL, INCIDENTAL OR

CONSEQUENTIAL DAMAGES

FOR BREACH OF THIS OR ANY

OTHER WARRANTY, EX-

PRESSED OR IMPLIED, WHAT-

SOEVER. Some states do not allow

the exclusion or limitation of

special, incidental or consequential

damages so the above limitation or

exclusion may not apply to you.

This warranty gives you specific

legal rights, and you may also have

other rights which vary from state

to state.

OUTPUT

INPUTS

1 2 3 4

1234

MADE IN THE USA

STEREO MINI MIXER

MX42

LEVELS

INTRODUCTION

Congratulations and thank you for your purchase of the

MX42. This unit is a stereo, four channel passive mixer for

expanding a console mixer, mixing instruments, cd or cas-

sette players, or other signal sources. It requires no batteries

or other power source. The unit may be used as a stereo 1-in

4-out box when all controls are turned completely clockwise.

DESCRIPTION

OUTPUT: Stereo RCA jack for connection to a mixer input or

other input device.

IN 1 - 4: Stereo RCA jacks for connection to line, instrument,

or consumer level devices.

VOLUME 1 - 4: Control the level of the signals coming from

Inputs 1 - 4.

SPECIFICATIONS

Input Impedance: 10K to 47K Ω

Output Impedance: 2.5K to 10K Ω

Gain: -12 dB MAX

Dimensions: 3" x 2" x 1.42" (W x H x D)

Weight: 1 lb.

OUTPUT

INPUTS

1 2 3 4

1234

MADE IN THE USA

STEREO MINI MIXER

MX42

LEVELS

SCHEMATIC
