RDV-985 DVD Player
Owner’s Manual
RDV-985
DVD Player
DVD
ch Disc
REMAIN
REPEAT
TITLE CHAP.
SUB
S
CL
LS
R
RS
WARNING: There are no user serviceable parts in-
side. Refer all servicing to qualified service person-
nel.
WARNING: To reduce the risk of fire or electric shock,
do not expose the unit to moisture or water. Do not
allow foreign objects to get into the enclosure. If the
unit is exposed to moisture, or a foreign object gets
into the enclosure, immediately disconnect the power
cord from the wall. Take the unit to a qualified ser-
vice person for inspection and necessary repairs.
Read all the instructions before connecting or operating the
component. Keep this manual so you can refer to these safety
instructions.
Heed all warnings and safety information in these instruc-
tions and on the product itself. Follow all operating instruc-
tions.
Clean the enclosure only with a dry cloth or a vacuum cleaner.
You must allow adequate unobstructed clearance around the
unit. Do not place the unit on a bed, sofa, rug, or similar sur-
face that could block the ventilation slots. If the component
is placed in a bookcase or cabinet, there must be ventilation
of the cabinet to allow proper cooling.
Keep the component away from radiators, heat registers, stoves,
or any other appliance that produces heat.
The unit must be connected to a power supply only of the type
and voltage specified on the rear panel of the unit.
Connect the component to the power outlet only with the sup-
plied power supply cable or an exact equivalent. Do not modify
the supplied cable in any way. Do not attempt to defeat ground-
ing and/or polarization provisions. Do not use extension cords.
Do not route the power cord where it will be crushed, pinched,
bent at severe angles, exposed to heat, or damaged in any
way. Pay particular attention to the power cord at the plug
and where it exits the back of the unit.
The power cord should be unplugged from the wall outlet if
the unit is to be left unused for a long period of time.
Immediately stop using the component and have it inspected
and/or serviced by a qualified service agency if:
• The power supply cord or plug has been damaged.
• Objects have fallen or liquid has been spilled into the unit.
• The unit has been exposed to rain.
• The unit shows signs of improper operation
• The unit has been dropped or damaged in any way
Place the unit on a fixed, level surface strong enough to sup-
port its weight. Do not place it on a moveable cart that could
tip over.
For U.S.A.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential in-
stallation.
This equipment gene rates, uses and can radiate radio fre-
quency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to ra-
dio communications. However, there is no guarantee that in-
terference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or tele-
vision reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to cor-
rect the interference by one or more of the following mea-
sures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. DANGER: Visible laser radiation when open and inter-
lock failed or bypassed. Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user
serviceable parts inside the player; leave all servicing to
qualified service personnel.
REPRODUCTION OF LABELS
1. Classification label, placed on rear enclo-
sure.
2. Warning label, placed inside unit.
WARNING!
To reduce the risk of electrical shock, fires, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose the unit to rain or moisture.
3. Do not touch the power cord or plug with wet hands.
Caution – POWER Button Operation
The POWER buttons on the front panel and the remote con-
trol switches the unit between “On” and “Standby” modes.
They do not disconnect the power mains. The power cord must
be unplugged from the wall to shut power off completely.
Caution: Proper Ventilation
To avoid the risk of electric shock and fire and to protect from
damage, observe the following minimum clearance require-
ments:
Front No obstructions, open access
Sides 1
1
/
4
” / 30mm minimum clearance
Top 2” / 50mm minimum clearance
Back 6” / 150mm minimum clearance
Bottom No obstructions, place on a level surface
RDV-985 Outside Cover 11/11/99, 3:15 AM1
The Rotel Co. Ltd.
10-10 Shinsen-Cho
Shibuya-Ku
Tokyo 150-0045
Japan
Phone: +81 3-5458-5325
Fax: +81 3-5458-5310
Rotel of America
54 Concord Street
North Reading, MA 01864-2699
USA
Phone: +1 978-664-3820
Fax: +1 978-664-4109
Rotel Europe
Meadow Road
Worthing, West Sussex BN11 2RX
England
Phone: +44 (0)1903 524 813
Fax: +44 (0)1903 524 831
Rotel Deutschland
Kleine Heide 12
D-33790 Halle/Westf.
Germany
Phone: +49 05201-87170
Fax: +49 05201-73370
082 OMRDV-985 111199
2
RDV-985 DVD Player
Owner’s Manual
RDV-985
DVD Player
DVD
ch Disc
REMAIN
REPEAT
TITLE CHAP.
SUB
S
CL
LS
R
RS
WARNING: There are no user serviceable parts in-
side. Refer all servicing to qualified service person-
nel.
WARNING: To reduce the risk of fire or electric shock,
do not expose the unit to moisture or water. Do not
allow foreign objects to get into the enclosure. If the
unit is exposed to moisture, or a foreign object gets
into the enclosure, immediately disconnect the power
cord from the wall. Take the unit to a qualified ser-
vice person for inspection and necessary repairs.
Read all the instructions before connecting or operating the
component. Keep this manual so you can refer to these safety
instructions.
Heed all warnings and safety information in these instruc-
tions and on the product itself. Follow all operating instruc-
tions.
Clean the enclosure only with a dry cloth or a vacuum cleaner.
You must allow adequate unobstructed clearance around the
unit. Do not place the unit on a bed, sofa, rug, or similar sur-
face that could block the ventilation slots. If the component
is placed in a bookcase or cabinet, there must be ventilation
of the cabinet to allow proper cooling.
Keep the component away from radiators, heat registers, stoves,
or any other appliance that produces heat.
The unit must be connected to a power supply only of the type
and voltage specified on the rear panel of the unit.
Connect the component to the power outlet only with the sup-
plied power supply cable or an exact equivalent. Do not modify
the supplied cable in any way. Do not attempt to defeat ground-
ing and/or polarization provisions. Do not use extension cords.
Do not route the power cord where it will be crushed, pinched,
bent at severe angles, exposed to heat, or damaged in any
way. Pay particular attention to the power cord at the plug
and where it exits the back of the unit.
The power cord should be unplugged from the wall outlet if
the unit is to be left unused for a long period of time.
Immediately stop using the component and have it inspected
and/or serviced by a qualified service agency if:
• The power supply cord or plug has been damaged.
• Objects have fallen or liquid has been spilled into the unit.
• The unit has been exposed to rain.
• The unit shows signs of improper operation
• The unit has been dropped or damaged in any way
Place the unit on a fixed, level surface strong enough to sup-
port its weight. Do not place it on a moveable cart that could
tip over.
For U.S.A.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential in-
stallation.
This equipment gene rates, uses and can radiate radio fre-
quency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to ra-
dio communications. However, there is no guarantee that in-
terference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or tele-
vision reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to cor-
rect the interference by one or more of the following mea-
sures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
IMPORTANT FOR LASER PRODUCTS
1. CLASS 1 LASER PRODUCT
2. DANGER: Visible laser radiation when open and inter-
lock failed or bypassed. Avoid direct exposure to beam.
3. CAUTION: Do not open the top cover. There are no user
serviceable parts inside the player; leave all servicing to
qualified service personnel.
REPRODUCTION OF LABELS
1. Classification label, placed on rear enclo-
sure.
2. Warning label, placed inside unit.
WARNING!
To reduce the risk of electrical shock, fires, etc.:
1. Do not remove screws, covers or cabinet.
2. Do not expose the unit to rain or moisture.
3. Do not touch the power cord or plug with wet hands.
Caution – POWER Button Operation
The POWER buttons on the front panel and the remote con-
trol switches the unit between “On” and “Standby” modes.
They do not disconnect the power mains. The power cord must
be unplugged from the wall to shut power off completely.
Caution: Proper Ventilation
To avoid the risk of electric shock and fire and to protect from
damage, observe the following minimum clearance require-
ments:
Front No obstructions, open access
Sides 1
1
/
4
” / 30mm minimum clearance
Top 2” / 50mm minimum clearance
Back 6” / 150mm minimum clearance
Bottom No obstructions, place on a level surface
RDV-985 Outside Cover 11/11/99, 3:15 AM1
53
3 4
RDV-985 DVD PlayerRDV-985 DVD Player
29
Figure 1: RR-DV91 Remote Control
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
RETURN button
OPEN/CLOSE button
button
(STOP) button
button
TITLE button
/ / / (Cursor) buttons
THEATER POSITION button
3D PHONIC (VSS) button
SUBTITLE button
CANCEL button
RESUME button
Numeric buttons
TV/VIDEO button
SHIFT button
1 6
17
18
3
19
5
20
21
22
23
24
25
26
27
Infrared output window
TV ON/OFF button
DVD ON/OFF button
button
(PAUSE) button
button
(PLAY) buttons
MENU button
ENTER button
ON SCREEN button
STROBE button
ANGLE button
DIGEST buttons
ZOOM button
28
29
TV VOLUME buttons
TV CHANNEL button
1
RETURN button
Returns to the previous menu.
2
OPEN/CLOSE button
Opens and closes the disc tray.
3
/ buttons
Perform rapid advance/reverse playback
operations. Also used for slow-motion play-
back of a picture (for DVD/Video CD/SVCD).
4
■ (STOP) button
Stops playback. Also used to erase all the pro-
grammed tracks for the program play (for
Audio CD/Video CD/SVCD).
5
buttons
Perform skipping a chapter, title or track. Also
used for the page selection of a menu screen
(for DVD/Video CD/SVCD).
6
TITLE button
Displays a title menu of DVD on the TV screen
or monitor.
7
p/q/u/t (Cursor) buttons
Used to select an item from a menu or on-
screen display, or to change the setting of an
item in the on-screen display, etc.
8
THEATER POSITION button
Selects a picture character from 4 settings.
9
VSS button
Produces a simulated surround effect.
10
SUBTITLE button
Turns subtitles on or off.
11
CANCEL button
Cancels the previous settings.
12
RESUME button
Stores the location to resume playback from
later.
13
Numeric buttons
Mainly used to select a title/track number, or
a TV channel. Also used to enter a time for
the Time search and a chapter number for the
Chapter search.
14
TV/VIDEO button
Switches the TV input mode.
15
SHIFT button
When pressing and holding this button, the
numeric keys (0 -9) select the TV channels.
Also used to display the PARENTAL LOCK
display.
16
Infrared signal-emitting window
Point this window toward the remote sensor
on the front panel when pressing buttons.
17
TV ON/OFF button
Turns the TV on or off.
18
DVD ON/OFF button
Turns the unit on or off (standby).
19
II
(PAUSE) button
Pauses playback.
20
u
(PLAY) button
Starts playback. Also used as a SELECT but-
ton for PBC of Video CDs/SVCDs.
21
MENU button (for DVD)
Displays a DVD menu on the TV screen or
monitor.
22
ENTER button
Executes the selected item in a menu or on-
screen display when pressing the button.
23
ON SCREEN button
Displays an on-screen display of the unit on
the TV screen or monitor.
24
STROBE button
Displays nine continuous still pictures.
25
ANGLE button (for DVD)
Changes camera angles during playback of
a DVD containing multiple camera angles.
26
DIGEST button (for DVD/Video
CD/SVCD)
Displays beginning scenes of each title, chap-
ter, or track on the TV screen.
27
ZOOM button (for DVD/Video
CD/SVCD)
Zoom-in for a close-up view of the scene.
28
TV VOL buttons
Adjust the TV volume.
29
TV CH buttons
Change the TV channels.
Figure 2: Front Panel Controls
B
C
A
D
I
FGH E
Figure 3: Display Window Indicators and Functions
DVD
ch Disc
REMAIN
REPEAT
TITLE CHAP.
SUB
S
CL
LS
R
RS
1 2 3 4 5
78
6 10 11
9
Disc Indicator
Lights when a disc is in the unit. When a DVD
disc is in the unit “DVD” also appears .
Multi-Information Display
Displays time and status information.
Time Selection Indicator
Shows which time display mode is selected.
Function Indicator
POWER button
Turns the unit on or off (standby).
STANDBY indicator
Lights when the power cord is connected and
the unit is on standby. When the unit is turned
on, the STANDBY indicator goes off.
VSS button
Produces a simulated surround effect.
Remote sensor
Receives the signal from the remote control
unit.
Disc tray
Used to load discs.
(OPEN/CLOSE) button
Opens and closes the disc tray.
u (PLAY) button
Starts playback. Also, used as a SELECT button
for PBC of Video CDs.
■ (STOP) button
Stops playback.
II (PAUSE) button
Pauses playback.
(SKIP) buttons
Performs skipping a chapter, title or track. Also
used for the page selection of a menu screen
(for DVD).
SHUTTLE knob
Performs rapid advance/reverse playback
operations. Also used for slow-motion play-
back of a picture (for DVD/Video CD).
Lights when one of the programmable play
functions is selected
Resume Indicator
Lights when a location on the disk has been
stored. Play can be resumed at the stored lo-
cation
Chapter, Title, Track Indicator
Displays chapter, title, or track number.
Speaker Indicator
lights during disc playback when sig-
nals are output from the video output jacks.
lights when the VSS function is turned
on.
Linear PCM Indicator
Lights only when the playback disc contains
linear PCM data. This indicator also lights when
an Audio CD is placed in the unit.
Channel Indicator
Displays the currently selected audio playback
format.
Specifications
General
Readable Discs: DVD VIDEO, Audio CD, Video CD,
Super Video CD
Video Format: PAL or NTSC selectable
Video 0utput
VIDEO OUT (pin jack): 1.0 Vp-p (75 ohms)
S-VIDEO OUT (S jack):
Y Output:1.0 Vp-p (75 ohms)
C Output:286 mVp-p (75 ohms)
Horizontal Resolution: 500 Lines
Signal to Noise Ratio: 65 dB
Audio Output
ANALOG OUT (pin jack): 2.0 Vrms (10 k ohms)
DIGITAL OUT (optical): – 21 to –15 dBm (peak)
Audio Characteristics
Frequency Response:
CD: (sampling frequency 44.1
kHz): 2 Hz to 20 kHz
DVD (sampling frequency 48
kHz): 2 Hz to 22 kHz
DVD (sampling frequency 96
kHz): 2 Hz to 44 kHz
Dynamic Range:
16 bit: More than 100 dB
20 bit: More than 108 dB
24 bit: More than 108 dB
Wow and Flutter: Unmeasurable (less than ± 0.002%)
Total Harmonic Distortion: Less than 0.002%
Physical
Power Requirements:
USA Version: AC 120V, 60
Hz
European Version: AC 230V, 50
Hz
Power Consumption: 21 W (POWER ON), 2 W (STANDBY
mode)
Weight: 4.7 kg (10.4 lbs)
Dimensions (W x H x D): 435 x 112 x 338 mm
17
3/16
x 4
7/16
x 13
5/16
inch
* Specifications and appearance subject to change without prior notice.
Produktspecifikationer
| Varumärke: | Rotel |
| Kategori: | DVD-spelare |
| Modell: | rdv 985 |
Behöver du hjälp?
Om du behöver hjälp med Rotel rdv 985 ställ en fråga nedan och andra användare kommer att svara dig
DVD-spelare Rotel Manualer
30 September 2025
21 Augusti 2024
21 Augusti 2024
14 Augusti 2024
13 Augusti 2024
11 Augusti 2024
10 Augusti 2024
10 Augusti 2024
8 Augusti 2024
DVD-spelare Manualer
Nyaste DVD-spelare Manualer
6 Oktober 2025
1 Oktober 2025
26 September 2025
24 September 2025
24 September 2025
24 September 2025
24 September 2025
24 September 2025
24 September 2025
24 September 2025
