Flush-mount multifunction display unit
ATE 310
KEY POINTS
Front face
Brushed stainless steel 316 L
Back housing
Flush-mount in stainless steel 304 L
Protection
IP65 in front face
Weight
585 g
●
Alternating display of 1 to 3 parameters
●
3 audible and visual alarms
●
Configuration keyboard and acknoledgment of the alarm on the front face
●
3 analogue inputs 0-5/10 V or 0/4-20 mA
●
Ethernet communication (option)
●
RS485 MODBUS protocol communication
●
30 pre-programmed units and configurable units
●
Front face made of brushed stainless steel with electroluminescent display
FEATURES OF THE HOUSING
DISPLAY FEATURES
DisplayElectroluminescent alphanumeric (38 x 48 mm). Protection glass in red inactinic PMMA .
First line (measurement)4 digits of 8 segments each. Size: 14 x 48 mm.
Second line (unit)4 digits of 14 segments each. Size: 14 x 48 mm.
Comma positionConfigurable: 0 / 0.0 / 0.00
Value of the measurementFrom -9.99 to 99.99 and from -999 to 999
Accuracy*±0.1% of reading ±1 digit
Number of channelsFrom 1 to 3 ways alternating
Location of channelsBy red Led V1, V2 and V3
Available units30 pre-programmed units (see table) and configurable units
Response time< 1 second
*All accuracies indicated in this document were stated in laboratory conditions and can be guaranteed for measurements carried out in the same conditions, or carried out with calibration compensation.
234 mm
92 mm
44 mm
42.5 mm
70 mm
196 mm
3.2 mm
218 mm
76 mm
69 mm
147.3 mm
