Sida 1/146
Home Appliances
Fridge-freezers
SJ-BA35CHXIE-EU
User ManualEN
BedienungsanleitungDE
Guide d’utilisationFR
HandleidingNL
Manual de UsoES
Manual de InstruçőesPT
BrugsanvisningDK
BruksanvisningNO
EN -2-
Contents
CHAPTER -1: GENERAL WARNINGS 3 ........................................................................
CHAPTER -2: YOUR FRIDGE FREEZER 8 ....................................................................
CHAPTER -3: USING YOUR FRIDGE FREEZER 8 ........................................................
CHAPTER -4: FOOD STORAGE GUIDANCE 16 ............................................................
CHAPTER -5: DOOR REVERSAL 17 ..............................................................................
CHAPTER -6: TROUBLESHOOTING 17 .........................................................................
CHAPTER -7: TIPS FOR SAVING ENERGY 19 ..............................................................
Your fridge freezer conforms to current safety requirements. Inappropriate use can lead to personal injury and damage
to property. To avoid the risk of damage, read this manual carefully before using your fridge freezer for the rst time.
It contains important safety information on the installation, safety, use and maintenance of your fridge freezer. Retain
this manual for future use.
EN FIRE Warning; Risk of re / ammable materials
EN -3-
CHAPTER -1: GENERAL WARNINGS
WARNING: Keep the ventilation openings of the Fridge
clear from obstruction.
WARNING: Do not use mechanical devices or other
means to accelerate the defrosting process.
WARNING: Do not use other electrical appliances inside
the Fridge.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance, ensure the
supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the appliance.
WARNING: To avoid personal injury or damage this
appliance must be installed in accordance with the
manufacturer instructions.
The small quantity of refrigerant used in this fridge is eco-
friendly R600a (an isobutene) and is ammable and
explosive if ignited in enclosed conditions.
* While carrying and positioning the fridge, do not damage
the cooler gas circuit.
* Do not store any containers with ammable materials, such
as spray cans or re extinguisher rell cartridges in the
vicinity of the fridge.
* This appliance is intended to be used in household and
similar applications such as;
- staff kitchen areas in shops, ofces and other working
environments which can be equated with ordinary
household
- farm houses and by clients in hotels, motels and other
residential type environments which can be equated with
ordinary household
- bed and breakfast type environments which can be
equated with ordinary household
EN -5-
To avoid contamination of food, please respect the
following instructions:
* Opening the door for long periods can cause a signicant
increase of the temperature in the compartments of the
appliance.
* Clean regularly surfaces that can come in contact with food
and accessible drainage systems.
* Store raw meat and sh in suitable containers in the
refrigerator, so that it is not in contact with or drip onto other
food.
* Two-star frozen-food compartments are suitable for storing
pre-frozen food, storing or making ice cream and making
ice cubes.
* One-, two- and three-star compartments are not suitable for
the freezing of fresh food.
* If the refrigerating appliance is left empty for long periods,
switch off, defrost, clean, dry, and leave the door open to
prevent mould developing within the appliance.
CHAPTER -1: GENERAL WARNINGS
EN -6-
CHAPTER -1: GENERAL WARNINGS
Disposal
• All packaging and materials used are environmentally friendly and recyclable. Please dispose of any packaging
in an environmentally friendly manner. Consult your local council for further details.
• When the appliance is ready to be scrapped, cut off the electrical supply cable and destroy the plug and cable.
Disable the door catch in order to prevent children getting trapped inside.
• A cut-off plug inserted into a 16 amp socket is a serious safety (shock) hazard. Please ensure the cut-off plug
is disposed of safely.
Notes:
• Please read the instruction manual carefully before installing and using your appliance. We are not responsible
for damage resulting from misuse.
• Follow all instructions for your appliance, and keep this manual handy in order to resolve any problems that
may occur in the future.
• This appliance is produced to be used in homes and can only be used in domestic environments and for the
specied purposes. It is not suitable for commercial use. Such use will nullify the warranty and our company
will not be responsible for any losses that occur.
• This appliance is produced for home use and it is only suitable for cooling / storing foods. It is not suitable for
commercial or use and / or for storing any substances except for food. Our company is not responsible for any
losses due to improper use.
Safety warnings
• Do not connect your Fridge Freezer to the mains electricity supply using an extension lead.
• A damaged power cord / plug can cause re or give you and electric shock. When damaged it must be
replaced, this should only be done by qualied personnel.
• Never bend the power cord excessively.
• Never touch the power cord / plug with wet hands as this could cause a short circuit electric shock.
• Do not place glass bottles or beverage cans in the freezer department. Bottles or cans may explode.
• When taking ice made in the freezer department, do not touch it, ice may cause ice burns and/or cuts.
• Do not remove items from the freezer if your hands are damp or wet. Tis could cause skin abrasions or frost /
freezer burns.
• Do not refreeze food once it has thawed out.
Disposal of your old appliance
This symbol on the product or package shows that the product should not be treated as domestic waste.
Instead, it should be taken to applicable waste collection sites that recycle electrical and electronic equipment.
Recycling materials will help preserve our natural resources. For more detailed information regarding
recycling this product, please contact your local authority, domestic waste disposal service, or the shop
where you purchased the product.
Please ask your local authority about the disposal of WEEE for reuse, recycle and recovery purposes.
Installation Information
Before unpacking and manoeuvring your fridge freezer please take some time to familiarise yourself with the following
points.
• Position your fridge freezer out of direct sunlight and away from any heat source such as a radiator.
• Your appliance should be at least 50 cm away from stoves, gas ovens and heater cores, and should be at least
5 cm away from electrical ovens.
• Do not expose your fridge freezer to moisture or rain.
• Your fridge freezer should be positioned at least 20mm away from another freezer.
• Clearance of at least 150 mm is required at the top
of your appliance. Do not place anything on top of
your appliance.
• For safe operation, it is important that your fridge
freezer is seated securely and balanced. The
adjustable feet are used to level your fridge freezer.
Make sure that your appliance is level before placing
any foodstuffs inside it.
• We recommend that you wipe all shelving and trays
with a cloth soaked in warm water mixed with a
teaspoon of bicarbonate of soda before use. After
cleaning, rinse with warm water and dry.
If your refrigerator has a fan condenser:
The condenser of your fridge is placed at the bottom of
For Denmark products:
The appliance is equipped with a plug approved in the EU ( EU-Schuko Plug) and can be used in Finland, Norway and
Sweden. In Denmark, the appliance is only approved for use with a wall outlet type E or type CEE7 // 7-S with a ground
leg. If there is only wall outlet type K at the connection point, Replacing EU-Schuko plug with the Danish plug must be
performed by only an authorized service personel. Alternatively, connect a suitable and approved power adapter to
transition between Schuko plug and Danish earth system. This adapter (min. 10 amps and up to max. 13 amps) can
be ordered via at well assorted whitegoods dealer or authorized electrician. Only with one of these methods it can be
ensured that the appliance is the correct safety ground. In the absence of earthing installation, an authorised electrician
should carry out an earthing installation. In the case of use without earthing installed, we will not be responsible for any
loss of use that may occur.
Plastic for distance setting
EN -7-
CHAPTER -1: GENERAL WARNINGS
Before using your fridge freezer
• Before setting up your fridge freezer, check for any visible damage. Do not install or use your fridge
freezer if it is damaged
• When using your fridge freezer for the rst time, keep it in an upright position for at least 3 hours before
plugging into the mains. This will allow efcient operation and prevent damage to the compressor.
• You may notice a light odour when using your fridge freezer for the rst time. This is perfectly normal and
will fade away as the fridge starts to cool.
Information about new-generation cooling technology
Fridge freezers with new-generation cooling technology have a different working system than static
fridge freezers. In normal fridge freezers, humid air entering the freezer and the water vapour
emanating from the foods, turns into frost in the freezer compartment. In order to melt this frost, in
other words defrost, the fridge has to be unplugged. In order to keep foods cold during the defrosting
period, the user must store the food elsewhere and the user must clear the remaining ice and
accumulated frost.
The situation is completely different in freezer compartments equipped with new-generation cooling
technology. With the aid of fan, cold and dry air is blown throughout the freezer compartment. As a
result of the cold air that is blown easily throughout the compartment – even in the spaces between
shelves – foods are frozen equally and properly. And there will be no frost.
The conguration in the refrigerator compartment will be nearly same as the freezer compartment. Air
emitted by the fan located at the top of refrigerator compartment is cooled while passing through the
gap behind the air duct. At the same time, air is blown out through the holes on the air duct so that
cooling process is successfully completed in the refrigerator compartment. Holes on the air duct are
designed for even air distribution throughout the compartment.
Since no air passes between the freezer and refrigerator compartment, odours will not mix.
As a result, your fridge with new-generation cooling technology is easy to use and it offers you an
access to a huge volume and aesthetic appearance.
cabinet. As a result of that, assemble the spacer by xing it to holes on the cover bottom panel and turn 90° that’s
shown below gure for arranging the distance between the refrigera¬tor and the back wall at where you place the
fridge. You can move the fridge towards the back wall until that point.
EN -8-
CHAPTER -2: YOUR FRIDGE FREEZER
This gure has been drawn for information purposes to show the various parts and accessories in the appliance.
Parts may vary according to the model of the appliance.
Fridge compartment
Wine rack *
Fridge shelves
Door shelves
Door shelf / Adjustable door shelf
C *KLOO'UDZHU
Crisper cover
Bottle shelf
Crispers
Ice-matic *
Freezer top basket / ap
Freezer compartment
Freezer - middle basket
Freezer - bottom basket
Levelling feet
Egg holder
Ice tray *
* In some models
This appliance is not intended to be used as a built-in appliance.
General notes:
Fresh Food Compartment (Fridge): Most efcient use of energy is ensured in the conguration with the drawers
in the bottom part of the appliance, and shelves evenly distributed, position of door bins does not affect energy
consumption.
Freezer Compartment (Freezer): Most Efcient use of energy is ensured in the conguration with the drawers and
bins are on stock position.
Display and Control Panel
Using the Control Panel
1. Freezer temperature setting.
2. Super Freeze mode indicator
3. Fridge temperature setting
4. Super Cooling mode indicator
5. Holiday mode indicator
6. Eco mode indicator
7. Alarm indicator
8. Child Lock mode indicator
9. Screen selector
10. Decrease value
11. Increase value
12. Mode Selector
13. Child Lock Selector
1 2 3 4
5 6
7 8
910 1112 13
CHAPTER -3: USING YOUR FRIDGE FREEZER
EN -9-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Operating your Fridge Freezer
Lighting (If available)
When the product is plugged in for the rst time, the interior lights may turn on 1 minute late due to opening tests.
Super Freeze Mode
Purpose
• To freeze a large quantity of food that cannot t on the fast freeze shelf.
• To freeze prepared foods.
• To freeze fresh food quickly to retain freshness.
How to use
• Press icon (#9 on control panel diagram), until the
‘Freezer temperature setting’ is selected (#1).
• Once Freezer temperature setting is selected, the
temperature will ash.
• Press the icon (#10) repeatedly until the ‘Super
Freeze logo appears’ in the top left corner (#2)
• Once the Super Freeze mode has been set, the machine will beep to conrm the mode has been switched on.
• After the beep the original temperature of the freezer will appear on screen.
• Mode can be cancelled by repeating the above instructions from the beginning.
During this mode:
• Temperature of the fridge compartment may be adjusted, this will not impact Super Freeze Mode.
• Economy and holiday mode cannot be selected whilst Super Freeze is active.
Super Cool Mode
Purpose
• To cool and store a large quantity of food in the fridge compartment.
• To quickly cool drinks.
How to use
• Press icon (#9 on control panel diagram), until the
‘Fridge temperature setting’ is selected (#1).
• Once fridge temperature setting is selected, the
temperature will ash.
• Press the icon (#10) repeatedly until the ‘Super Cool
logo appears’ in the top right corner (#4)
• Once the Super Cool mode has been set, the machine will beep to conrm the mode has been switched on.
• After the beep the last temperature of the fridge will appear on screen.
• Mode can be cancelled by repeating the above instructions from the beginning.
During this mode:
• Temperature of the freezer compartment may be adjusted, this will not impact Super Cool Mode.
• Economy and holiday mode cannot be selected whilst Super Cool is active.
EN -10-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Economy Mode
Purpose
Energy savings. During periods of less frequent use (door opening) or absence from home, such as a holiday, Eco
program can provide optimum temperature whilst saving power.
How to Use
• Press icon (#12 on control panel diagram), until the
‘Eco Mode’ icon appears (#6).
• Once the ‘Eco mode’ has been set, the machine will beep
to conrm the mode has been switched on.
• After the beep the both the fridge and freezer temperature
setting (#1 and #3) will display an ‘E’.
• Eco Mode can be cancelled by pressing the Icon (#12).
During this mode:
• The freezer and fridge temperature may be adjusted however the adjustment will not be made until Eco
Mode is cancelled. When economy mode is cancelled, the selected setting values will be activated and the
temperature(s) will be adjusted.
• Super Cool or Super Freeze mode can be selected, however by selecting either modes Eco Mode is cancelled
immediately.
• Holiday mode can only be selected after cancelling the economy mode.
Holiday Mode
Purpose
Holiday mode is to be used if the device is to be left for an extended period. During Holiday mode only the freezer
compartment remains active.
How to Use
• Press icon (#12 on control panel diagram), until the
‘Holiday Mode’ icon appears (#5).
• Once the ‘Holiday mode’ has been set, the machine will
beep to conrm the mode has been switched on.
• After the beep the fridge will display ‘--’ and the freezer will
display the -18 oC set temperature.
• Holiday Mode can be cancelled by pressing the icon
(#12).
During this mode:
• Freezer and fridge temperature may be adjusted however the adjustment will not be made until Holiday Mode is
cancelled. When Holiday mode is cancelled, the selected setting values will be activated and the temperature(s)
will be adjusted.
• Super Cool or Super Freeze mode can be selected, however by selecting either modes Holiday Mode is
cancelled immediately.
• Eco Mode can only be selected after Holiday mode has been cancelled.
EN -11-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Drink Cool Mode
Purpose
This mode is used to cool drinks within an adjustable time frame.
How to Use
• Press icon (#12) and (#9) icons simultaneously
for ve seconds.
• The cooler temperature set indicator will start showing
‘05’. This value will ash on screen
• Users can either press or buttons to adjust the
time period (05, 10, 15, 20, 25 or 30 minutes)
• When you select the time the numbers will blink 3 times
on screen and sound beep beep. If the user do not press
any button within 2 seconds the time will be set.
• The machine will then set the time, the remaining time will be shown on screen
• Once the total time has elapsed, an alarm will sound
• Cool Drink Mode can be cancelled by following pressing the icon (#12) and (#9) icons simultaneously
for ve seconds.
During this mode:
• When drink cool and child lock modes are active, the child lock mode must be cancelled in order to stop the
alarm sound
• While using this mode, you must regularly check the temperature of the bottles. When the bottles are cool
enough, you must take them out of the appliance.
• Bottles can explode if left in the appliance for too long with drink cool mode active.
Screen Saver Mode
Purpose
This mode saves energy by switching off all control panel lighting when the panel is left inactive.
How to Use
• Screen saver mode will be activated automatically after
30 seconds.
• If you press any key while the lighting of the control panel
is off, the current machine settings will reappear on the
display to let you make any change you wish.
• If you do not cancel the screen saving mode or press any
key for 30 seconds, control panel will remain off.
To deactivate the screen saving mode,
• To cancel the screen saving mode, rst of all, you need to press any key to activate the keys and then press
and hold the Mode button " " (#12) for 3 seconds.
• To reactivate screen saving mode, press and hold the mode button " " (#12) for 3 seconds.
The Child Lock Function
Purpose
Child lock can be activated to prevent any accidental or
unintentional changes being made to the appliance settings.
Activating Child Lock
Press and hold child lock button (#13) for 5 seconds.
Cancelling Child Lock
Press and child lock button (#13) for 5 seconds.
EN -13-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Temperature indicator
In order to help you better set your refrigerator, we have equipped it with a temperature indicator located in
the coldest area.
To better store the food in your refrigerator, especially in the coldest area, make sure the message “OK”
appears on the temperature indicator. If "OK" does not appear, this means that the temperature setting has
not been done properly.
Since “OK” appears in black, it will be difcult to see this indication if the temperature indicator is badly lit. To
be able to see this indication properly, there should be enough light.
Each time the temperature setting device is changed, wait for the stabilisation of the temperature inside the appliance
before proceeding, if necessary, with a new temperature setting. Please change the position of the temperature setting
device progressively and wait at least 12 hours before starting a new check and potential change.
NOTE: Following repeated openings (or prolonged opening) of the door or after putting fresh food into the appliance, it
is normal for the indication “OK” not to appear in the temperature setting indicator. If there is an abnormal ice crystals
build-up (bottom wall of the appliance) on the refrigerator compartment evaporator (overloaded appliance, high room
temperature, frequent door openings), set the temperature setting device to a lower position until compressor off
periods are obtained again.
Putting food in the coldest area of the refrigerator
Your foods will be better stored if you put them in the most appropriate
cooling area. The coldest area is just above the crisper.
The following symbol indicates the coldest area of your refrigerator.
To ensure a low temperature in this area, make sure the shelf is located at
the the same level as this symbol, as shown in the illustration.
The upper limit of the coldest area is indicated by the lower side of the sticker (head of
the arrow). The coldest area upper shelf must be at the same level with the arrow head.
The coldest area is below this level.
As these shelves are removable, make sure they are always at the same level with these
zone limits described on the stickers, in order to guarantee temperatures in this area.
OK
Accessories
Icematic (In some models)
• Take out the ice making tray
• Fill the water to the line.
• Place the ice making tray in its original position
• When ice cubes are formed, twist the lever to drop ice cubes into the icebox.
Note:
• Do not ll the icebox with water in order to make ice. It may be broken.
• The movement of the ice maker may be difcult while the refrigerator is running. In
such a case, it should be cleaned after removing the glass shelves.
=HUR'HJUHH=RQH (In some models)
Keeping food in the chill instead of the freezer or refrigerator GUDZHU
compartment allows food retain freshness and avour longer while
preserving its fresh appearance. If the chiller tray becomes dirty, remove it
and wash with water.
(Water freezes at 0 °C, but foods containing salt or sugar require lowered
temperatures to freeze)
Normally people use the chiller compartment for raw sh, rice, etc...
Do not put foods you want to freeze or ice trays in order to make ice.
Removing the chiller shelf
• Pull the chiller shelf out toward you by sliding it on rails.
• Pull the chiller shelf up from the rail to remove.
Ice tray
• Fill the ice tray with water and place in freezer compartment.
• After the water completely turned into ice, you can twist the tray as shown below to get the ice cube.
EN -14-
Freezer box
• The freezer box is for foods that need to be accessed more easily.
• Removing The freezer box;
• Pull the box out as far as possible
• Pull the front of box up and out.
!Make the inverse of the same operation for the resetting the
sliding compartment.
Note: Always hold the handle of box while moving in or out.
Freezer boxes
CHAPTER -3: USING YOUR FRIDGE FREEZER
Fresh dial
If you want to keep your vegetables longer in that compartment, you have to
change the humidty controller that is located at the front of the crisper, to closed
position. With the aid of this function, humidty level in the crisper compartment,
will stay constant and vegetables will last longer.
If you want to keep your vegetables colder in that compartment, you have to
change the humidity controller to open position. By doing this change, you will
allow the cold air to enter the crisper compartment. As a result of this, your
vegetables will be colder.
If you see any condensation on the glass shelf that is located at the top of
crisper, you can change the humidity controller to open position.
Adapti-Lift door shelf
Five different height adjustments can be made to provide storage areas that you need by
Adapti-Lift.
To change the position of Adapti-Lift;
Lift up front of the shelf (1) and move up or down adjustable door shelf (2) with both hands(Fig
1)
Before releasing the door shelf make sure the door shelf is located at door positions.
Visual and text descriptions on the accessories section may vary according to the model.
Fig.1
(1) (2)
EN -15-
CHAPTER -3: USING YOUR FRIDGE FREEZER
Cleaning
• Make sure to unplug the fridge before cleaning.
• Do not wash your fridge by pouring water .
• You can wipe the inner and outer sides with a soft cloth or a sponge using warm and soapy water.
• Remove the parts individually and clean with soapy water. Do not wash in washing machine.
• Never use ammable, explosive or corrosive material like thinner, gas, acid for cleaning.
Make sure that your fridge is unplugged while cleaning.
Replacing The LED (if an LED is used as lighting)
1 LED strip in freezer compartment and 2 LED strips in cooler compartment
are used to illuminate your appliance.
Please contact the Sharp help desk as this should be changed by
authorized personnel only.
Note: Numbers and location of LED strips may change according to
different models.
Led strip lamps
(In some models)
Led strip lamps
(In some models)
EN -16-
CHAPTER -4: FOOD STORAGE GUIDANCE
Refrigerator compartment
• To reduce frost build up never place liquids with unsealed containers in the fridge compartment.
• Allow warn or hot food to cool down before storing. This helps reduce power consumption.
• To avoid frost build-up ensure that nothing is stored touching the back wall.
• The coldest area of the refrigerator is at the bottom. We recommend to use this area to store food that will perish
easily, such as sh, ready meals, baked goods or dairy products. The warmest area is the top shelf of the door.
We recommend you store butter or cheese here.
Important Note:
• Cover any nished dishes when you put them in the
fridge. Place them in the fridge when they are cool,
otherwise temperature/humidity inside the fridge
increases and this causes the fridge to operate more.
Covering food and beverages also preserves their
avour and aroma.
• Potatoes, onion and garlic shouldn’t be kept in the
fridge.
• Please avoid the foods from touching to temperature
sensor which is located at refrigerator compartment.
In order to keep optimum preservation temperature in
refrigerator compartment, foods mustn’t contact with
the sensor.
Freezer compartment
• Use the freezer to store frozen foods for long periods
of time and make ice cubes.
• To freeze fresh food - ensure that as much of the
surface of food to be frozen is in contact with the
cooling surface.
• Do not put fresh food on either side of frozen food as it can thaw it.
• While freezing fresh foods(i.e meat,sh and mincemeat),divide into portion sizes.
• Once the unit has been defrosted replace the foods into freezer and remember to consume them in a short
period of time.
• Never place warm food in the freezer compartment.
• The instructions shown on frozen food packages should always be followed carefully and if no information is
provided food should not be stored for more than 3 months from the purchased date.
• When buying frozen foods ensure that these have been frozen at suitable temperatures and that the packing
is intact.
• Frozen foods should be transported in appropriate containers to maintain the quality of the food and should be
stored in the freezer as soon as possible.
• If a package of frozen food shows signs of humidity and abnormal swelling it has been previously stored at an
unsuitable temperature and that the contents have deteriorated.
• The storage life of frozen foods depends on the room temperature, thermostat setting, how often the door is
opened, the type of food and the length of time required to transport the product from the shop to your home.
Always follow the instructions printed on the package and never exceed the maximum storage life indicated.
That; If you decide to open the freezer door again immediately after closing, it may be difcult to re-open. This is normal
and after the freezer has reached an equilibrium condition the door will open easily.
Important note:
• Frozen foods, when thawed, should be cooked just like fresh foods. If they are not cooked after being thawed
they must NEVER be re-frozen.
• The taste of some spices found in cooked dishes (anise, basilica, watercress, vinegar, assorted spices, ginger,
garlic, onion, mustard, thyme, marjoram, black pepper, etc.) changes and they assume a strong taste when they
are stored for a long period. Therefore, only add a small amount of spice if planning to freeze, or the desired
spice should be added after the food has been thawed.
• The storage period of food is dependent on the oil used. The suitable oils are margarine, calf fat, olive oil and
butter and the unsuitable oils are peanut oil and pig fat.
• The food in liquid form should be frozen in plastic cups and the other food should be frozen in plastic folios or
bags.
• For normal working conditions, it will be sufcient to adjust the temperature setting of your refrigerator to +4 °C.
• The temperature of the fridge compartment should be in the range of 0-8 °C, fresh foods below 0 °C are iced
and rotted, bacterial load increases above 8 °C, and spoils.
Temperature sensor area
EN -17-
CHAPTER -5: DOOR REVERSAL
Repositioning the door
• It depends on which fridge freezer you have as to whether it is possible the reverse the doors.
• It is not possible where handles are attached at the front of the appliance.
• If your model does not have handles it is possible to reverse the doors, but this needs to be completed by
authorised personnel. Please call Sharp service.
CHAPTER -6: TROUBLESHOOTING
Check Warnings;
Your fridge warns you if the temperatures for cooler and freezer are in improper levels or when a problem occurs in the
appliance. Warning codes are displayed in the Freezer and Cooler Indicators.
ERROR TYPE MEANING WHY WHAT TO DO
E01 Sensor warning Contact the Sharp help desk as
soon as possible.
E02 Sensor warning Contact the Sharp help desk as
soon as possible.
E03 Sensor warning Contact the Sharp help desk as
soon as possible.
E06 Sensor warning Contact the Sharp help desk as
soon as possible.
E07 Sensor warning Contact the Sharp help desk as
soon as possible.
E08 Low Voltage Warning
Power supply to the device
has dropped to below
170W.
- This is not a device failure, this
error helps to prevent damages
to the compressor.
- The voltage needs to be
increased back to required
levels
If this warning continues, contact
the Sharp help desk as soon as
possible.
• Do not put hot food in the refrigerator immediately, wait for the temperature to pass outside. Hot foods increase
the degree of your refrigerator and cause food poisoning and unnecessary spoiling of the food.
• Meat, sh, etc. should be store in the chiller compartment of the food, and the vegetable compartment is
preferred for vegetables. (if available)
• To prevent cross contamination, meat products and fruit vegetables are not stored together.
• Foods should be placed in the refrigerator in closed containers or covered to prevent moisture and odors.
CHAPTER -4: FOOD STORAGE GUIDANCE
EN -19-
CHAPTER -6: TROUBLESHOOTING
If the food in your refrigerator compartment is over cooled
• Is the temperature adjustment right?
• Are there many food recently put inside the freezer compartment? If so, your fridge may over cool the food
inside the refrigerator compartment as it will operate longer to cool these food.
If your fridge is operating too loudly;
To maintain the set cooling level, compressor may be activated from time to time. Noises from your fridge at this time
are normal and due to its function. When the required cooling level is reached, noises will be decreased automatically.
If the noises persist;
• Is your appliance stable? Are the legs adjusted?
• Is there anything behind your fridge?
• Are the shelves or dishes on the shelves vibrating? Re-place the shelves and/or dishes if this is the case.
• Are the items placed on your fridge vibrating?
Normal Noises;
Cracking (Ice cracking) Noise:
• During automatic defrosting.
• When the appliance is cooled or warmed (due to expansion of appliance material).
Short cracking: Heard when the thermostat switches the compressor on/off.
Compressor noise (Normal motor noise): This noise means that the compressor operates normally Compressor
may cause more noise for a short time when it is activated.
Bubbling noise and splash: This noise is caused by the ow of the refrigerant in the tubes of the system.
Water ow noise: Normal ow noise of water owing to the evaporation container during defrosting. This noise
can be heard during defrosting.
Air Blowing Noise (Normal fan noise): This noise can be heard in No-Frost fridge during normal operation of
the system due to the circulation of air.
If humidity builds up inside the fridge;
• Has the food been properly packaged? Have the containers been well dried before they were put into the
refrigerator?
• Are the doors of the refrigerator opened very frequently? When the door is opened, the humidity found in the
air in the room enters the refrigerator. Especially if the humidity rate in the room is too high, the more frequently
the door is opened the faster will be the humidication.
If the doors are not opened and closed properly;
• Do the food packages prevent closing of the door?
• Are the door compartments, shelves and drawers placed properly?
• Are door gaskets broken or torn?
• Is your fridge on a level surface?
If the edges of fridge cabinet that the door joint contact are warm;
Especially in summer (hot weather), the surfaces that the joint contact may get warmer during the operation of the
compressor, this is normal.
IMPORTANT NOTES:
• The compressor protection thermal fuse will cutout after sudden power breakdowns or after unplugging the
appliance, because the gas in the cooling system is not stabilised. This is quite normal, and the fridge will
restart after 4 or 5 minutes.
• The cooling unit of your refrigerator is hidden in the rear wall. Therefore, water droplets or ice may occur on the
rear surface of your fridge due to the operation of the compressor in specied intervals. This is normal. There
is no need to perform a defrosting operation unless the ice is excessive.
• If you will not use your fridge for a long time (e.g. in summer holidays) unplug it. Clean your fridge according to
Part 4 and leave the door open to prevent humidity and smell.
• The appliance you have purchased is designed for home type use and can be used only at home and for
the stated purposes. It is not suitable for commercial or common use. If the consumer use the appliance in
a way that does not comply with these features, we emphasise that the producer and the dealer shall not be
responsible for any repair and failure within the guarantee period.
• If the problem persists after you have followed all the instructions above, please consult an authorised service
provider.
CHAPTER -7: TIPS FOR SAVING ENERGY
1. Always allow foodstuffs to cool before storing in the appliance.
2. Thaw food in the fridge compartment, this helps save energy.
3. The door gasket must be clean and pliable. In case of wear, if your gasket is detachable, replace the gasket. If
not detachable, you have to replace the door.
DE -20-
Ihr Kühlschrank entspricht den derzeit gültigen Sicherheitsvorschriften. Die nicht zweckgerechte Verwendung kann zu
Körperverletzungen oder Schäden an Eigentum führen. Lesen Sie sich vor der ersten Verwendung Ihres Kühlschranks
dieses Handbuch sorgfältig durch, um Schäden zu vermeiden. Es enthält wichtige Sicherheitsinformationen für die
Aufstellung, Sicherheit, Verwendung und Wartung Ihres Kühl-/Gefrierschranks. Heben Sie dieses Handbuch für
spätere Fragen auf.
Inhalt
KAPITEL -1: ALLGEMEINE WARNHINWEISE 21 ...........................................................
KAPITEL -2: IHR KÜHL-/GEFRIERSCHRANK 25 ..........................................................
KAPITEL -3: NUTZUNG IHRES KÜHL-/GEFRIERSCHRANKS 26 ................................
KAPITEL -4: ANLEITUNG ZUR LEBENSMITTELAUFBEWAHRUNG 32 .......................
KAPITEL -5: VERÄNDERUNG DES TÜRANSCHLAGS 33 ............................................
KAPITEL -6: INFORMATIONEN ZUR FEHLERBEHEBUNG 34 .....................................
KAPITEL -7: TIPPS ZUM STROMSPAREN 36 ................................................................
DE BRANDGEFAHR Warnung: Brandgefahr / entammbare Materialien
DE -23-
* Ein beschädigtes Stromkabel/Stecker kann einen
Brand oder einen Stromschlag auslösen. Wenn hier
Beschädigungen vorliegen , muss der Schaden durch
einen Elektriker ausgetauscht werden.
* Dieses Gerät ist nicht für den Einsatz auf Höhen über 2000
m vorgesehen.
Bitte beachten Sie zur Vermeidung einer
Lebensmittelkontamination die folgenden Hinweise:
* Durch längeres Öffnen der Tür kann die Temperatur in den
Fächern des Gerätes deutlich ansteigen.
* Reinigen Sie Flächen, die mit Lebensmitteln in Kontakt
kommen, sowie erreichbare Ablaufsysteme regelmäßig.
* Bewahren Sie rohes Fleisch und Fisch in geeigneten
Behältern im Kühlschrank auf, damit sie nicht mit anderen
Lebensmitteln in Berührung kommen.
* Zwei-Sterne-Gefrierfächer eignen sich zur Aufbewahrung
von Tiefkühlkost, zur Aufbewahrung und Herstellung von
Eiscreme und zur Herstellung von Eiswürfeln.
* Ein-, Zwei- und Drei-Sterne-Gefrierfächer eignen sich
nicht zum Einfrieren frischer Lebensmittel.
* Falls das Kühlgerät lange Zeit nicht verwendet wird, sollten
Sie es abschalten, abtauen, reinigen, abtrocknen und die
Tür offen lassen, damit sich kein Schimmel im Gerät bildet.
Produktspecifikationer
| Varumärke: | Sharp |
| Kategori: | kylskåp |
| Modell: | SJ-BA35CHXIE-EU |
Behöver du hjälp?
Om du behöver hjälp med Sharp SJ-BA35CHXIE-EU ställ en fråga nedan och andra användare kommer att svara dig
kylskåp Sharp Manualer
9 April 2025
2 April 2025
1 April 2025
1 April 2025
27 Januari 2025
6 Januari 2025
10 Oktober 2024
10 Oktober 2024
7 Oktober 2024
6 Oktober 2024
kylskåp Manualer
- kylskåp Blucher
- kylskåp DCG
- kylskåp Coca-Cola
- kylskåp Perlick
- kylskåp Perel
- kylskåp Iberna
- kylskåp Tecnolux
- kylskåp Mercury
- kylskåp V-Zug
- kylskåp IFB
- kylskåp Americana
- kylskåp HABAU
- kylskåp Koenic
- kylskåp Daewoo
- kylskåp Godrej
Nyaste kylskåp Manualer
30 Maj 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
8 April 2025
8 April 2025
8 April 2025
