Sida 1/14
Discussion and Conferencing
DIS-CCU CENTRAL CONTROL UNIT
Quickstart Guide
DIS-CCU Quick Setup Guide
1. Introduction
3. Up and Running 4. Computer Control2. Prepare the Units
Quick Setup Guide
This quick setup guide applies to
most DDS 5900 Discussion System
installations with up to 50 microphone
units.
To operate with the DCS-6000
Conference System, simply add a feature
license to the DIS-CCU. See the Shure
website for information on obtaining and
installing a license.
Important: Do not turn on the
CCU until all microphone units are
connected.
Online Manuals
For more information, refer to the full
system manuals available on Shure.com.
DIS-CCU Quick Setup Guide
1. Introduction
3. Up and Running 4. Computer Control2. Prepare the Units
System Overview
① Central Control Unit (CCU)
System processor: provides power and control to the
microphone units, analog audio inputs and outputs for
external equipment, and a web server to access the
DDS 5900 web interface for complete system control.
② Microphone units
Participants use the microphone units to speak and
listen to other members of the event. Available in two
types:
• Integrated unit that sits on the DC 5980 P portable unit:
table surface. It is programmable as chairman, delegate, or
interpreter.
• Modular unit that installs DC 5900 F flushmount unit:
into the table. It is programmable as chairman or delegate.
③ Browser Interface
Provides full control, set up, and monitoring of the
discussion. Accessible from a computer or tablet
networked with the CCU.
④ Shielded Cat5e cables (not included)
Used to connect DIS devices. Visit the Shure website
for information on high-quality, Shure pre-tested
cables in various lengths from 0.5 m to 100 m.
