Sida 1/8

| 1

ForwardScan | User Guide

Installation

Connecting the transducer

The ForwardScan™ transducer can be connected to the

StructureScan port on the SonarHub or the NSS evo2, leaving the

sonar port open for a CHIRP transducer. Refer to the ForwardScan

installation manual for transducer installation instructions.

Sonar performance

The accuracy of the sonar depth display can be aected by many

factors, including the type and location of the transducer and

water conditions. Never use this equipment to gauge depth or

other conditions for swimming or diving.

The choice, location, and installation of transducers and other

components of the system are critical to the performance of the

system as intended. If in doubt, consult your dealer.

To reduce the risk of misusing this equipment, you must read and

understand all aspects of the supplied documentation.

Sharing ForwardScan data

ForwardScan data can be shared with NSO evo2, NSS evo2 or

Zeus2 displays by connecting the forward-looking transducer to a

SonarHub on your Ethernet network.

You can also connect the transducer to a NSS evo2 to share

ForwardScan data with multi-function displays on your Ethernet

network.

¼Note: We do not recommend operating dierent brands of multi-

function displays on the same network.

Do not rely on this equipment as your principle

Warning:

source of navigation or hazard detection.

ForwardScan™ Sonar

User guide

It is the owner’s sole responsibility to install and Warning:

use the equipment in a manner that will not cause accidents,

personal injury or property damage. The user of this product is

solely responsible for observing safe boating practices.

2 | ForwardScan | User Guide

Operation

ForwardScan™ forward-looking sonar is a navigational aid that

helps you monitor the depth in front of your vessel.

ForwardScan features are available in the latest software update

for your multi-function display. Refer to your display’s brand

website to download the latest update.

¼Note: Screen captures in this document are from a NSS evo 2 unit.

The look of your unit may dier slightly, but it will operate in a

similar manner.

Key Description

1Transducer location shown as the origin on the screen

2Depth range scale/Boat position

3Point data

4Depth history

5Bottom

6Forward range scale

| 3

ForwardScan | User Guide

Accessing ForwardScan

ForwardScan sonar can be displayed full screen or in a multi-

panel page. Refer to your operation manual for information

about setting up a multi-panel page.

ForwardScan setup

Critical forward range and Critical depth

Critical Forward Range and Critical Depth are user-selected

thresholds that dene a critical zone forward of your vessel.

If you travel into water shallow enough to cross into the critical

zone, the Critical Zone alarm is activated. You can display the

critical and warning zones by activating Show zones.

Warning Forward Range and Warning Depth values are based on

the selected Critical Forward Range and Critical Depth values.

¼Note: To receive Critical Zone alerts, enable ForwardScan alarm

on the Alarm settings tab. Refer to your unit’s operation manual

for information on enabling alarms.

Warning zoneCritical zone

ForwardScan display with Show zones active
