POD

TRANSDUCERS

INSTALLATION GUIDE

Parts included

EnvironmentalPod without

temp. sensor

Pod with temp.

sensor

Pod with remote

temp. sensor

Operating

temperature

0°C to +50°C (32°F

to +122°F)

0°C to +50°C (32°F

to +122°F)

0°C to +50°C (32°F

to +122°F)

Storage

temperature

30°C to +70°C

(-22°F to +158°F)

30°C to +70°C

(-22°F to +158°F)

30°C to +70°C

(-22°F to +158°F)

Physical

Weight0.07 kg (0.15 lbs)

w/o cable

0.07 kg (0.15 lbs)

w/o cable

0.18 kg (0.39 lbs)

w/ cable

Cable length6.4 m (21 ft)3.9 m (12.5 ft)6 m (19.5 ft)

Mounting

options

Shoot-thru-hull,

trolling motor

Shoot-thru-hull,

trolling motor

Shoot-thru-hull

Sonar

OutputDepthDepth and

temperature

Depth and

temperature

FrequencyMedium/High

CHIRP (83/200 kHz)

Medium/High

CHIRP (83/200 kHz)

Medium/High

CHIRP (83/200 kHz)

Beam width

(at -3dB)

38° at 83 kHz /

17° at 200 kHz

38° at 83 kHz /

17° at 200 kHz

38° at 83 kHz /

17° at 200 kHz

Max depth304 m (1000 ft) at

200 kHz

304 m (1000 ft) at

200 kHz

304 m (1000 ft) at

200 kHz

Max speed60 knots (70 mph)60 knots (70 mph)60 knots (70 mph)

Technical specications

Pod with/without temp. sensorPod with remote temp. sensor

A

B

Two component epoxy adhesive

www.lowrance.com

www.bandg.com

www.simrad-yachting.com

Produktspecifikationer
