Sida 1/12

WLR-2100/3100

Wireless Router N300

(802.11b/g/n)

User Manual

ABLE OF

ONTENTS

KEY FEATURES .......................................................................................................................... 4

PACKAGE CONTENTS .............................................................................................................. 5

CAUTIONS ................................................................................................................................... 6

PRODUCT LAYOUT ................................................................................................................... 7

NETWORK + SYSTEM REQUIREMENTS ............................................................................10

WLR-2100/3100 PLACEMENT .................................................................................................10

SETUP LAN, WAN ...................................................................................................................... 11

PC NETWORK ADAPTER SETUP ..........................................................................................12

BRING UP THE WLR-2100/3100 ..............................................................................................16

INITIAL SETUP WLR-2100/3100 .............................................................................................16

CONFIGURATION WIZARD ...................................................................................................25

WIRELESS SETTINGS .............................................................................................................27

FIREWALL SETTINGS .............................................................................................................37

ADVANCED SETTINGS ............................................................................................................43

TOOLBOX SETTINGS ..............................................................................................................50

Revision 1.0

Note: All the information contained in this manual was correct at the time of

publication.

However, as our engineers are always updating and improving the product, your

device’s software may have a slightly different appearance or modified

functionality than presented in this manual.

Introduction

Congratulations on your purchase of the WLR-2100/3100 Wireless Network

Broadband Router. The WLR-2100/3100 is compliant with 802.11n and up to

6 times faster than standard 802.11g based routers while still being

compatible with 802.11g & 802.11b. The WLR-2100/3100 is not only a

Wireless Access Point, but also doubles as a 4-port full-duplex Switch that

connects your wired-Ethernet devices together.

At 300 Mbps wireless transmission rate, the Access Point built into the Router

uses advanced MIMO (Multi-Input, Multi-Output) technology to transmit

multiple steams of data in a single wireless channel, giving you seamless

access to multimedia content. Robust RF signal travels farther, eliminates

dead spots and extends network range. For data protection and privacy, the

WLR-2100/3100 encodes all wireless transmissions with WEP, WPA, and

WPA2 encryption.

With the inbuilt DHCP Server & powerful SPI firewall, the WLR-2100/3100

protects your computers against intruders and most known Internet attacks

but provides safe VPN pass-through. With incredible speed and QoS function

of 802.11n(draft2.0), the WLR-2100/3100 is ideal for media-centric

applications like streaming video, gaming, and VoIP telephony to run multiple

media-intense data streams through the network at the same time, with no

degradation in performance.

The router includes Sitecom Cloud Security to protect your home network

against cybercrime.

Produktspecifikationer

Varumärke:	Sitecom
Kategori:	Router
Modell:	WLR-3100
Vikt:	198 g
Bredd:	140 mm
Djup:	115 mm
Höjd:	35 mm
LED-indikatorer:	LAN, Power, WAN, WLAN, WPS
Processorfrekvens:	580 MHz
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Frekvensband:	2.4 GHz
Snabbstartsguide:	Ja
Certifiering:	ROHS, CE
Internminne:	32 MB
Kabelteknik:	10/100Base-T(X)
Processor:	MediaTek MT7620
Återställningsknapp:	Ja
Rackmontering:	Nej
Bandbredd (första):	2.4 GHz
MAC-adressfiltrering:	Ja
Filtrering:	Ja
Ethernet WAN:	Ja
Brandvägg:	Ja
Flashminne:	8 MB
DHCP-server:	Ja
Universal Plug and Play (UPnP):	Ja
Nätverksadressöversättning (NAT):	Ja
DMZ-stöd:	Ja
Full duplex:	Ja
Antenndesign:	Intern
Systemhändelselogg:	Ja
Produktens färg:	Vit
Monteringsbar på väggen:	Ja
Windows-operativsystem som stöds:	Ja
Mac-operativsystem som stöds:	Ja
Inbyggd processor:	Ja
Datahastighet för Ethernet-LAN:	10, 100 Mbit/s
Antal LAN (RJ-45) anslutningar:	4
AC-inspänning:	220 - 240 V
Kryptering/säkerhet:	WPA, WPA-AES, WPA-PSK, WPA-TKIP, WPA2
Kabel inkluderad:	LAN (RJ-45)
Nätverksansluten (Ethernet):	Ja
Stöd för nätverksprotokoll:	TCP/IPv4, IPv6
Likströmsingång:	Ja
Firmware kan uppgraderas:	Ja
Strömkälla av typen:	AC
AC-adapter inkluderad:	Ja
På / av-knapp:	Ja
Webbaserad adminstraion:	Ja
Antenner mängd:	2
Antenn ökningsnivå (max):	3 dBi
Processorkärnor:	1
Kommunikationsstandarder:	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3i, IEEE 802.3u
Stöd för garanterad tjänstekvalitet (QoS):	Ja
Plug & Play-kompatibel:	Ja
Typ av Ethernet LAN-gränssnitt:	Snabb Ethernet
Linux operativsystem som stöds:	Ja
Automatisk kanalväljare:	Ja
Tillgängliga dataöverföringshastigheter, WLAN:	300 Mbit/s
Wi-Fi-standard:	Wi-Fi 4 (802.11n)
Wi-Fi-band:	Singel-band (2,4 GHz)
WPS tryckknapp:	Ja
Portvidarebefordran:	Ja
Dataöverföringshastighet via WLAN (max):	300 Mbit/s
Kontrollampa:	Ja
Gästanvändare:	Ja
VPN-stöd:	Nej
DoS-attacker:	Ja
SPI (Stateful Packet Inspection):	Ja
Verifieringsmetod:	802.1x RADIUS
