Smart-AVI HDR-16x16 Plus V3 Bruksanvisning
Läs gratis den bruksanvisning för Smart-AVI HDR-16x16 Plus V3 (14 sidor) i kategorin Router. Guiden har ansetts hjälpsam av 11 personer och har ett genomsnittsbetyg på 4.5 stjärnor baserat på 6 recensioner. Har du en fråga om Smart-AVI HDR-16x16 Plus V3 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga
Sida 1/14
HDR-16x16 Plus V3
User Manual
16 Port 4K 30Hz HDMI Matrix Switch
Table of Contents
TABLE OF CONTENTS / WHAT'S IN THE BOX? 2
INTRODUCTION 3
FEATURES 3
APPLICATIONS 3
TECHNICAL SPECIFICATIONS 4
HARDWARE INSTALLATION 5
VOLTAGE WARNING 6
FRONT PANEL CONTROL 7
ESTABLISHING AN RS-232 CONNECTION 8
USING THE SmartControl SOFTWARE 9-11
Using TCP/IP Control 12-13
LIMITED WARRANTY STATEMENT 14
WHATS IN THE BOX?
Model Number Descripon
HDR-16x16 Plus V3-S 16 Port HDMI Matrix Switch, Power Cord, Manual
NOTICE:
The informaon contained in this document is subject to change without noce. Smart-AVI makes no warranty of any kind with regard to this material,
including but not limited to, implied warranes of merchantability and tness for any parcular purpose. Smart-AVI will not be liable for errors contained
herein or for incidental or consequenal damages in connecon with the furnishing, performance or use of this material. No part of this document may be
photocopied, reproduced or translated into another language without prior wrien consent from Smart-AVI.
The HDR-16x16 Plus V3 conforms to the HDMI (High Denion Media Interface) standard with HDCP compliance and pro-
vides a connecon to view any of sixteen HDMI video sources on any combinaon of sixteen video displays. The HDR-16x16
Plus V3 provides HDMI output up to 40 feet away at resoluons up to . The system works with Blu-3840x2160 (4k) @30Hz
ray players, TiVo systems, HTPCs, and satellite set-top boxes that connect to an HDMI display. Users can switch to any source
locally using the Front Panel or remotely via RS-232 with Windows®-based soware that is easy to understand and simple to
use, a cornerstone of all SmartAVI products. It can also be controlled via TCP/IP.
• 4K 30Hz HDMI 16x16 router switches 16 HDMI inputs with 16 HDMI outputs
• Sources can be routed independently to displays
• Switching controlled via the front panel, RS-232 and TCP/IP
• Supports high denion video resoluons of 720p, 1080i, 1080p and 3840x2160 (4k) @ 30Hz
• Supports 7.1 Digital Surround Sound Audio
• HDCP and HDMI 1.4 compliant
• Supports EDID for total control of compliant displays
• Learn EDID from any display
• Delivers uncompressed digital video with zero signal loss
• Outputs HDMI up to 40 feet (with high quality acve cables)
• Rack-mountable
•Wall Displays
• Digital Signage
• Airports
• Dealer Rooms
• Control Rooms
• Audio/Visual Presentaons
• Shopping Centers
• Security
• Point-of-Sale
• Hotels/Resorts
APPLICAtions:
fEATURES:
introduction
