SM-D2H Series
4-port Dp-to-HDMI KVM Switch with USB 2.0 Support
USER MANUAL
Designed and Manufactured in the USA
1-800-284-2131
www.smartavi.com
SM-D2H-4S 4-Port Single-Head DP-to-HDMI KVM Switch with USB 2.0 Support
SM-D2H-4D 4-Port Dual-Head DP-to-HDMI KVM Switch with USB 2.0 Support
4-Port HDMI KVM Switch with USB 2.0 Support 2
OVERVIEW
TECHNICAL SPECIFICATIONS_________________________________________________________________
WHAT’S IN THE BOX?_________________________________________________________________________
FRONT AND BACK___________________________________________________________________________
INSTALLATION_______________________________________________________________________________
SYSTEM OPERATION_________________________________________________________________________
FRONT PANEL CONTROL_____________________________________________________________________
HOTKEY AND RS232 SERIAL CONTROL_______________________________________________________
CUSTOM HOTKEY TRIGGERS_________________________________________________________________
TROUBLESHOOTING_________________________________________________________________________
TECHNICAL SUPPORT________________________________________________________________________
LIMITED WARRANTY STATEMENT____________________________________________________________
3
4
4
5-6
7
7
7
8
9
9
10
4-Port DP-to-HDMI KVM Switch with USB 2.0 Support 3
Technical Specifications
VIDEO
Format DisplayPort, HDMI
Input Interface SM-D2H-2S (4) DisplayPort 20-pin
SM-D2H-2D (8) DisplayPort 20-pin
Output Interface SM-D2H-2S (1) HDMI 19-pin
SM-D2H-2D (2) HDMI 19-pin
Resoluon Up to 4K (3840x2160 @ 30Hz)
DDC 5 volts p-p (TTL)
Input Equalizaon Automac
Input Cable Length Up to 20
Output Cable Length Up to 20
AUDIO
Input Interface (4) 3.5 mm Stereo Audio
Output Interface (1) 3.5 mm Stereo Audio
Impedance 600 Ohm
Frequency Response 20 Hz to 20 kHz
Nominal Level 0-1.0 V
Common Mode Rejecon at 60 dB
USB
Signal Type USB 2.0, 1.1, and 1.0 w/ internal hub
Input Interface (4) USB Type B
Output Interface (2) USB 1.1 Type A for KVM Devices; (2) USB 2.0 Type A Transparent
CONTROL
Front Panel Push Buons with LED Indicators
RS-232 DB9 Female - 115200 N,8,1, No ow control
Hot Keys Via Keyboard
OTHER
Power Adapter External 100-240 VAC/12VDC3A @ 24W
Approvals UL, CE, ROHS Compliant
Operang Temperature +32 to +104°F (0 to +40°C)
Storage Temperature -4 to 140°F (-20 to +60°C)
Humidity Up to 80% (No Condensaon)
Emulaon Keyboard and Mouse
