Sida 1/3

Control KVM (Keyboard, Video and Mouse) on 16 computers

with high-resolution WUXGA video and OSD

FEATURES

• SupportsMac,PC,LinuxandSun

• Supportshighresolution1920x120060HzWUXGA

• KVMcontrolof16computers,rackmountable

• UsescomboKVMcableforconsolidated

connectivity

• SupportsUSB1.0/1.1andPS/2keyboardandmouse

withfullemulation

• FrontpaneltactileswitcheswithLEDstatus

indicator

• IncludesOSD(OnScreenDisplay)

• Supportsauto-scanmodefordiscovery

• Easycontrolandaccess

• GovernmentOperations

• DefenseApplications

• SecurityControlRooms

• CorporateCommunications

• ServerOperations

• MedicalCampuses

• Airports

• ProductionStudios

APPLICATIONS

16-Port Cross Platform WUXGA KVM Switch

VNET+16P

VNET+16P WUXGA

USB

16-Port WUXGA and USB KVM Switch

Computer 1 Computer 2 Computer 3 Computer 4 Computer 5 Computer 6 Computer 7 Computer 8 Computer 9 Computer 10 Computer 11 Computer 12 Computer 13 Computer 14 Computer 15 Computer 16

VNET+16P

Combo KVM

APPLICATION DIAGRAM

OVERVIEW

Forthewidevarietyofvenueswheresmoothanduser-friendlyKVM(Keyboard,VideoandMouse)controlareessential,the

VNET+16PKVMswitchbySmartAVIprovidestop-qualityKVMfunctionality.ManyKVMdevicesusemultiplecablesandports

foreachconnectedcomputer,buttheVNET+16PenablestheuseofcombinationKVMcables.Thesehandycablesbundle

WUXGAvideowithUSBandPS/2portstogethertoeliminatethemessandconfusioncausedbyrunningmultiplecablesfrom

eachcomputerconnectedtoaKVMswitch.

Switchingcontrolofthe16connectedcomputersiseasythankstoavarietyofswitchingoptions.Userscanswitchusingthe

front-panelswitchesonthedevice,usingsupportedhotkeyfunctionality,orusingtheOSD(OnScreenDisplay).Alldevices

connectedtotheVNET+16Parehotpluggable,enablinguserstoaddorremovedeviceswithoutneedingtorestarttheswitch.

TheswitchsupportsfullemulationforakeyboardandmouseviaUSB1.0/1.1orPS/2portswithhigh-performancemouse

trackingandsynchronization.Secureaccessthroughcerticateauthenticationanddataencryptionissupported.There’sno

softwarerequiredtoutilizetheswitch,andthereisaminiUSBportforrmwareupdates.

REAL-WORLD APPLICATIONS

TheVNET+16Phasabroadrangeofapplications,butthemainfunctionistocentralizetheaccessofasmanyas16computers

intoasingleworkstation.TheVNET+16Pisparticularlywellsuitedtomedical,industrial,studioanddefenseapplications,where

itisnotpracticalorsafetohavemultipleCPUsnexttotheworkstation.ThecombinationKVMcableusedbytheswitchfurther

enhancestheabilityoftheendusertobetterconsolidateandorganizetheirworkstationintheseandotherenvironments:

• ControlRooms

• Audio/VisualPresentations

• ShoppingCenters

• Hotels/Resorts

• ProductionStudios

• ServerCollocation

• Hospitals

• AcademicCampuses

• Airports

• DealerRooms

VIDEO

Format VGA RGB Analog

Resolution HDTV Up to 1600x1200 @85Hz, 2048x1536 @60Hz

Input Interface (16) HD-15 Male

Output Interface (1) HD-15 Female

H Frequency Range 30-95 kHz

V Frequency Range 50-180 Hz

CONTROL

Front Panel Tact Switches

OSD On Screen Display

USB

Signaling USB 1.1 and 1.0

Input Interface (16) HD-15 Female VGA/USB

Output Interface (2) USB Type A, (2) PS/2

Firmware Update (1) Mini USB

OTHER

Power External 100-240 VAC/5VDC4A @20W

Dimensions 17.3” W x 1.5” H x 6.1” D

Weight 5 lbs

Approvals UL, CE, ROHS Compliant

Operating Temp 32-131°F (0-55 °C)

Storage Temp -4-185 °F (-20-85 °C)

Humidity Up to 95%

SPECIFICATIONS

VNET+16P Front

VNET+16P Rear

ORDERING INFORMATION

Part No. Description

VNET+16PS 16-Port WUXGA, USB KVM Switch. Includes: [VNETX-16P & (PS5VD4A)]

VNET-CB1 Combo KVM Cable for VNET+16P.

Designed and Manufactured in the USA

VNET-CB1 Combined KVM Cable
