SM-UHN SERIES
Advanced 2-Port HDMI KVM Switch
USER MANUAL
Designed and Manufactured in the USA
1-800-284-2131
www.smartavi.com
SM-UHN-2S 2-Port Single-Head HDMI KVM Switch
SM-UHN-2D 2-Port Dual-Head HDMI KVM Switch
2-Port HDMI KVM Switch with Audio and USB 2.0 Support 2
OVERVIEW
TECHNICAL SPECIFICATIONS_________________________________________________________________
WHAT’S IN THE BOX?_________________________________________________________________________
FRONT AND BACK___________________________________________________________________________
INSTALLATION_______________________________________________________________________________
SYSTEM OPERATION_________________________________________________________________________
FRONT PANEL CONTROL_____________________________________________________________________
HOTKEY AND RS232 SERIAL CONTROL_______________________________________________________
CUSTOM HOTKEY TRIGGERS_________________________________________________________________
TROUBLESHOOTING_________________________________________________________________________
TECHNICAL SUPPORT________________________________________________________________________
LIMITED WARRANTY STATEMENT____________________________________________________________
3
4
4
5
6
6
6
7
8
8
9
2-Port HDMI KVM Switch with Audio and USB 2.0 Support 3
Technical Specifications
VIDEO
Format HDMI2.1
Maximum Pixel Clock 165 MHz
Input Interface SM-UHN-2S (2) HDMI
SM-UHN-2D (4) HDMI
Output Interface SM-UHN-2S (1) HDMI
SM-UHN-2D (2) HDMI
Resoluon 3840 x 2160 @ 60 Hz
Color Mode 24-bit
DDC 5 volts p-p (TTL)
Input Equalizaon Automac
Input Cable Length Up to 20
Output Cable Length Up to 20
Data Rate 1.65 Gbps per color
Console Monitors Supports both digital and analog monitors
AUDIO
Input Interface (2) 3.5 mm Stereo Audio
Output Interface (1) 3.5 mm Stereo Audio
Impedance 600 Ohm
Frequency Response 20 Hz to 20 kHz
Nominal Level 0-1.0 V
Common Mode Rejecon at 60 dB
USB
Signal Type USB 2.0, 1.1, and 1.0 w/ internal hub
Input Interface (2) USB Type B (female)
Output Interface (2) USB Type A (female) for K/M emulaon; (2) for USB 2.0 Transparent
CONTROL
Front Panel Push Buons with LED Indicators
RS-232 DB9 Female - 115200 N,8,1, No ow control
Hot Keys Via Keyboard
OTHER
Power Adapter External 100-240 VAC/12VDC2A @ 24W
Dimensions 8.8” W x 2.63” H x 6.69” D
Weight 3.85 lbs
Approvals UL, CE, ROHS Compliant
Operang Temperature +32 to +104°F (0 to +40°C)
Storage Temperature -4 to 140°F (-20 to +60°C)
Humidity Up to 80% (No Condensaon)
Emulaon Keyboard and Mouse
