page 1 / 3 sonel.com
Industrial Multimeter
CMM-30
index: WMGBCMM30
Unique design
Using the latest technologies, we have
created a compact device for working in
the toughest conditions. The rubber hous-
ing reduces the effects of liquid pollution
and falls (IP67 ingress protection).
Visibility in all conditions
Darkness at the workplace is not an issue
thanks to the built-in flashlight. Automatic
backlight of the display, buttons and rota-
ry switch enables to carry out measure-
ments in all lighting conditions.
Multifunctionality
CMM-30 multimeter provides unique ver-
satility with its 11 basic measurement
functions and additional features, includ-
ing relative measurement, measurement
of minimum, maximum and average val-
ues or peak value measurement.
Safety and comfort
Sonel CMM-30 meets the safety require-
ments of CAT III 1000 V / CAT IV 600 V.
The ergonomic housing provides a rm
grip and convenient function selection –
also in protecting gloves.
Wireless communication
Transfer measurement data via Bluetooth,
in „live” mode, to the Sonel Multimeter
Mobile application. This allows to record
and store the results and include addi-
tional description or photos. You can also
share measurement data as an e-mail at-
tachment.
page 2 / 3 sonel.com
Technical specications
Measurement functions Range Resolution Accuracy
±(% m.v. + digits)
AC voltage up to 1000 V from 0.001 V from ±(1.0% m.v. + 5 digits)
DC voltage up to 1000 V from 0.1 mV from ±(0.5% m.v. + 8 digits)
AC / DC current up to 10.00 A from 0.1 μA from ±(1.0% m.v. + 3 digits)
Resistance up to 60.00 MΩ from 0.1 Ω from ±(1.5% m.v. + 5 digits)
Low Z (AC / DC voltage) up to 1000 V from 0.001 V from ±(3.0% m.v. + 5 digits)
Frequency up to 9.999 kHz from 0.001 Hz ±(1.0% m.v. + 5 digits)
Capacitance up to 6000 µF from 0.01 nF from ±(3.0% m.v. + 5 digits)
Duty cycle (%) 20.0…80.0% 0.1% ±(1.2% m.v. + 2 digits)
Temperature measurement -20…+760ºC
-4…+1400ºF
0.1ºC
0.1ºF
±(1.0% m.v. + 5ºC)
±(1.0% m.v. + 9ºF)
Continuity / Diode test ✓ ✓ /
Basic features
Counting 6000 digits
HOLD ✓
Manual / automatic range selection ✓ ✓ /
Advanced features
MIN / MAX / AVG ✓✓✓ / /
AC+DC measurement ✓
PEAK HOLD ✓
Relative measurement REL ✓
TRMS measurement ✓
Memory in mobile application
Bluetooth communication ✓
Other features
Easy access to A / mA fuses ✓ ✓ /
Auto-off ✓
Empty battery indication ✓
Integrated flashlight ✓
Beeper ✓
Display
Type segment-based LCD, 4 digits
Display backlight automatic and manual
Safety and conditions for use
Measuring category (EN 61010) CAT IV 600 V
CAT III 1000 V
Ingress protection IP67
Dimensions 170 x 75 x 48 mm
Operating temperature 0...40ºC
Storage temperature -20…+60ºC
“m.v.” - measured value
page 3 / 3 sonel.com
4x LR03 AAA
1.5 V battery
Factory calibra-
tion certicate
Standard accessories
Set of test leads
for CMM (CAT IV, M)
WAPRZCMM2
Temperature
measurement
Probe (K-type)
WASONTEMK
Adapter
WAADATEMK
2x watertight socket
protection plug
Optional accessories
Temperature
measurement
Probe (K-type, bayonet)
WASONTEMP
Probe (K-type, metal)
WASONTEMK2
M1 hanging
hook straps
WAPOZUCH1 S1 carrying case
WAFUTS1
Check other meters from the CMM family
Sonel CMM-10
• intuitive
• clear reading
• safe and economical
• basic measuring device
Sonel CMM-11
• durable
• versatile
• pocket
• for every electrician
Sonel CMM-40
• precise
• handy
• extended functionality
• for industry
Sonel CMM-60
• ultra-durable
• multi-purpose
• for special applications
• advanced troubleshooting
Set of test leads
CAT IV, S (for CMM)
WAPRZCMM1
CAT IV (for CMP)
WAPRZCMP1
Crocodile clip mini,
1 kV 10A (set)
WAKROKPL10MINI
Calibration certica-
te with accreditation
Standard car-
rying case
Universal magnetic
hanging strap
WAPOZUCH6
