page 1 / 3 sonel.com
Fork clamp meter
CMP-200F
index: WMGBCMP200F
New level of fast measurements
Sonel CMP-200F is an innovative representative of the clamp meter family.
It combines simplicity, speed of measurements and versatility. It contains
all the necessary functionalities and improvements, such as: built-in flashli-
ght, reading of MAX and MIN values, automatic measurement of AC / DC
voltages and many others.
The CMP-200 F is perfect for places where it is difcult to operate the tra-
ditional clamp meter e.g. in narrow switchgear. Open measuring clamps
make measurements faster and easier. LowZ function eliminates the influ-
ence of ghost voltage and ensures accurate readings. The display is always
illuminated, ensuring excellent readability in the dark or even in sunny days
when the screens of other devices fail.
page 2 / 3 sonel.com
m.v. - measured value
Technical specications
Measure functions Range Resolution Precision
±(% m.v. + digits)
AC current 200,0 A 0,1 A ±(3% m.v. + 5 digits)
AC voltage up to 1000 V from 0,001 V from ±(1,2% m.v. + 2 digits)
DC voltage up to 1000 V from 0,001 V from ±(0,9% m.v. + 4 digits)
Low-impedance voltage measurement Low Z up to 600,0 V from 0,001 V ±(3,0% m.v. + 40 digits)
Resistance up to 60,00 MΩ from 0,1 Ω from ±(1,0% m.v. + 4 digits)
Capacitance up to 4000 µF from 0,01 nF from ±(3,0% m.v. + 5 digits)
Basic characteristics
Counting 6.000 digits
HOLD ✓
Automatic range choice zakresu ✓
Advanced characteristics
Open clamp meters ✓
Contactless voltage gauge ✓
MIN / MAX ✓ ✓ /
TRMS measurement ✓
Other characteristics
Automatic power off ✓
Low battery indicator ✓
Built-in flashlight ✓
Beeper ✓
Display
Type segmental LCD, 4 digits
Display backlight manual
Safety and terms of use
Measurement category acc. to EN 61010 CAT IV 600 V
CAT III 1000 V
Safety level IP40
Dimensions 230 x 44 x 66 mm 9.0” x 1.7” x 2.6”|
Weight 270 g 0.6 lbs|
Work temperature 5...40°C 41...104°F|
Storage temperature -20…+60°C -4...+140°F|
page 3 / 3 sonel.com
2x LR6 batte-
ries AA 1,5 V
Standard accesories
Test leads set
for CMM
CAT IV, M
WAPRZCMM2
AC-16 line splitter
WAADAAC16
Crocodile clip mini,
set, 1kV 10A (kpl.)
WAKROKPL10MINI
Optional accesories
Test leads set
for CMM
CAT IV, S
WAPRZCMM1
Factory calibra-
tion certicate
Calibration certica-
te with accreditation
Case M-13
WAFUTM13
Test leads set for
CMM for CMM/CMP
WAPRZCMP1
Test lead 2 m CAT
IV 1000V (banana
plugs, fused 10 A)
black / blue / green
/ red / yellow
WAPRZ002BLBBF10
WAPRZ002BUBBF10
WAPRZ002GRBBF10
WAPRZ002REBBF10
WAPRZ002YEBBF10
Pin probe (banana
socket) red / blue
/ yellow / blackB1
/ black B3
WASONREOGB1
WASONBUOGB1
WASONYEOGB1
WASONBLOGB1
WASONBLOGB3
Crocodile clip
red / blue /
yellow / back
WAKRORE20K02
WAKROBU20K02
WAKROYE20K02
WAKROBL20K01
+
Basic case
