Sida 1/4
System Type
2-way full range line array (Optional 120 W transformer for
25/70.7/100 V applications)
Impedance (Rated)
1
8 Ω
Sensitivity dB @ 2.83 V/ 1 m
92.0 dB
Sensitivity dB @ 1 W/ 1 m
2
92.0 dB
Frequency Response (±3 dB)
3
100 Hz - 20 kHz
Frequency Response (±10 dB)
3
65 Hz - 22 kHz
Max. Program Power
4
300 W
Max. Continuous Power
5
150 W
Max. SPL dB @ 1 m
6
114 dB
Coverage Angle (±6 dB @ 2 kHz)
174° horizontal | 25° vertical
Coverage Angle (±6 dB @ 10 kHz)
50° horizontal | 20° vertical
Coverage Angle (Avg. 2 to 10 kHz)
180° horizontal | 50° vertical (200-10k)
Tap Selector (Optional)
5-position rotary switch with transformer bypass position
Directivity Factor (Q)
9 (Average 100 Hz - 10 kHz) | 12.1 (2 kHz)
Directivity Index (DI)
12.8 dB (Average 100 Hz - 10 kHz) | 16.2 dB (2 kHz)
Low-Frequency Driver
8 - 76 mm (3”) woofer, polypropylene
High-Frequency Driver
8 - 25.4 mm (1”) titanium dome tweeters
Crossover Frequency
2.4 kHz
Network Type: Low-Pass
12 dB/OCT
Network Type: High-Pass
18 dB/OCT
Enclosure Material
Roto-molded polyethylene plastic
Grille
Painted coated stainless steel
Inputs
Weatherproof SpeakOn
Colors
Green, Black, or White
Height
949.3 mm | 37.37”
Width
172.7 mm | 6.8”
Depth
148.5 mm | 5.85”
Depth (Including Bracket)
223.5 mm | 8.8”
Weight
7.80 kg | 17.2 lbs
Shipping Weight
8.5 kg | 18.7 lbs
Included Accessories
Mounting plate and mounting bolts, SpeakOn connector and safety
cable
Optional Accessories
120 W transformer and tap switch
Packaging
1 per box
Certications
CE, RoHS
Description
The SoundTube XT-Spyke is not a typical line array
column loudspeaker. It is an advanced LAPS (Line
Array-Point Source) 2-way design that provides
a very short near-eld extent and robust far-eld
performance. Frequency tapering of low and high
frequency pass bands allows the XT-Spyke to
maintain a more consistent ratio of array height
to radiated wavelength, ensuring a stable vertical
beamwidth that out-performs many other single box
line arrays. Featuring eight 3” woofers and eight 1”
high frequency drivers for extremely smooth high
frequency response, the XT-Spyke achieves superb
coverage in an enclosure measuring only 37.6” x
6.80” x 5.50”.
Features
• Passive, xed length, column line array with 2-way
design.
• Eight 3” (76 mm) polypropylene woofers and eight
1” (25.4 mm) titanium dome tweeter.
• Optional 120 Watt transformer for 25/70.7/100
Volt applications
• Line Array - Point Source (LAPS) technology
provides short, near-eld extent and robust, far-
eld performance
• UV-, scratch-, chlorine- and weather-resistant with
professional-grade components for long-lasting
performance and durability.
• Painted stainless steel grille - custom paintable.
• Available in green, black or white nish.
• Flexible mounting options include surface-mount
and pole-mount.
• Weatherproof SpeakOn connectors allow for fast
connections and easy daisy chaining.
• Included accessories: Stainless steel mounting
plate, mounting bolts and safety cable.
1
Impedance listed per IEC 60268-5 with a minimum less than
80% the nominal impedance
2
1 W/1 M sensitivity determined using nominal impedance
3
Frequency response measured in half or full space as dictated
by speaker mounting conguration
4
Max program power is 3 dB above max continuous power
5
Continuous power rating, EIA-426-B test
6
Max output based on max continuous power
XT-SPYKE PRODUCT SPECIFICATIONS
XT-Spyke
Outdoor Line Array Speaker
Produktspecifikationer
