Sida 1/2
Use with products heavier than the rated weights indicated may result in instability causing possible injury.
Please closely follow the assembly instructions. Improper installation may result in damage or serious personal injury.
Safety gear and proper tools must be used. This product should only be installed by professionals.
Make sure that the supporting surface will safely support the combined weight of the equipment and all attached hardware and components.
Use the mounting screws provided and DO NOT OVER TIGHTEN mounting screws.
This product contains small items that could be a choking hazard if swallowed. Keep these items away from children.
This product is intended for indoor use only. Using this product outdoors could lead to product failure and personal injury.
Ensure that you have received all parts according to the component checklist prior to installation. If any parts are missing or faulty, contact your place of
purchase for a replacement.
Check that the product is secure and safe to use at regular intervals (at least every three months).
5
6
K
K
Note:
Adjust to the desired angle
then tighten the screws
using the hex key wrench as
shown. Alternate between
each screw as you tighten
them.
Item No.: 2731200 (SP-MM-900)
Installation Instructions
Monitor Desk Mount
Rated
2-9 kg
75x75 100x100
MAX
81.3 cm
2
M-C (x4)
D5
M-B (x4)
M5x12
M-A (x4)
M4x12
1
3
4
10-85mm
ø 10mm
(ø 3/8")
OR
Too long
Too Short
A (x1)
K (x1)
5mm
B (x1)
E (x3)
M6x12
F (x1)
H (x1) I (x1)
J (x1)
4mm
D (x2)
M6x10
G (x1)
C (x1)
K
M-A
M-B
M-C
K
3mm
M-A
M-B
M-C
10-85mm
Ø Ø10- 50mm
A
OR
A
B
E
J
C
10-55mm
J D
50-85mm
J
D
C
H
F
E
J
G
I
WARNING: Stored energy hazard!
•Firmly hold the two halves of the spring arm together, then have
another person cut the cable tie.
•Slowly release the pressure on the spring arm and allow it to
gradually stretch to full extension.
To properly balance the arm with monitors mounted, adjust the spring
tension using the supplied Hex key wrench as follows:
First, position and firmly hold the arm horizontally as shown.
Ask for assistance should you require it.
To avoid damage to monitors or mount, always
keep the arm in a horizontal position while
adjusting and ask for assistance if required.
To avoid damage to monitors or mount, always
keep the arm in a horizontal position while
adjusting and ask for assistance if required.
To avoid damage to monitors or mount, always
keep the arm in a horizontal position while
adjusting and ask for assistance if required.
CAUTION
CAUTION
If the arm , turn the adjustment screw drops
counter-clockwise until it stays in a horizontal
position.
If the arm , turn the adjustment screw rises
clockwise until it stays in a horizontal position.
DO NOT over tighten the screws.
