Sida 1/2
200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
DIMENSIONS
FEATURES
Intensifier T® Series HD-TVI 1080p 2MP Bullet Camera
Wall/Ceiling Mount, UTC, 2BNC out for TVI & CVBS, Dual voltage
HTi70TM – 2.8~12mm motorized
motorized
motorized
motorized motorized zoom focus lens,
zoom focus lens,
zoom focus lens,
zoom focus lens, zoom focus lens, dark gray housing
dark gray housing
dark gray housing
dark gray housingdark gray housing
HTi702TM – 5~50mm motorized
motorized
motorized
motorized motorized zoom focus lens,
zoom focus lens,
zoom focus lens,
zoom focus lens, zoom focus lens, dark gray housing
dark gray housing
dark gray housing
dark gray housingdark gray housing
SPECIFICATIONS
Image Sensor.................. 1/2.9” Progressive Scan CMOS, 2MP
Minimum Illumination....... 0.001 lux (Sens-up X32)
Effective Pixels................ 1984 (H) x 1105 (V)
Total Pixels...................... 2000 (H) x 1121 (V)
Scanning System............ Progressive
S/N Ratio......................... More than 50dB
Output Resolution............ 1920x1080 @ 30fps
Video Output.................... 1.0Vp-p / 75 Ohms
Electronic Shutter............ Auto / Manual (1/30 – 1/30,000 sec.)
Day / Night....................... Color (default) / BW / Ext / Auto
Test Monitor Output......... CVBS (BNC out in Yellow)
Communication............... UTC (up the coax)
Power............................. 12VDC / 24VAC
Power Consumption........ 600mA max. (DC), 450mA max. (AC)
Operating Temperature.... -40 F – 140 F ° °
Unit Dimensions.............. 9.64” (L) x 3.72” (Dia.)
Unit Weight...................... 2 lbs (camera), 0.9lbs (junction box)
Certifications.................... FCC, RoHS
Signal Distance............... Up to 1600 feet
(depending on coax quality)*
• Full HD resolution over coax (HD-TVI)
• Supports up to Full HD 1080p @ 30fps
• True WDR operation
• Superior low-light performance
• Amplify existing light with no distance limitation
• Presets: Outdoor, Low Light, Hallway, Lobby, Elevator, Indoor
• Built-in heater and anti-fog glass reduces condensation
• 3-axis for wall and ceiling mounting
• Full OSD operation through on-board control and UTC (up the coax)
• Additional 960H analog output
• Signal distance up to 1600 feet*
• IP67 compliant, weather resistant
• 12VDC & 24VAC dual voltage operation
• 5 year warranty
OSD MENU TREE
PRESET MODE
•OUTDOOR
•INDOOR•LOW LIGHT
•LOBBY
•HALLWAY
•ELEVATOR
MAIN SETUP
EXPOSURE
•B/W
•EXTERN
• • •LOW MIDDLE HIGH
• • •SHARPNESS GAMMA MIRROR
•FLIP
DAY / NIGHT
COLOR
SPECO DNR
EXIT
•BRIGHTNESS
•SHUTTER
BACKLIGHT
•HLC•BLC
•WDR
•AUTO
• •AWB COLOR GAIN
• •ACE DEFOG
SYSTEM
•OUTPUT
•FREQ.
•IMAGE RANGE
•INTENSIFY
•AGC
•COLOR
•SHADING
IRIS
MOTION
•FRAME RATE
•LANGUAGE
•COLOR BAR
•RESET
•CAM TITLE
•D-ZOOM
•PRIVACY
2-MOTOR
•COLOR SPACE
•COM.
INTCM1
(Pole/Corner Mount)
DIMENSIONS
Camera
Optional Accessories
Unit : inch
Junction Box
included
OSD Joystick
Video Test (CVBS)
Right (Near)
Up (Zoom-In)
Down (Zoom-Out)
Left (Far)
OSD CONTROL
