Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: July 18, 2019

Product Diagram (CONNLOCKPK)

PartFunction

1Steel Cable Tether• Tether to A/V CablesA/V Adapters

2Aluminum Ferrule

• Create a loop by routing the Steel Cable Tether

through each opening

• Crimp to secure the loopSteel Cable Tether

3Heat Shrink Tubing• Shrink around the crimped Aluminum Ferrules

Requirements

• Swaging Tool x 1

• (Optional) Heat Gun x 1

• (Optional) Wire Cable Cutter x 1

For the latest requirements please visit: . www.startech.com/CONNLOCKPK

Installation

1. (Optional) Thread the onto the center of the Heat Shrink TubingSteel Cable

Tether.

Note: This step is necessary if you plan to utilize the . Heat Shrink Tubing

2. Thread the onto each end of the .Aluminum FerrulesSteel Cable Tether

3. Wrap one end of the around the .Steel Cable Tether A/V Cable

Connectivity Lock - Steel Cable Tether

4. Route the working end of the back into the second hole in the Steel Cable Tether

Aluminum Steel Ferrule.

5. Cinch the until it ts snugly around the.Steel Cable Tether A/V Cable

Note: Do not cinch the down all the way. Cinch the SSteel Cable Tetherteel Cable

TetherAV until it is no longer possible to slip the loop over the connectors of the

Cable.

6. Crimp the in the appropriate tting of a . Aluminum Steel FerruleSwaging Tool

(Figure 1)

Note: It may be necessary to crimp the a few times to create Aluminum Steel Ferrule

a strong and circular shaped crimp.

7. Wrap the other end of the around the cable portion of the Steel Cable TetherA/V

Adapter.

1

2

3

Figure 1
