Sida 1/2
Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 01/22/2015
For the most up-to-date information, please visit: www.startech.com
Packaging Contents
• 1x 7 Port PCI Express USB 3.0 Card
• 1x Low-Prole Bracket
• 1x Driver CD
• 1x Instruction Manual
System Requirements
• PCI Express enabled computer with an available PCI Express p1-x1 slot
or higher (x4, x8, x16)
• SATA power connector (highly recommended, but optional)
• Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64),
Windows Server® 2012, 2008 R2, Linux 2.6.31 and up (Tested up to
3.5)
Product Overview
PEXUSB3S7
7 Port PCI Express SuperSpeed USB 3.0 Card with UASP - SATA Power
USB 3.0 Ports Type
“A” Female x6
PCI Express x1
SATA Power
Internal USB 3.0
Port Type “A”
Female
Installation
Hardware Installation
WARNING!
PCI Express cards, like all computer equipment, can be severely
damaged by static electricity. Be sure that you are properly
grounded before opening your computer case or touching your PCI
Express card. StarTech.com recommends that you wear an anti-
static strap when installing any computer component. If an anti-
static strap is unavailable, discharge yourself of any static electricity
build-up by touching a large grounded metal surface (such as the
computer case) for several seconds. Also be careful to handle the PCI
Express card by its edges and not the gold connectors.
1. Turn your computer o and any peripherals connected to the
computer (i.e. printers, external hard drives, etc.). Unplug the
power cable from the rear of the power supply on the back of the
computer and disconnect all peripheral devices.
2. Remove the cover from the computer case. (See documentation
for your computer system for details).
3. Locate an open PCI Express p1-x1 slot and remove the metal cover
plate on the rear of the computer case (See documentation for
your computer system for details).
Note: This card will work in PCI Express slots of additional lanes (i.e.
x4, x8, or x16 slots).
4. Gently insert the card into the open PCI Express slot and fasten
the bracket to the rear of the computer case.
Note: If installing the card into a small form-factor/low-prole
desktop system, replacing the pre-installed standard-prole bracket
with the included low-prole (half-height) installation bracket may
be necessary.
5. It is highly recommended you connect the optional SATA power
using an available SATA power connector from the computers
power supply.
Note: It is highly recommended that SATA power is connected to the
card to ensure sucient power is provided to each USB 3.0 port.
6. Place the cover back onto the computer case.
7. Insert the power cable into the socket on the power supply of the
computer, and reconnect all other connectors removed in Step 1.
